功率四分支齿轮传动系统的固有特性与动载系数

李楠; 王三民; 杜佳佳

功率四分支齿轮传动系统的固有特性与动载系数

西北工业大学机电学院,西安 710072

基金项目: 国家自然科学基金(51075329)

计量
- 文章访问数: 1468
- HTML浏览量: 1
- PDF量: 1039
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-29
- 刊出日期: 2013-02-28

Natural characteristics and dynamic load coefficient of power four embranchments gear transmission

School of Mechanical Engineering, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 建立了功率四分支齿轮传动系统动力学模型,基于轴单元法建立了单根转子的振动方程,依据齿轮啮合矩阵实现各转子振动方程的耦合,形成了传动系统的动力学方程,依据动力学方程求解了系统的固有频率和固有振型,得出了在给定转速下系统需进行越界阻尼设计以确保稳定工作的结论;然后分析了不同传动误差下齿轮动载系数变化情况.结果表明:传动误差对功率四分支齿轮传动系统的动载系数有比较明显的影响,随着传动误差的增加系统动载系数也增大,特别在高速级齿轮上表现更加显著.该分析方法和结论为四分支齿轮传动系统的动态优化设计奠定了基础.
- 功率四分支 /
- 轴单元法 /
- 啮合误差 /
- 固有特性 /
- 动载系数
Abstract: Dynamic model of power four embranchments gear transmission system has been provided,and vibration equation of a single axis has also been established based on axis-element method. With the gear mashing matrix,coupling between equations of every axis can be achieved,which helped to establish dynamic equation of the whole power transmission system. Solving that equation,natural frequency and natural vibration of system were obtained,and the conclusion that the system needs damping design to make sure it work stably at the normal working speed has been conferred. Meanwhile,difference between dynamic load coefficients of different transmission errors has been analyzed,and results show that transmission error has an obvious effect on dynamic load coefficient of the power four embranchments gear transmission system.With the increase of the transmission error,the dynamic load coefficient is also increasing,especially in high speed stage gears the performance even more significant.The research methods and conclusions lay foundation for dynamic optimization design of power four embranchments gear transmission system.
- power four embranchments /
- axis-element method /
- meshing error /
- natural characteristics /
- dynamic load coefficient

HTML

参考文献(15)

[1]	刘琳辉,张超,况季孙.船舶传动装置双重功率分支机构研究[J].舰船科学技术,2010,32(8):151-153. LIU Linhui,ZHANG Chao,KUANG Jisun.Double power embranchment gear train for marine power transmission[J].Ship Science and Technology,2010,32(8):151-153.(in Chinese)
[2]	常山.船舶大功率齿轮传动装置的技术发展现状与展望[J].舰船科学技术,2010,32(7):17-22. CHANG Shan.Progress and development trends in heavy duty marine propulsion gearing[J].Ship Science and Technology,2010,32(7):17-22.(in Chinese)
[3]	杨振,王三民,范叶森.一种新型功率分流齿轮传动系统动态特性研究[J].机械设计与制造,2007(8):99-101. YANG Zhen,WANG Sanmin,FAN Yesen.Dynamic analysis of a new split-power gear system[J].Machinery Design & Manufacture,2007(8):99-101.(in Chinese)
[4]	李杰,王乐勤.国内基于功率分支技术齿轮箱的发展现状[J].机械传动,2007,31(4):106-110. LI Jie,WANG Leqin.The present status and development of domestic reducer based on the splite power[J].Journal of Mechanical Transmission,2007,31(4):106-110.(in Chinese)
[5]	Krantz T L.A method to analyze and optimize the load sharing of split path transmissions[R].NASA TM-107201, 1996.
[6]	Fussner D R,Singh Y P.Design of input coupled split Power transmissions,arrangements,and their characteristics[J].Journal of Mechanical Design,2004,126(3):542-550.
[7]	欧卫林,王三民,袁茹.齿轮耦合复杂转子系统弯扭耦合振动分析的轴单元法[J].航空动力学报,2005,20(3):434-439. OU Weilin,WANG Sanmin,YUAN Ru.Shaft element method for the analysis of lateral-torsional coupling vibration of a complex gear-rotor system[J].Journal of Aerospace Power,2005,20(3):434-439.(in Chinese)
[8]	Iwatsubo T,Arii S,Kawai R.Coupled lateral-torsional vibration of rotor system train by gears[J].Bulletin of JSME,1984,27(224):271-277.
[9]	张文.转子动力学理论基础[M].北京:科学出版社,1990.
[10]	虞烈,刘恒.轴承-转子系统动力学[M].西安:西安交通大学出版社,2001.
[11]	闻邦椿,顾家柳,夏松波,等.高等转子动力学[M].北京:机械工程出版社,1999.
[12]	李润芳,王建军.齿轮系统系统动力学[M].北京:科学技术出版社,1997.
[13]	CHENG Yuping,Lim T C.Dynamics of hypoid gear transmission with nonlinear time-varying mesh characteristics[J].Journal of Mechanical Design,Transactions of the ASME,2003,125(2):373-382.
[14]	齿轮手册编委会.齿轮手册[M].2版.北京:机械工程出版社,2000.
[15]	Al-Wedyan H M.Dynamic torque and response of geared rotors excited by random static transmission error[J].Journal of Mechanical Engineering Research,2011,3(2):40-47.
