某型无人直升机带传动离合器控制系统

周尧明; 蒙志君; 何维; 武哲

某型无人直升机带传动离合器控制系统

周尧明¹,
蒙志君^1, ,,
何维^1,2,
武哲¹

1.
北京航空航天大学航空科学与工程学院,北京 100191
2.
空军航空大学航空理论系,长春 130022

计量
- 文章访问数: 1612
- HTML浏览量: 199
- PDF量: 1299
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-09
- 刊出日期: 2013-01-28

Belt drive clutch control system of unmanned helicopter

ZHOU Yao-ming¹,
MENG Zhi-jun^{1
, ,},
HE Wei^1,2,
WU Zhe¹

1.
School of Aeronautic Science and Engineering, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
Aviation Theory Department, Aviation Univeristy of Airforce,Changchun 130022,China

摘要

摘要: 针对某型直升机无人化改装过程中带传动离合器的控制要求,探讨一种具有安全保护功能的控制系统.通过分析带传动离合器的操纵原理和控制特性,提出了控制系统的设计需求,确定了控制系统的总体方案.采用转速反馈和间歇接合的控制方法,实现离合器的自动接合,避免发动机转速降幅过大.通过采集着陆信号,采取硬件注销的方式,避免无人直升机在飞行中响应离合器分离等危险指令.采用转速反馈和磁电机间歇接地的控制方法,防止发动机在离合器未接合的情况下超速.在某型无人直升机上分别进行自动接合试验和超速保护试验,在地面模拟进行空中/地面保护试验.结果显示:自动接合试验中发动机最小转速为960r/min;超速保护试验中发动机瞬时最大转速为2016r/min,最小转速为1088r/min,超速持续时间为0.5s;空中/地面保护试验确认了地面状态指令正常执行和空中状态指令注销的功能.试验结果表明:该控制系统设计方案满足无人直升机的使用需求.
- 无人直升机 /
- 带传动离合器 /
- 控制系统 /
- 自动接合 /
- 安全保护
Abstract: In light of belt drive clutch control requirements in unmanned modified process of one helicopter,a control system with security features was researched.By analyzing the belt drive clutch manipulation principles and control characteristics,the design requirements of control system were proposed,and then overall design was determined.Rotating speed feedback and intermittent engagement were adopted to realize clutch automatic engagement and avoid excessive decline of engine rotating speed (ERS).Landing signal was collected and hardware cancellation was adopted to avoid responsing dangerous instructions in flight.Rotating speed feedback and magnetor intermittent grounding were used to prevent engine overspeed.Automatic engagement experiment and overspeed experiment were conducted in an unmanned helicopter,and air/ground protection experiment was conducted through simulation.The results show that the minimum ERS is 960r/min in automatic engagement experiment;the maximum instantaneous ERS is 2016r/min;the minimum ERS is 1088r/min,and the overspeed duration is 0.5s in overspeed experiment;air/ground protection experiment confirms the function of instruction normal execution in ground state and instruction cancellation in air state.These experiments prove that the control system meets the needs of unmanned helicopter.
- unmanned helicopter /
- belt drive clutch /
- control system /
- automatic engagement /
- security

HTML

参考文献(18)

[1]	王海,徐国华.无人驾驶直升机的研究现状和发展趋势[J].直升机技术,2003(2):45-49. WANG Hai,XU Guohua.Research status and development trend of unmanned helicopter[J].Helicopter Technique,2003(2):45-49.(in Chinese)
[2]	彭延辉,徐国华.无人驾驶直升机的技术发展及其关键技术[J].飞行力学,2004,22(1):1-5. PENG Yanhui,XU Guohua.Development and key technologies of VTOL UAVs[J].Flight Dynamics,2004,22(1):1-5.(in Chinese)
[3]	陈健.无人直升机飞行控制技术研究 .南京:南京航空航天大学,2008. CHEN Jian.Research on flight control technology of the unmanned helicopter .Nanjing:Nanjing University of Aeronautics and Astronautics,2008.(in Chinese)
[4]	ZHANG Lei,XU Hongzhe,WU Zhe.Common avionics system design for serial unmanned adaption RUAS //Proceedings of 30th Digital Avionics Systems Conference.Seattle,WA:IEEE,2011:5E1.1-5E1.8.
[5]	Pineda S X.MQ-8B fire scout vertical unmanned aircraft system . .http://www.as.northropgrumman.com/products/mq8bfirescout_navy/assets/fs-fact-sheet.pdf.
[6]	Brunet P.EADS systems & defence electronics at the Le bourget international air show 2003 . .http://www.eads.com/eads/int/en/news/press. 21014e83-bdd6-4270-9a81-8ff6f4fa52b0.08af92a7-2c53-400a-8429-8b135733cbcc.html?queryStr=ORKA-1200&pid=1.
[7]	Israel Aeronautics Defense Systems Corporation. Picador VTOL UAV . .http://www.aeronautics-sys.com/_Uploads/dbsAttachedFiles/Picador.pdf.
[8]	机械设计手册编委会.机械设计手册[M].3版.北京:机械工业出版社,2004.
[9]	Zhu F,Parker R G.Piece-wise linear dynamic analysis of serpentine belt drives with a one-way clutch[J].Proceedings of the Institution of Mechanical Engineers:Part C Journal of Mechanical Engineering Science,2008,222(7):1165-1176.
[10]	Leamy M J,Wasfy T M.Transient and steady-state dynamic finite element modeling of belt-drives[J].Journal of Dynamic Systems,Measurement and Control,2002,124(4):575-581.
[11]	陈奇,黄士伟,王雪瑶,等.基于ARM与UDP通信协议的带传动试验仪控制系统的研究[J].机械与电子,2010(10):7-10. CHEN Qi,HUANG Shiwei,WANG Xueyao,et al.Research of beltwork experiment system based on the communication protocol of UDP and ARM[J].Mechinery & Electronics,2010(10):7-10 (in Chinese)
[12]	孙良玉.小型无人直升机传动系统的设计与研究[J].南京航空航天大学学报,1994,26(4):551-553. SUN Liangyu.Design and study on transmission system of a mini-pilotless helicopter[J].Journal of Nanjing University of Aeronautics & Astronautics,1994,26(4):551-553.(in Chinese)
[13]	Schweizer Aircraft Crop.Model 269C-1 helicopter basic handbook of maintenance instructions[M].New York:Horseheads Schweizer Aircraft Crop,2006.
[14]	陈建中,张兴波,刘海沙.直升机构造学[M].北京:长城出版社,1996.
[15]	张伟.航空发动机[M].北京:航空工业出版社,2008.
[16]	Schweizer Aircraft Crop.Model 269C-1 helicopter pilot's flight manual[M].New York:Horseheads Schweizer Aircraft Crop,2006.
[17]	Schweizer Aircraft Crop.Model 269C-1 maintenance training manual[M].New York:Horseheads Schweizer Aircraft Crop,2008.
[18]	北京航空航天大学.一种具有安全保护功能的直升机旋翼自动离合控制系统:中国,201010219300.0 .2010-11-10.
