径流/斜流叶轮全三维反问题方法中的边界条件和级数截断

田晓沛; 单鹏

径流/斜流叶轮全三维反问题方法中的边界条件和级数截断

田晓沛,
单鹏

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 高等学校学科创新引智计划(B08009)

计量
- 文章访问数: 1546
- HTML浏览量: 0
- PDF量: 1343
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-10
- 刊出日期: 2013-02-28

Boundary conditions and Fourier series truncation errors with 3-D inverse method for radial and mixed flow turbomachines

School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 研究了脉动流场不同类型的进出口边界条件,比较了端壁边界条件的不同给法,并用基于定常雷诺平均Navier-Stokes(RANS)的商用计算流体动力学(CFD)软件数值研究了进出口、端壁的边界条件和级数截断误差对气动设计的影响.研究表明:进出口边界条件的影响可忽略不计,端壁边界条件的影响较大.取傅里叶级数约前15项后,截断误差的影响可忽略不计.
- 径流和斜流叶轮 /
- 通流设计方法 /
- 全三维反问题 /
- 流线曲率法 /
- 边界条件 /
- 级数截断误差
Abstract: Different kinds of the inlet and outlet boundary conditions were studied in theory and different specifications of the endwall boundary condition were compared. The impacts of the inlet, outlet, endwall boundary conditions and the series truncation errors on the blade design by a steady Reynolds averaged Navier-Stokes (RANS) solver were studied numerically. The results show that the impacts of the inlet and outlet boundary conditions on the blade design are neglectable, while those of the endwall boundary conditions are relative large. The impacts of the series truncation errors could be neglected if the number of Fourier series terms is more than 15.
- radial and mixed flow turbomachines /
- through-flow method /
- three-dimensional inverse problem /
- streamline curvature approach /
- boundary condition /
- series truncation errors

HTML

参考文献(15)

[1]	Wu C.A general theory of three-dimensional flow in subsonic and supersonic turbomachines of axial-,radial-,and mixed-flow types[R].NACA Technical Note 2604,1952.
[2]	Wu C, Wang Z,Chen H.Three-dimensional rotational flow in transonic turbomachines:Part Ⅰ solution obtained using a number of S₁ stream filaments of revolution and a central S₂ stream filament[J].ASME Journal of Turbomachinery,1992,114(1):38-49.
[3]	Zhao X,Sun C,Wu C.A simple method for solving three-dimensional inverse problems of turbomachine flow and the annular constraint condition[J].ASME Journal of Engineering for Gas Turbines and Power,1985,107(4):293-300.
[4]	Demeulenaere A,Van B R.Three-dimensional inverse method for turbomachinery blading design[J].ASME Journal of Turbomachinery,1998,120(4):247-255.
[5]	Dang T,Damle S,Qiu X.Euler-based inverse method for turbomachine blades:Part Ⅱ three dimensions flows[J].AIAA Journal,2000,38(11):2007-2013.
[6]	Ji M,Dang T,Cave M J.Fully three-dimensional viscous semi-inverse method for subsonic mixed-flow and radial impeller design[R].ASME Paper GT2009-59679,2009.
[7]	Hawthorne W R,Tan C S,Wang C,et al.Theory of blade design for large defections:Part Ⅰ two-dimensional cascades[J].ASME Journal of Engineering for Gas Turbines and Power,1984,106(2):346-353.
[8]	Tan C S,Hawthorne W R,Wang C,et al.Theory of blade design for large defections:Part Ⅱ annular cascades[J].ASME Journal of Engineering for Gas Turbines and Power,1984,106(2):354-365.
[9]	Tian X,Shan P.A compressible three-dimensional inverse design method based on the streamline curvature approach and Clebsch formulation for radial and mixed flow turbomachines[R].ASME Paper Power,2012-54805,2012.
[10]	Borges J E.A three-dimensional inverse method for turbomachinery:Part Ⅰ theory[J].ASME Journal of Turbomachinery,1990,112(3):346-354.
[11]	罗兴琦,陈乃祥,林汝长.混流式转轮内有旋流动的全三元反问题计算[J].力学学报,1995,27(增刊):30-36. LUO Xingqi,CHEN Naixiang,LIN Ruchang.Inverse calculation of a full three dimensional rotational flow for mixed flow runner[J].Acta Mechanica Sinica,1995,27(Sup.):30-36.(in Chinese)
[12]	郑小波.混流式转轮的全三维设计[R].西安:西安理工大学,2000.
[13]	Zangeneh M, Hawthorne W R.A fully compressible three-dimensional inverse design method applicable to radial and mixed flow turbomachines[R].ASME Paper 90-GT-198,1990.
[14]	罗兴琦,陈乃祥,彭国义,等.有旋流动的全三维反问题计算在混流式转轮设计中的应用[J].水利学报,1996(10):27-38. LUO Xingqi,CHEN Naixiang,PENG Guoyi,et al.An optimum design method for hydraulic turbine runner[J].Journal of Hydraulic Engineering,1996(10):27-38.(in Chinese)
[15]	NUMECA International.Fine^TM user manual version 6.2-b [M].Brussels,Belgium:NUMECA International,2004.
