橡胶隔振器黏弹性5参数分数导数并联动力学模型
Parallel dynamic model of rubber isolator about five-parameter fractional derivatives
-
摘要: 以辅助动力装置(APU)橡胶隔振器为研究对象,建立了橡胶隔振器非线性分数导数动力学模型.提出了橡胶隔振器5参数分数导数频率相关性和振幅相关性并联模型.该模型能够使用较少的参数描述APU橡胶隔振器在宽广频率范围内的黏弹性特性.还分析研究了各参数对APU橡胶隔振器储存模量和损失模量的影响,利用数值求解的方法给出定量结果.研究结果表明并联模型能更好地描述APU橡胶隔振器宽广频率范围内的动态特性.为橡胶隔振器设计应用提供了理论基础.Abstract: The dynamic model of nonlinear fractional derivatives was established for the research of an auxiliary power unit(APU) rubber isolator.The parallel model of five-parameter fractional derivative was presented,which concerned frequency and amplitude dependencies.The model can simulate viscoelastic properties in a wide range with few parameters.At the same time,the influence of every parameter on dynamic modulus and loss modulus as well as the methods of numerical solution were studied.The result shows that the model can be used to predict the dynamic properties in a wide range.It provided basis for design and application of rubber isolator.
-
[1] Pritz T.Analysis of four-parameter fractional derivative model of real solid materials[J].Journal of Sound and Vibration,1996,195(1):103-115. [2] Schmidt A,Gaul L.Finite element formulation of viscoelastic constitutive equations using fractional time derivatives[J].Nonlinear Dynamics,2002,29(1/2/3/4):37-55. [3] Kim S Y,Lee D H.Identification of fractional-derivative-model parameters of viscoelastic materials from measured FRFs[J].Journal of Sound and Vibration,2009,324(3/4/5):570-586. [4] Fukunaga M,Shimizu N,Nasuno H.A nonlinear fractional derivative model of impulse motion for viscoelastic materials[J].Physica Scripta,2009,136:014010.1-014010.6. [5] Yajima T,Nagahama H.Differential geometry of viscoelastic models with fractional-order derivatives[J].Journal of Physics A:Mathematical and Theoretical,2010,43(38):385207.1-385207.9. [6] Rossikhin Y A,Shitikova M V.Analysis of damped vibrations of linear viscoelastic plates with damping modeled with fractional derivatives[J].Signal Processing,2006,86(10):2703-2711. [7] Heymans N.Fractional calculus description of non-linear viscoelastic behaviour of polymers[J].Nonlinear Dynamics,2004,38(1/2/3/4):221-231. [8] Sjöberg M,Kari L.Non-linear behavior of a rubber isolator system using fractional derivatives[J].Vehicle System Dynamics,2002,37(3):217-236. [9] Sjöberg M.Nonlinear isolator dynamics at finite deformations:an effective hyperelastic,fractional derivative,generalized friction model[J].Nonlinear Dynamics,2003,33(3):323-336. [10] Negrete N G,Vinolas J,Kari L.A simplified methodology to predict the dynamic stiffness of carbon-black filled rubber isolators using a finite element code[J].Journal of Sound and Vibration,2006,296(4/5):757-776. [11] Negrete N G,Vinolas J,Kari L.A nonlinear rubber material model combining fractional order viscoelasticity and amplitude dependent effects[J].Journal of Applied Mechanics,2009,76(1):011009.1-011009.9. [12] Kari L.On the dynamic stiffness of preloaded vibration isolators in the audible frequency range:modeling and experiments[J].Journal of Acoustical Society of America,2003,113(4):1909-1921. [13] Ortigueira M D.The fractional quantum derivative and its integral representations[J].Communications in Nonlinear Science and Numerical Simulation,2010,15(4):956-962. [14] Singh S J,Chatterjee A.Beyond fractional derivatives:local approximation of other convolution integrals[J].Proceedings of Royal Society A,2010,466(2114):563-581. [15] Méhauté A L,Kaabouchi A E.Riemann's conjecture and a fractional derivative[J].Computers and Mathematics with Applications,2010,59(5):1610-1613. [16] Palfalvi A.Efficient solution of a vibration equation involving fractional derivatives[J].International Journal of Non-linear Mechanics,2010,45(2):169-175.
