一种两侧布局的无隔道亚声速进气道流场特性

夏杨; 李博; 王海朋

一种两侧布局的无隔道亚声速进气道流场特性

1.
中国人民解放军总参谋部第六十研究所,南京 210016
2.
南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1781
- HTML浏览量: 124
- PDF量: 1121
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-04
- 刊出日期: 2013-02-28

Flow field characteristics of side-mounted subsonic inlet of the UAV

1.
The 60th Research Institute of the General Staff Department of the Chinese People's Liberation Army, Nanjing 210016, China
2.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 对一种两侧翼下布局的无人机无隔道亚声速进气道进行了气动设计和数值模拟研究,给出了该进气道的鼓包结构设计思想,得到了设计飞行马赫数下该进气道的工作特性.计算结果表明:在0°～8°范围内,攻角和侧滑角对进气道性能影响不大,在所有计算状态下,该进气道的总压恢复系数大于0.965,畸变指标小于0.253,满足发动机的工作要求.研究发现:无隔道亚声速进气道的鼓包表面存在相对于机身较高的压力分布,鼓包排除附面层的效果与机身形状、唇口、进口位置以及飞行姿态等有关,对两侧布局方案,鼓包头部不宜太尖,曲面机身有利于附面层的排移.
- 亚声速进气道 /
- 无隔道进气道 /
- 鼓包进气道 /
- 无人机 /
- 附面层 /
- 数值模拟
Abstract: A side-mounted diverterless subsonic inlet of the UAV(unmanned aerial vehicle) was designed and the flow field was simulated.The design methodology of the bump was presented and the characteristics of the inlet were obtained.The results show that angle of attack and yaw angle have little effect on the inlet's performance within 0°～8°.The total pressure recovery of the inlet is great than 0.965 and the distortion index is less than 0.253 under all states.The inlet meets the requirements of the engine,proving that the side-mounted diverterless subsonic inlet is feasible.It has also been found that there exists a higher pressure region on the bump surface than that on the fuselage for the diverterless subsonic inlet.The effect of pushing boundary layer aside for the bump is related to the fuselage profile,lip,relative positon of the entrance and flight conditions.The leading curve of the bump should not be too sharp for side-mounted inlet and a curved surface is better than a flat one in pushing the boundary layer away.
- subsonic inlet /
- diverterless inlet /
- bump inlet /
- UAV(unmanned aerial vehicle) /
- boundary layer /
- numerical simulation

HTML

参考文献(25)

