双锥Bump压缩面设计及气动特性

王龙; 钟易成; 吴晴; 杨应凯

双锥Bump压缩面设计及气动特性

1.
南京航空航天大学能源与动力学院,南京 210016
2.
中国电子科技集团公司第三十八研究所,合肥 230001
3.
中国航空工业集团公司成都飞机设计研究所,成都 610015

基金项目: 成都飞机设计所联合基金

计量
- 文章访问数: 2246
- HTML浏览量: 203
- PDF量: 1248
- 被引次数: 0
出版历程
- 收稿日期: 2011-12-28
- 刊出日期: 2013-01-28

Bipyramid Bump compression surface design and aerodynamic characteristics

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China
2.
The No.38 Research Institute, China Electronics Technology Group Corporation,Hefei 230001,China
3.
Chengdu Aircraft Design and Research Institute, Aviation Industry Corporation of China,Chengdu 610015,China

摘要

摘要: 采用反设计方法研究双锥Bump压缩面设计技术,该方法实质是融合运动间断边界在运动网格条件下对轴对称欧拉方程组求解.为避免激波捕获法对激波型面位置求解误差,应用计算域分块的方法预估第2道激波,在此基础上采用流线追踪法生成Bump压缩面;结合平面机身设计一双锥Bump实例,运用计算流体力学仿真手段对其进行黏性数值模拟.研究结果表明:①该模型流场结构仍保持较强的附面层扫掠能力;②在来流马赫数为2.0条件下,相比传统的正圆锥乘波体Bump压缩面设计,新型设计方法可使Bump外压缩系统总压恢复系数提高0.04左右,为Bump进气道性能提高奠定基础.
- Bump进气道 /
- 运动间断边界算法 /
- 反设计方法 /
- 运动间断拟合 /
- 计算流体力学
Abstract: An inverse design numerical method was introduced to investigate the design technique of new bipyramid bump compression surface.The axisymmetric Euler equations with the discontinuities boundary condition were solved on dynamic mesh using computational domain partition method which calculated the second shock wave in order to avoid solving the shock location error by shock capture method.On this basis,a bipyramid Bump example combined with the flat plane was designed by the streamline tracking method introduced to generate Bump compression surface,and it was simulated by computational fluid dynamics in viscosity.The results show that:(1) the model maintains a strong boundary layer swept capacity in the flow field structure;(2) at Mach number 2.0 condition,the method adopted here can make the total pressure recovery coefficient of the Bump compression system increases 0.04 compared to the traditional Bump compression surface based on cone waverider design,also lays the foundation for improving the Bump inlet performance.
- Bump inlet /
- dynamic discontinuities boundary arithmetic /
- inverse design numerical method /
- dynamic discontinuities fitting /
- computational fluid dynamic(CFD)

HTML

参考文献(16)

[1]	Gridley M C,Cahill M J.ACIS air induction system trade study .AIAA 1996-2646,1996.
[2]	Gridley M C,Walker S H.Inlet and nozzle technology for 21st century fighter aircraft .ASME 96-GT-244,1996.
[3]	McFarlan III J D.Joint strike fighter diverterless supersonic inlet .Washing DC,US:National Press Club,2000.
[4]	Ketter F C.Lockheed Martin joint strike fighter low risk STOVL propulsion system .Washing DC,US:National Press Club,1999.
[5]	钟易成.基于乘波理论的新型进气道设计研究 .南京:南京航空航天大学,2003. ZHONG Yicheng.The design research for innovatory inlets derived from waverides .Nanjing:Nanjing University of Aeronautics and Astronautics,2003.(in Chinese)
[6]	钟易成,余少志,吴晴.凸包 (Bump)进气道/DSI模型设计及气动特性研究[J].航空动力学报,2005,20(5):740-745. ZHONG Yicheng,YU Shaozhi,WU Qing.Research of Bump inlet (DSI) model design and its aerodynamic propertie[J].Journal of Aerospace Power,2005,20(5):740-745.(in Chinese)
[7]	梁德旺,李博.无隔道进气道反设计及附面层排除机理分析[J].航空学报,2005,26(3):286-289. LIANG Dewang,LI Bo.Reverse design of diverterless inlet and mechanism of diversion of boundary layer[J].Acta Aeronautica et Astronautica Sinica,2005,26(3):286-289.(in Chinese)
[8]	杨应凯.枭龙飞机Bump进气道设计[J].南京航空航天大学学报,2007,39(4):449-452. YANG Yingkai.Design of Bump inlet of thunder/JF-17 air-craft [J].Journal of Nanjing University of Aeronautics and Astronautics,2007,39(4):449-452.(in Chinese)
[9]	杨应凯.Bump进气道设计与试验研究[J].空气动力学学报,2007,25(3):336-338. YANG Yingkai.The research of Bump inlet design and test[J].Acta Aerodynamica Sinica,2007,25(3):336-338.(in Chinese)
[10]	李博,梁德旺.无隔道超声速进气道/前机身一体化计算与试验[J].航空学报,2009,26(3):286-289. LI Bo,LIANG Dewan.Numerical simulation and experiment of integral flow field of diverterless supersonic inlet/forebody[J].Acta Aeronautica et Astronautica Sinica,2009,26(3):286-289.(in Chinese)
[11]	Kim S D.Aerodynamic design of a supersonic inlet with a parametric Bump[J].Journal of Aircraft,2009,46(1):198-202.
[12]	Lim S,Koh D H,Kim S D,et al.A compitational study on the efficiency of boundary layer bleeding for the supersonic Bump type inlet .AIAA 2009-34,2009.
[13]	Kim S D,Song D J,Lim S.A numerical analysis on three-dimensional flow field in a supersonic Bump inlet .AIAA 2007-689,2007.
[14]	吴晴,钟易成,余少志,等.基于DDB的二维/轴对称三波交汇流场数值模拟[J].空气动力学学报,2010,28(6):683-688. WU Qing,ZHONG Yicheng,YU Shaozhi,et al.Numerical simulation based on DDB fitting for 2D/axisymmetric triple shocks[J].Acta Aerodynamica Sinica,2010,28(6):683-688.(in Chinese)
[15]	吴晴,钟易成,胡骏,等.基于激波拟合与柔性壁的反设计数值方法研究[J].空气动力学学报,2009,27(2):234-239. WU Qing,ZHONG Yicheng,HU Jun,et al.Numerical method for shape inverse design based on shock-fitting and flex-wall[J].Acta Aerodynamica Sinica,2009,27(2):234-239.(in Chinese)
[16]	Oswatisch K.Pressure recovery in missiles with reaction propulsion at high supersonic speeds (the efficiency of shock diffusers) .NACA TM1140,1947.
