氢燃料先进旋涡燃烧室流动和燃烧特性

邓洋波; 孙海涛; 王玉龙; 严春吉

氢燃料先进旋涡燃烧室流动和燃烧特性

大连海事大学轮机工程学院,辽宁大连 116026

基金项目: 国家自然科学基金(51076020)

计量
- 文章访问数: 1612
- HTML浏览量: 78
- PDF量: 1159
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-23
- 刊出日期: 2013-01-28

Flow and combustion characteristics of advanced vortex combustor with hydrogen fuel

Marine Engineering College, Dalian Maritime University,Dalian Liaoning 116026,China

摘要

摘要: 为了对整体煤气化联合循环(IGCC)燃气轮机的氢燃料先进旋涡燃烧室(advanced vortex combustor,AVC)结构设计提供理论依据,应用实验和数值模拟相结合的方法对AVC气流流动特性受燃烧室几何参数影响规律进行研究,在此基础上,确定氢燃料AVC内前、后钝体合理的布置方式.应用19步氢气和空气详细化学反应机制,对氢燃料AVC流动和燃烧特性进行数值模拟研究,结果显示:氢气和空气预混和气体主气流当量比为0.65时,在前、后钝体之间形成的凹腔内无喷射气流条件下,燃氢AVC能够形成稳定燃烧,出口温度被控制在1950K以下,总压损失系数为2.7665%,燃烧效率为99.54%.相对于凹腔内无喷射气流,凹腔内有喷射气流的AVC旋涡在z轴方向分层有序、结构更加稳定,但不同xy截面上温度分布不同,导致出口截面温度分布不均匀,总压损失系数略有增大,燃烧效率提高了.
- 先进旋涡燃烧室(AVC) /
- 整体煤气化联合循环(IGCC) /
- 流动特性 /
- 燃烧 /
- 前钝体 /
- 后钝体
Abstract: To provide a valuable theory basis for the structure design of the advanced vortex combustor (AVC) of the turbine in integrated gasification combined cycle (IGCC),experiment and numerical simulation were conducted to study the flow characteristics of the AVC under cold flow condition.On this basis,the reasonable arrangement of fore-body and after-body in the AVC with hydrogen fuel was attained.Using 19-step chemical reaction mechanism,a numerical simulation was conducted to study the flow and combustion characteristics of AVC with hydrogen fuel.The results show that the combustion can be steadily maintained,and the temperature at the outlet can be controlled below 1950K with the equivalence ratio of hydrogen and air being kept at 0.65 without gas injected into the cavity between fore-body and after-body.At the same time,there are total pressure loss coefficient of 2.7665% and combustion efficiency of 99.54%.Contrasting to the AVC without gas injected into the cavity,the AVC with flow injected has more regular and steadier vortex configuration,higher combustion efficiency,higher total pressure loss coefficient,and uneven temperature distribution at the outlet.
- advanced vortex combustor(AVC) /
- integrated gasification combiend cycle (IGCC) /
- flow characteristic /
- combustion /
- fore-body /
- after-body

HTML

参考文献(15)

[1]	王云,赵小路,徐建中.新概念旋转冲压发动机的研究与分析[J].北京航空航天大学学报,2004,30(8):777-782. WANG Yun,ZHAO Xiaolu,XU Jianzhong.Research of new conceptive rotated ramjet[J].Journal of Beijing University of Aeronautics and Asronautics,2004,30(8):777-782.(in Chinese)
[2]	邓洋波,钟兢军.旋转冲压发动机驻涡燃烧技术研究现状分析[J].燃气涡轮实验与研究,2006,19(3):58-62. DENG Yangbo,ZHONG Jingjun.Progress of research on trapped vortex combustion technology in rotated ramjet[J].Gas Turbine Experiment and Research,2006,19(3):58-62.(in Chinese)
[3]	何小民,王家华.驻涡火焰稳定器冷态流场特性的初步研究[J].航空动力学报,2002,17(5):567-571. HE Xiaomin,WANG Jiahua.An investigation on the fluid characteristics of trapped-vortex combustor[J].Journal of Aerospace Power,2002,17(5):567-571.(in Chinese)
[4]	Kendrick D W,Chenevert B C,Trueblood B,et al.Combustion system development for the Ramgen engine[J].Journal of Engineering for Gas Turbines and Power,2003,125(4):885-894.
[5]	Edmonds R G,Steele R C,Williams J T,et al.Ultra-low NO_x advanced vortex combustor //Proceedings of the ASME Turbo Expo 2006 Power for Land,Sea,and Air.Barcelona,Spain:ASME,2006:255-262.
[6]	邓洋波,刘世青,钟兢军.先进旋涡燃烧室燃烧特性数值模拟[J].大连海事大学学报,2008,34(3):21-24. DENG Yangbo,LIU Shiqing,ZHONG Jingjun.Numerical simulation for combustion characteristics of advanced vortex combustor[J].Journal of Dalian Maritime University,2008,34(3):21-24.(in Chinese)
[7]	邓洋波,刘世青,钟兢军.先进旋涡燃烧室流动与燃烧特性分析[J].航空动力学报,2009,24(3):488-493. DENG Yangbo,LIU Shiqing,ZHONG Jingjun.Analysis of the combustion and flow field characteristics of advanced vortex combustor[J].Journal of Aerospace Power,2009,24(3):488-493.(in Chinese)
[8]	邓洋波,刘世青,钟兢军.AVC中钝体布置与燃烧室流动特性研究[J].工程热物理学报,2008,29(8):1415-1418. DENG Yangbo,LIU Shiqing,ZHONG Jingjun.Reseach of the flow characteristics of cold state flow of advanced vortex combustion[J].Jounal of Engineering Thermophysics,2008,29(8):1415-1418.(in Chinese)
[9]	陈光诚.流体力学实验技术[M].北京:机械工业出版社,1983.
[10]	林峰,张堃元,彭成一.五孔探针的标定技术[J].航空动力学报.1990,5(3):236-238. LIN Feng,ZHANG Kunyuan,PENG Chengyi.Calibration techniques of five-hole probe[J].Journal of Aerospace Power,1990,5(3):236-238.(in Chinese)
[11]	Requemore W M,Shouse D,Burrus D.Vortex combustor concept for gas turbine engines . AIAA 2001-0483,2001.
[12]	Frassoldati A,Faravelli T,Ranzi E A.A wide range modeling study of NO_x formation and nitrogen chemistry in hydrogen combustion[J].International Journal of Hydrogen Energy,2006,31(15):2310-2328.
[13]	Strohle J,Myhrvold T.An evaluation of detailed reaction mechanisms for hydrogen combustion under gas turbine conditions[J].International Journal of Hydrogen Energy,2007,32(1):125-135.
[14]	Rortveit G J,Hustad J E,Li S C,et al.Effects of diluents on NO_x formation in hydrogen counterflow flames[J].Combustion and Flame,2002,130(1):48-61.
[15]	Alejandro M B,Suresh K A.A numerical study of H₂-air partially premixed flames[J].International Journal of Hydrogen Energy,2005,30(3):327-339.
