直升机尾传动系统扭转振动建模与特性

朱自冰; 朱如鹏; 鲍和云

直升机尾传动系统扭转振动建模与特性

南京航空航天大学机电学院,南京 210016

基金项目: 江苏省高校优势学科建设工程;中央高校基本科研业务费专项基金(NS2012050)

计量
- 文章访问数: 1536
- HTML浏览量: 5
- PDF量: 1059
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-09
- 刊出日期: 2013-02-28

Torsional vibration characteristics analyzing and modeling for helicopter tail drive system

College of Mechanical and Electrical Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 将直升机传动系统简化为轴段和当量圆盘的串联系统,建立了直升机尾传动系统扭转振动的等效多自由度动力学模型.模型中考虑了啮合齿轮对的综合啮合误差激励和尾减齿轮的啮合刚度.针对系统的扭转动力学方程,求得了系统的扭转振动响应,分析了直升机尾传动系统在轴的不同扭转刚度和齿轮的不同啮合刚度下的扭转振动的特性,结果表明:与尾斜轴相联的当量圆盘的扭转角位移始终比与水平轴相联的当量圆盘的扭转角位移的数值大,即与尾斜轴相联的尾减输出齿轮振动大于输入齿轮;当轴的扭转刚度变化时,水平轴相联的当量圆盘与尾斜轴相联的当量圆盘的扭转角位移变化的趋势相反;啮合刚度对系统扭转角位移的影响比较大,在建模时应当给予重视.
- 直升机 /
- 尾传动系统 /
- 扭转振动 /
- 轴段和圆盘 /
- 多支点传动轴 /
- 数值积分法
Abstract: The helicopter tail drive system was simplified to a series system with shaft section and equivalent disk.A equivalent dynamic analysis model with multiple degrees of freedom,in which the transmission error of meshing gear pair and meshing stiffness of tail-decelerated gear were included,was established for this simplified helicopter tail drive system.According to the torsional dynamics equation of helicopter tail drive system,the torsional vibration response of system was obtained, and the torsional vibration characteristics of the system with different torsional stiffness of the shaft and meshing stiffness of the gear were discussed. The following conclusions may be drawn from the analysis result. The torsional displacement of tail rotor is larger than the torsional displacement of driven gear of tail gearbox, namely the vibration response of output gear of tail gear box is larger than the input gear. The variation tendency is opposite of the torsional angle displacement between the equivalent disk connected to the horizontal shaft and oblique shaft respectively. The meshing stiffness has more influence on the system than the shaft torsional stiffness, it should be taken account into the modeling of helicopter tail drive system.
- helicopter /
- tail drive system /
- torsional vibration /
- shaft segment and disk /
- multi-supporting drive shaft /
- numerical integration method

HTML

参考文献(14)

[1]	许兆棠,朱如鹏.直升机尾传动系扭转振动的分析[J].航空学报,2007,28(2):425-431. XU Zhaotang,ZHU Rupeng.Torsional vibration analysis for a helicopter tail drive system[J].Acta Aeronautica et Astronautica Sinica,2007,28(2):425-431.
[2]	Yue L,Fei Q G,Zhang L M.Improvement accuracy of system identification based on morlet wavelet[J].Transaction of Nanjing University of Aeronautics and Astronautics,2005,22(3):206-211.
[3]	邵忍平,沈允文,刘更,等.直升机旋翼传动系统固有振动特性的研究[J].机械科学与技术,1997,16(3):523-526. SHAO Renping,SHEN Yunwen,LIU Geng,et al.Study on dynamic characteristic of transmission system for helicopter rotary wings[J].Mechanical Science and Technology,1997,16(3):523-526.(in Chinese)
[4]	徐敏.直升机传动系统机械扭振计算与试验联合建模[J].振动、测试与诊断,2004,24(1):41-45. XU Min.Calculation testing joint modeling of helicopter drive system for analysis of torsional vibration[J].Journal of Vibration,Measurement and Diagnosis,2004,24(1):41-45.(in Chinese)
[5]	薛海峰,向锦武,张晓谷.直升机旋翼/动力/传动系统模型及耦合影响[J].北京航空航天大学学报,2004,30(5):438-443. XUE Haifeng,XIANG Jinwu,ZHANG Xiaogu.Coupled helicopter rotor/propulsion/ transmission system torsional vibration analytical model and coupled influence investigation[J].Journal of Beijing University of Aeronautics and Astronautics,2004,30(5):438-443.(in Chinese)
[6]	顾仲权,杨景新.直升机传动系统扭转振动特性分析[J].南京航空航天大学学报,1997,29(6):674-678. GU Zhongquan,YANG Jingxin.Analyses of torsional vibration characteristics for transmission system of helicopter[J].Journal of Nanjing University of Aeronautics and Astronautics,1997,29(6):674-678.(in Chinese)
[7]	Lee C W,Jia H S,Kim C S,et al.Turning of simulated natural frequencies for a flexible shaft-multiple flexible disk system[J].Journal of Sound and Vibration,1997,207(4):435-451.
[8]	艾剑波,邓景辉,方永红.某直升机扭振系统共振问题研究[J].直升机技术,2006,146(2):14-18. AI Jianbo,DENG Jinghui,FANG Yonghong.Solutions study of XX Helicopter rotor,engine,train couples system resonance problem[J].Helicopter Technique,2006,146(2):14-18.(in Chinese)
[9]	鲁金华,何九龄,邱志平,等.某型直升机涵道尾桨的固有频率区间估计[J].直升机技术,2006,146(2):10-13. LU Jinhua,HE Jiuling,QU Zhipeng,et al.Interval estination of natural frequency for culvert tail rotor of some kind of helicopter[J].Helicopter Technique,2006,146(2):10-13.
[10]	苏文斗.封闭盘轴系统扭转振动固有频率的计算[J].热能动力工程,1990,5(5):36-38. SU Wendou.Calculation of natural frequency of torsional vibrations for an enclosed disc shaft system[J].Journal of Engineering for Thermal Energy and Power,1990,5(5):36-38.
[11]	任传波,蒲琪,谭德荣.轴盘系统扭振固有频率的精确计算[J].机械科学与技术,1999,18(4):578-579. REN Chuanbo,PU Qi,TAN Derong.Exact computation for torsional vibration natural frequency of shaft and disks system[J].Mechanical Science and Technology,1999,18(4):578-579.
[12]	LI Q S.Torsional vibration of multi-step non-uniform rods with various concentrated elements[J].Journal of Sound and Vibration,2003,260(4):637-651.
[13]	华东耘,张和豪,徐东.转子齿轮传动系统动力学研究[J].上海工业大学学报,1990,11(2):124-134. HUA Dongyun,ZHANG Hehao,XU Dong.A research on dynamics of rotator-gearing system[J].Journal of Shanghai University of Technology,1990,11(2):124-134.
[14]	Alugongo A A,Munda J L.A wavelet-time frequency analysis on torsional vibration response of a rator with a switching crack and a dominant twisting torque[R].IEEE Report,AFRICON-2007-4401643,2007.