[1]	Hehs E.JSF diverterless supersonic inlet[EB/OL].Http://www.codeonemagazine.com/article.html? item_id=58.
[2]	杨应凯,李玉璞.JSF X-35的一绝——无附面层隔道超音速进气道[J].国际航空,2001(8):13-15. YANG Yingkai,LI Yupu.Diverterless supersonic inlet of JSF X-35[J].International Aviation,2001(8):13-15.(in Chinese)
[3]	梁德旺,李博.无隔道进气道反设计及附面层排除机理分析[J].航空学报,2005,26(3):286-289. LIANG Dewang,LI Bo.Reverse design of diverterless inlet and mechanism of diversion of boundary layer[J].Acta Aeronautica et Astronautica Sinica,2005,26(3):286-289.(in Chinese)
[4]	马晓光.Bump进气道喘振特性研究[J].气动研究与实验,2005,22(1):25-29. MA Xiaoguang.Study of buzz characteristics of the bump inlet[J].Aerodynamic Research and Experiment,2005,22(1):25-29.(in Chinese)
[5]	钟易成,余少志,吴晴.凸包(bump)进气道/DSI模型设计及气动特性研究[J].航空动力学报,2005,20(5):740-745. ZHONG Yicheng,YU Shaozhi,WU Qing.Research of bump inlet (DSI) model design and its aerodynamic properties[J].Journal of Aerospace Power,2005,20(5):740-745.(in Chinese)
[6]	尹方,王家启,乔盛德.无附面层隔道超音速进气道设计技术研究[J].飞机工程,2006(1):25-27. YIN Fang,WANG Jiaqi,QIAO Shengde.Study on the design of diverterless supersonic inlet[J].Aircraft Engineering,2006(1):25-27.(in Chinese)
[7]	杨应凯.枭龙飞机Bump进气道设计[J].南京航空航天大学学报,2007,39(4):449-452. YANG Yingkai.Design of bump inlet of Thunder/JF-17 aircraft[J].Journal of Nanjing University of Aeronautics & Astronautics,2007,39(4):449-452.(in Chinese)
[8]	杨应凯.Bump进气道设计与试验研究[J].空气动力学学报,2007,25(3):336-338. YANG Yingkai.The research of bump inlet design and test[J].Acta Aerodynamica Sinica,2007,25(3):336-338.(in Chinese)
[9]	李博,梁德旺.无隔道超声速进气道/前机身一体化计算与试验[J].航空学报,2009,30(9):1597-1604. LI Bo,LIANG Dewang.Numerical simulation and experiment of integral flow field of diverterless supersonic inlet/forebody[J].Acta Aeronautica et Astronautica Sinica,2009,30(9):1597-1604.(in Chinese)
[10]	Masud J,Akram F.Flow field and performance analysis of an integrated diverterless supersonic inlet[R].AIAA 2010-481,2010.
[11]	Masud J,Akram F.Effect of passive bleed system on an integrated diverterless supersonic inlet[R].AIAA 2011-920,2010.
[12]	张宝鑫.“枭龙”04架全状态飞机成功首飞[J].国际航空,2006(6):14-15. ZHANG Baoxin.Thunder-04 made first flight successfully [J].International Aviation,2006(6):14-15.(in Chinese)
[13]	Simon P C,Dennis W B,Huff R G.Performance of external-compression bump inlet at Mach numbers of 1.5 to 2.0[R].NACA RM E56L19,1957.
[14]	Seddon J,Goldsmith E L.Intake aerodynamics[M].London:Collins Professional and Technical Books,1985.
[15]	TAN Huijun,GUO Rongwei.Design and wind tunnel study of a top-mounted diverterless inlet[J].Chinese Journal of Aeronautics,2004,17(2):72-78.
[16]	谭慧俊,郭荣伟.一种背负式无附面层隔道进气道的数值模拟研究与实验验证[J].航空学报,2004,25 (6):540-545. TAN Huijun,GUO Rongwei.Numerical simulation investigation and experimental validation of a top-mounted diverterless inlet and its validation[J].Acta Aeronautica et Astronautica Sinica,2004,25(6):540-545.(in Chinese)
[17]	XIE Wenzhong,GUO Rongwei.A ventral diverterless high offset S-shaped inlet at transonic speeds[J].Chinese Journal of Aeronautics,2008,21(3):207-214.
[18]	谢文忠,郭荣伟.腹下无隔道大偏距S弯进气道流场特性[J].航空学报,2008,29(6):1453-1459. XIE Wenzhong,GUO Rongwei.Flow field of ventral diverterless high offset S shaped inlet at transonic speeds[J].Acta Aeronautica et Astronautica Sinica,2008,29(6):1453-1459.(in Chinese)
[19]	马高建,郭荣伟.无人机两侧式布局的S弯进气道设计与实验[J].南京航空航天大学学报,2008,40(2):146-150. MA Gaojian,GUO Rongwei.Design and experiment of bilateral type S-shaped inlet of UAV[J].Journal of Nanjing University of Aeronautics & Astronautics,2008,40(2):146-150.(in Chinese)
[20]	蒋武根,彭云晖,李博.一种两侧布局的亚声速无人机进气道流场特性[J].航空动力学报,2011,26(11):2549-2555. JIANG Wugen,PENG Yunhui,LI Bo.Flow field characteristics of a side-mounted subsonic inlet of UAV[J].Journal of Aerospace Power,2011,26(11):2549-2555.(in Chinese)
[21]	Seddon J,Goldsmith E L.Intake aerodynamics[M].London:Blackwell Scientific Publications,1985.
[22]	黄国平,梁德旺.一种改进的MUSCL格式[J].南京航空航天大学学报,1997,29(3):277-282. HUANG Guoping,LIANG Dewang.Improvement on MUSCL scheme[J].Journal of Nanjing University of Aeronautics & Astronautics,1997,29(3):277-282.(in Chinese)
[23]	黄国平,梁德旺.块结构的MUSCL算法求解三维进气道流场[J].空气动力学学报,2000,18(2):194-199. HUANG Guoping,LIANG Dewang.The numerical simulation of 3-D flows of a inlet using a multi-block MUSCL algorithm[J].Acta Aerodynamica Sinica,2000,18(2):194-199.(in Chinese)
[24]	梁德旺,黄国平,赵海峰.B/L湍流模型在强压力梯度流场计算中的应用[J][R].南京航空航天大学学报,1999,31(1):37-42. LIANG Dewang,HUANG Guoping,ZHAO Haifeng.Application of B/L turbulence model for calculating flow with strong adverse pressure gradient[J].Journal of Nanjing University of Aeronautics & Astronautics,1999,31(1):37-42.(in Chinese)
[25]	李博,梁德旺.混压式进气道与弹体一体化流场数值模拟[J].推进技术,2002,23(4):307-310. LI Bo,LIANG Dewang.Computation of the integrated flow field around missile and mixed compression intake[J].Journal of Propulsion Technology,2002,23(4):307-310.(in Chinese)
