双倾斜壁缝式机匣处理对离心压气机性能的影响

滕金芳; 朱铭敏; 羌晓青

双倾斜壁缝式机匣处理对离心压气机性能的影响

上海交通大学航空航天学院,上海 200240

计量
- 文章访问数: 1589
- HTML浏览量: 89
- PDF量: 1194
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-17
- 刊出日期: 2013-01-28

Effect of double inclined slotted casing treatment on centrifugal compressor performance

School of Aeronautics and Astronautics, Shanghai Jiaotong University,Shanghai 200240,China

摘要

摘要: 采用数值仿真手段研究不同倾斜方向的双倾斜壁缝式机匣处理对离心压气机性能的影响.研究结果表明:合适的机匣处理缝倾角组合有助于合理组织导叶和动叶气流角匹配关系.通过详细分析离心压气机内部流场表明:双倾斜壁缝式机匣处理方案A通过对动叶叶尖泄漏流的抽吸和重新组织,对机匣处理缝后部的低能流体抽吸并吸除,经过背腔在机匣处理缝前部重新注入相邻的叶栅流道,从而在轴向和周向控制了叶尖泄漏流的发展,改善了下游的堵塞情形,大幅度提高了压气机的稳定工作裕度.
- 离心压气机 /
- 机匣处理 /
- 双倾斜壁缝式 /
- 泄漏流 /
- 数值仿真
Abstract: Numerical investigations were conducted to study the effects of double inclined slotted casing treatment on a certain centrifugal compressor's performance.The numerical results show that appropriate inclined angle combination of casing treatment slots helps to organize the flow matching between inlet guide vane and rotor blades.The detailed analysis of the flow-filed in compressor with casing treatment indicates that configuration A has the best ability to expand stability margin.With the suction and re-organization of the tip leakage flow,high energy flow is re-injected into the adjacent flow channel which controls the development intent of leakage flow in the axial and circumferential directions and improves the blockage situation downstream of rotor passage.Thus,the compressor stability margin is substantially increased.
- centrifugal compressor /
- casing treatment /
- double inclined slotted /
- leakage flow /
- numerical simulation

HTML

参考文献(17)

[1]	Koch C C.Experimental evaluation of outer case blowing or bleeding of single stage axial flow compressor:Part Ⅵ final report .NASA CR-54592,1970.
[2]	Bailey E E.Effect of grooved casing treatment on the flow range capability of a single-stage axial-flow compressor .NASA-TM-X-2459,1972.
[3]	SUN Xiaofeng.On the relation between the inception of rotating stall and casing treatment .AIAA-96-2579,1996.
[4]	杜辉,朱俊强,楚武利,等.凹槽导流片式机匣处理的结构尺寸优化研究[J].推进技术,1998,19(1):70-74. DU Hui,ZHU Junqiang,CHU Wuli,et al.Optimization of structural parameters of recess vaned casing treatment[J].Journal of Propulsion Technology,1998,19(1):70-74.(in Chinese)
[5]	楚武利,朱俊强,刘志伟.折线斜缝式机匣处理的实验研究及机理分析[J].航空动力学报,1999,14(3):270-274. CHU Wuli,ZHU Junqiang,LIU Zhiwei.Experimental research and analysis of sloped slotted casing treatment[J].Journal of Aerospace Power,1999,14(3):270-274.(in Chinese)
[6]	ZHU Junqiang,CHU Wuli.The effects of bend skewed groove casing treatment on performance and flow field near endwall of an axial compressor .AIAA-2005-809,2005.
[7]	Behnam H B,Joao A T,Paul C I,et al.Parametric study of tip clearance-casing treatment on performance and stability of a transonic axial compressor[J].Journal of Turbomachinery,2004,126(4):527-535.
[8]	Emmrich R,Hönen H,Niehuis R.Time resolved experimental investigations of an axial compressor with casing treatment[J].Journal of Turbomachinery,2009,131(1):011018.1-011018.9.
[9]	LU Xingen,CHU Wuli,ZHU Junqiang,et al.Numerical investigations of the coupled flow through a subsonic compressor rotor and axial skewed slot[J].Journal of Turbomachinery,2009,131(1):011001.1-011001.9.
[10]	Gourdain N,Leboeuf F.Unsteady simulation of an axial compressor stage with casing and blade passive treatments[J].Journal of Turbomachinery,2009,131(2):021013.1-021013.12.
[11]	Voges M,Schnell R,Willert C,et al.Investigation of blade tip interaction with casing treatment in a transonic compressor:Part Ⅰ particle image velocimetry[J].Journal of Turbomachinery,2011,133(1):011007.1-011007.11.
[12]	Schnell R,Voges M,Mönig R,et al.Investigation of blade tip interaction with casing treatment in a transonic compressor:Part Ⅱ numerical results[J].Journal of Turbomachinery,2011,133(1):011008.1-011008.11.
[13]	《航空发动机设计手册》编委会.航空发动机设计手册:第8册[M].北京:航空工业出版社,1999.
[14]	Hathaway M D,Chriss R M.Experimental and computational investigation of the NASA low speed centrifugal compressor flow field[J].Journal of Turbomachinery,1993,115(3):527-542.
[15]	Chriss R M,Hathaway M D,Wood J R.Experimental and computational results from the NASA Lewis low speed centrifugal impeller at design and part-flow conditions[J].Journal of Turbomachinery,1996,118(1):55-65.
[16]	高鹏,楚武利,杨泳.低速离心压气机非稳态流和机匣处理的数值分析[J].推进技术,2007,28(1):32-35. GAO Peng,CHU Wuli,YANG Yong.Numerical analysis for the unsteady flow and casing treatment in a low speed centrifugal compressor[J].Journal of Propulsion Techno-logy,2007,28(1):32-35.(in Chinese)
[17]	胡良军,杨策,祁明旭,等.离心压气机机匣处理与导叶轮缘放气的扩稳机理分析及比较[J].机械工程学报,2009,45(7):138-144. HU Liangjun,YANG Ce,QI Mingxu,et al.Numerical investigation and comparison on the stall improvement mechanism of centrifugal compressor with inducer casing and bleeding[J].Journal of Mechanical Engineering,2009,45(7):138-144.(in Chinese)
