反向旋转盘腔内部流动特性

陈淑仙; 张靖周; 谭晓茗; 左渝钰

反向旋转盘腔内部流动特性

1.
中国民航飞行学院航空工程学院,四川广汉 618307
2.
南京航空航天大学能源与动力学院,南京 210016

基金项目: 国家自然科学基金(51076063); 中国民航飞行学院科学研究基金(J2007-24)

计量
- 文章访问数: 1886
- HTML浏览量: 198
- PDF量: 1053
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-12
- 刊出日期: 2013-01-28

Flow characteristics inside counter-rotating disk cavity

1.
Aviation Engineering Institute, Civil Aviation Flight University of China,Guanghan Sichuan 618307,China
2.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 对反向旋转盘腔系统内部流动特性进行了数值模拟,计算结果与已有文献中的实验结果对比表明,采用的数学模型和计算方法是准确的.数值模拟结果表明:反向旋转盘腔内流动结构较为复杂,转速比对流动结构有重要影响.根据流动结构特点研究了旋转雷诺数和转速比对盘腔内压力分布以及转盘壁面摩擦力矩的影响,旋转雷诺数越大,盘腔内的压力越低,转盘壁面的摩擦力矩越大.反向同速旋转有助于增大盘腔内的压力,但与其他转速比相比其摩擦力矩最大.
- 反向旋转盘腔 /
- 紊流流动 /
- 数值模拟 /
- 压力分布 /
- 摩擦力矩
Abstract: The flow inside a counter-rotating disk cavity was studied numerically,and the validity of numerical model and methodology was evaluated by comparing the results with the experimental data in the literature.The results show that the flow structure in the cavity between counter-rotating disks is complex and the disk angular velocity ratio has an important effect on it.The effects of rotation Reynolds number and disk angular velocity ratio on the pressure in the cavity and frictional moment number on the disk were also studied.The results indicate that the pressure decreases and the frictional moment increases with the increase of rotational Reynolds number,and the pressure is the largest when the frictional moment is also the largest with the counter-rotating disks at the same speeds compared with others at different speeds.
- counter-rotating disk cavity /
- turbulent flow /
- numerical simulation /
- pressure distribution /
- frictional moment
