锻造TC4钛合金电子束焊接接头的疲劳破坏机制

齐红宇; 李少林; 杨晓光; 王相平; 苏守丽

锻造TC4钛合金电子束焊接接头的疲劳破坏机制

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司沈阳发动机设计研究所,沈阳 110015

计量
- 文章访问数: 1972
- HTML浏览量: 113
- PDF量: 1409
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-29
- 刊出日期: 2013-02-28

Fatigue fracture mechanics of forged TC4 alloy joints by electron beam welding

1.
School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Shenyang Aeroengine Design and Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 对锻造TC4钛合金电子束焊接(EBW)接头进行了应力控制的高周疲劳试验和应变控制的低周疲劳试验,利用扫描电子显微镜对疲劳断口进行观察与分析,研究了疲劳裂纹的起裂机制.研究结果表明:所有的高周疲劳试样裂纹起裂位置和最后断裂位置均发生在母材区,而低周疲劳试验试样断裂位置表现出不确定性,在焊缝区和母材区均可导致裂纹起裂.高周疲劳载荷下,裂纹起源于表面滑移;低周疲劳时,裂纹可能在接头母材区的表面起裂,也可能在接头焊缝的内部缺陷处起裂,裂纹起裂模式取决于载荷大小.
- TC4钛合金 /
- 电子束焊接(EBW) /
- 疲劳试验 /
- 断口 /
- 疲劳破坏
Abstract: Stress controlled high-cycle fatigue (HCF) test and strain controlled low-cycle fatigue (LCF) test for electron beam welding (EBW) joints of forged TC4 alloy were investigated at room temperature.Fracture surfaces were observed by scanning electron microscope (SEM),and the crack initiation mechanism of fatigue failure was analyzed.The results show that all HCF specimens are fractured in the base material (BM) observed by SEM,while LCF specimens are mainly ruptured at fusion zone (FZ) and BM.Due to low stress level in HCF test,the crack of joints is initiated near the surface,while the crack of the joint in LCF test is initiated not only near the surface but also in the interior defects.The crack initiation mode depends on the load.
- TC4 alloy /
- electron beam welding(EBW) /
- fatigue test /
- fracture surfaces /
- fatigue fracture

HTML

参考文献(18)

[1]	郭恩明.航空先进制造技术发展趋势[J].航空制造技术,2007(增刊1):1-5. GUO Enming.Development trend of advanced aeronautical manufacturing [J].Aeronautical Manufacturing Technology,2007(Sup.1):1-5.(in Chinese)
[2]	樊振中,熊艳才.航空先进制造技术的应用及发展趋势[J].装备制造技术,2011(11):86-91. FAN Zhenzhong,XIONG Yancai.Aviation advanced manufacturing technology application and development trend[J].Equipment Manufacturing Technology,2011(11):86-91.(in Chinese)
[3]	Zhang G Q.Research and development of high temperature structural materials for aero-engine application[J].Acta Metallurgical Sinica,2005,18(4):443-452.
[4]	黄春峰.航空发动机整体叶盘结构及发展趋势[J].现代零部件,2005(4):96-99. HUANG Chunfeng.Structure and development trends of blisk[J].Modern Components,2005(4):96-99.(in Chinese)
[5]	黄春峰.现代航空发动机整体叶盘及其制造技术[J].航空制造技术,2006(4):94-100. HUANG Chunfeng.Modern aeroengine integral blisk and its manufacturing technology[J].Aeronautical Manufacturing Technology,2006(4):94-100.(in Chinese)
[6]	陈光.整体叶盘在国外航空发动机中的应用[J].航空发动机,1999(1):1-6. CHEN Guang.Application of blisk in foreign aircraft engine[J].Aeroengine,1999(1):1-6.(in Chinese)
[7]	刘家富.整体叶盘结构及制造工艺[J].航空科学技术,1998(6):21-23. LIU Jiafu.Blisk structure and its manufacture technology[J].Aeronautical Science and Technology,1998(6):21-23.(in Chinese)
[8]	莱茵斯 C,皮特尔斯 M.钛与钛合金[M].陈振华,译.北京:化学工业出版社,2005.
[9]	Ahmed N.New developments in advanced welding[M].Cambridge:Woodhead Publishing,2005.
[10]	徐建新,明平伟,王旭东.钛合金焊接件疲劳寿命估算[J].中国民航学院学报,2006,24(5):30-33. XU Jianxin,MING Pingwei,WANG Xudong.Fatigue life evaluation of titanium alloy welding specimens[J].Journal of Civil Aviation University of China,2006,24(5):30-33.(in Chinese)
[11]	Bllinghaus T,Herold H.Hot cracking phenomena in welds[M]. Berlin Heidelberg:Springer,2005.
[12]	Saresh N,Pillai M G,Mathew J.Investigations into the effects of electron beam welding on thick Ti-6Al-4V titanium alloy[J].Journal of Materials Processing Technology,2007,192/193:83-88.
[13]	Oh J,Kim N J,Lee S,et al.Correlation of fatigue properties and microstructure in investment cast Ti-6Al-4V welds[J].Materials Science and Engineering:A,2003,340(1/2):232-242.
[14]	Liu J Z,Chen B,Wang L F.Effect of weld defect on fatigue life for electron-beam welded titanium alloy[C]//Proceedings of FM2008-Evaluation,Inspection and Monitoring of Structural Integrity.Shanghai:East China University of Science and Technology Press,2008:251-256.
[15]	Krupp U.Fatigue crack propagation in metals and alloys:microstructural aspects and modelling concepts[M].New York:Wiley-VCH,2007.
[16]	葛敬鲁.钛合金电子束焊接接头的性能研究[R].沈阳:沈阳大学,2011. GE Jinglu.Performance of eletron-beam welded TC11 jionts[R].Shenyang:Shenyang University,2011.(in Chinese)
[17]	钟群鹏,赵子华.断口学[M].北京:高等教育出版社,2006.
[18]	陶春虎,刘庆瑔,曹春晓,等.航空用钛合金的失效及其预防[M].北京:国防工业出版社,2002:1-33.
