基于磁流体控制的高超声速进气道黏性效应

何淼生; 杨文将; 郑小梅; 刘宇

基于磁流体控制的高超声速进气道黏性效应

北京航空航天大学宇航学院,北京 100191

基金项目: 中央高校基本科研业务费专项资金(YMF-11-03-Q-071)

计量
- 文章访问数: 1648
- HTML浏览量: 1
- PDF量: 1143
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-19
- 刊出日期: 2013-02-28

Viscosity effect of hypersonic inlet based on magnetohydrodynamic control

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 建立引入电磁源项的二维低磁雷诺数磁流体动力学(MHD)方程组,对高超声速二维前体/进气道黏性流场进行了数值模拟.在给出了进气道高于设计马赫数的非设计工况下黏性流场的基本特征基础上,进一步分析了施加MHD控制对进气道黏性效应的影响.结果表明:施加MHD控制可以有效抑制非设计工况下内进气道表面的附面层分离,改善上壁面的热状况,平衡上、下壁面之间的热负担;黏性作用下,进气道流场及性能参数随磁感强度的变化规律与无黏模型计算结果存在较大差别,对磁流体控制的高超声速进气道研究不可忽略黏性的影响.
- 高超声速 /
- 进气道 /
- 磁流体动力学 /
- 磁流体动力学(MHD)控制 /
- 黏性效应
Abstract: Two-dimensional steady-state flow equations coupled with low Reynolds number MHD(magnetohydrodynamic) effects were solved with MHD equations to study the viscosity effects of a MHD controlled hypersonic forebody/inlet.The numerical results showed some typical characteristics of viscous flowfield at the inlet when flight Mach number was larger than the designed value.Furthermore,the viscosity effect of inlet with MHD interaction was taken into discussion.The result analysis indicates that shock-induced boundary layer separation at the inlet can be restrained,and the maximum temperature near the interface of the inlet can be significantly lowered by implementing MHD control.Additionally,it is particularly true that the flow and performance parameters of MHD controlled inlet profiles versus magnitude force of the magnetic are fairly different when the viscosity is taken into consideration.
- hypersonic /
- inlet /
- megnetohydrodynamics /
- megnetohydrodynamic(MHD) control /
- viscosity effect

HTML

参考文献(16)

[1]	Gurijanov E P,Harsha P T.AJAX:new directions in hypersonic technology[R].AIAA-96-4609,1996.
[2]	Van Wie D M,Risha D J,Suchomel C F.Research issues resulting from an assessment of technologies for future hy- personic aerospace systems[R].AIAA 2004-1357,2004.
[3]	Fraishtadt V L,Kuranov A L,Sheikin E G.Use of MHD systems in hypersonic aircraft[J].Technical Physics,1998,43(11):1309-1313.
[4]	Bityurin V,Klimov A,Leonov S,et al.Assessment of a concept of advanced flow flight control for hypersonic flights in atmosphere[R].AIAA-99-4820,1999.
[5]	Golovachev Y P,Sushikh S Y,Van Wie D M.Numerical simulation of MGD flows in supersonic media[R].AIAA 2000-2666,2000.
[6]	Vatazhin A,Kopchenov V,Gouskov O.Some estimations of possibility to use the MHD control for hypersonic flow deceleration[R].AIAA-99-4972,1999.
[7]	Macheret S O,Shneider M N,Miles R B.External supersonic flow and scramjet inlet control by MHD with electron beam ionization[R].AIAA 2001-0492,2001.
[8]	Miles R B,Macheret S O,Martinelli L,et al.Plasma control of shock waves in aerodynamics and sonic boom mitigation[R].AIAA 2001-3062,2001.
[9]	Macheret S O,Shneider M N,Miles R B.Magnetohydrodynamic control of hypersonic flows and scramjet inlets using electron beam ionization[J].AIAA Journal,2002,40(1):74-81.
[10]	Macheret S O,Shneider M N,Miles R B,et al.Optimum performance of electron beam driven MHD generators for scramjet inlet control[R].AIAA 2003-3763,2003.
[11]	Shneider M N,Macheret S O,Miles R B.Analysis of magnetohydrodynamic control of scramjet inlets[J].AIAA Journal,2004,42(11):2303-2310.
[12]	Bityurin V,Bocharov A,Lineberry J.MHD flow control in hypersonic flight[R].AIAA 2005-3225,2005.
[13]	郑小梅,吕浩宇,徐大军,等.二维超燃冲压发动机磁控进气道的数值模拟[J].推进技术,2010,31(1):12-17. ZHENG Xiaomei,LV Haoyu,XU Dajun,et al.Numerical simulation of a two-dimensional scramjet MHD controlled inlet[J].Journal of Propulsion Technology,2010,31(1):12-17.(in Chinese)
[14]	SU Changbing,LI Yinghong,CHENG Bangqin,et al.MHD flow control of oblique shock waves around ramps in low-temperature supersonic flows[J].Chinese Journal of Aeronautics,2010,23(1):22-32.
[15]	Kuranov A L,Sheikin E G.Magnetohydrodynamic control on hypersonic aircraft under “AJAX” concept[J].Journal of Spacecraft and Rockets,2003,40(2):174-182.
[16]	Kuranov A L,Sheikin E G.MHD control on hypersonic aircraft under “AJAX” concept:possibilities on MHD generator[R].AIAA 2002-0490,2002.
