涡喷发动机尾气静电监测及气路故障特征

刘鹏鹏; 左洪福; 付宇; 孙见忠

涡喷发动机尾气静电监测及气路故障特征

南京航空航天大学民航学院,南京 210016

基金项目: 国家自然科学基金与中国民航联合资助基金(60939003);江苏省普通高校研究生科研创新计划(CXLX12_0164)

计量
- 文章访问数: 1759
- HTML浏览量: 3
- PDF量: 1194
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-27
- 刊出日期: 2013-02-28

Exhaust gas electrostatic monitoring and gas path fault feature for turbojet engine

College of Civil Aviation, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 利用涡喷发动机试车台和新研制的小型涡喷发动机完成了一系列静电监测实验,获取了涡喷发动机尾气静电信号特性,并通过分析静电信号特征证实了尾气静电监测技术对发动机气路部件机械故障的监测.研究发现发动机尾气静电信号的细微变化与发动机工况相关,通过分析第102试车阶段的静电信号发现活动率水平出现了与发动机工况同步变化的情况,验证了活动率水平是一种可作为表征尾气中微小颗粒的带电情况的特征参数;在102～108试车阶段中,发动机出现了燃烧室内壁积炭、燃烧室内壁轻微烧蚀和气路润滑油泄漏故障,根据静电信号的统计分析以及大时间尺度的趋势分析,发现活动率水平、正(负)事件率可作为预警参数来反映因这些故障而导致尾气静电整体水平的变化.
- 涡喷发动机 /
- 气路 /
- 尾气 /
- 状态监测 /
- 静电感应 /
- 信号特征 /
- 机械故障
Abstract: Some experimental stages of electrostatic monitoring explorative experiments which used the engine test bed and a certain small turbojet engine were conducted. The characteristics of electrostatic signal of the turbojet engine's exhaust gas were obtained, and the electrostatic monitoring technology's ability of monitoring the engine gas path mechanical faults was verified.Then,the result of the next research shows that electrostatic signal of the turbojet engine's exhaust gas may change a little with the engine conditions.There are some evidences obtained by the analysis of the electrostatic signal in stage 102 showing that the activity level changes with the engine conditions,and the activity level is a characteristic parameter of the charged micronized particles in the turbojet engine's exhaust gas.In the process of engine test from stage 102 to stage 108,there were some faults such as engine combustion chamber carbon deposition fault,mild ablation breakdown and lub oil leaking in gas path.There were some changes in electrostatic whole level of engine's exhaust gas which can be found by analyzing signal statistical and long time domain to make characteristic parameters of the electrostatic signal like active level and positive (negative) event rate as early-warning parameters corresponding with these faults.
- turbojet engine /
- gas path /
- exhaust gas /
- state monitoring /
- electrostatic induction /
- signal characteristics /
- mechanical fault

HTML

参考文献(16)

[1]	Cartwright R A,Fisher C.Marine gas turbine condition monitoring by gas path electrostatic detection techniques[R].ASME Paper 91-GT-376,1991.
[2]	Powrie H E G,McNicholas K.Gas path cognition monitoring during accelerated mission testing of a demonstrator engine[R].AIAA-1997-2904,1997.
[3]	Powrie H E G,Fisher C E.Engine health monitoring:towards total prognostics[C]//IEEE Aerospace Conference Proceedings.Chandlers Ford,UK:IEEE,1999:11-20.
[4]	Fisher C E.Gas path debris monitoring:a 21st century PHM tool[C]//IEEE Aerospace Conference Proceedings.Chandlers Ford,UK:IEEE,2000:441-448.
[5]	Fisher C E,Ford C.Data and information fusion for gas path debris monitoring[C]//Proceedings of IEEE Aerospace Conference.Montana,USA:IEEE,2001:3017-3022.
[6]	Powrie H E G.Electrostatic charge generation associated with machinery component generation[C]//Proceedings of IEEE Aerospace Conference.Montana,USA:IEEE,2002:2927-2934.
[7]	Novis A,Powrie H E G.PHM sensor implementation in the real world:a status report[C]//IEEE Aerospace Conference Proceedings.Montana,USA:IEEE,2006:1-9.
[8]	Powrie H E G,Novis A.Gas path debris monitoring for F-35 joint strike fighter propulsion system PHM[C]//IEEE Aerospace Conference Proceedings.Montana,USA:IEEE,2006.
[9]	Lapini G L,Zippo M,Trionc G.The use of electrostatic charge measurements as an early warning of distress in heavy-duty gas turbines[C]//ASME Turbo Expo Proceedings.New Orleans,USA:ASME,2001.
[10]	Wilcox M,Ransom D.Engine distress detection in gas turbines with electrostatic sensors[C]//Proceedings of ASME Turbo Expo 2010: Power for Land,Sea and Air.Glasgow,UK:ASME,2010.
[11]	文振华,左洪福,李耀华.气路颗粒静电监测技术及实验[J].航空动力学报,2008,23(12):2321-2326. WEN Zhenhua,ZUO Hongfu,LI Yaohua.Gas path debris electrostatic monitoring technology and experiment[J].Journal of Aerospace Power,2008,23(12):2321-2326.(in Chinese)
[12]	李耀华,左洪福,文振华.航空发动机气路颗粒静电监测技术模拟实验[J].航空学报,2009,30(4):604-608. LI Yaohua,ZUO Hongfu,WEN Zhenhua.Simulated experiment of aircraft engine gas path debris monitoring technology[J].Acta Aeronautica et Astronautica Sinica,2009,30(4):604-608.(in Chinese)
[13]	李耀华,左洪福,刘鹏鹏.某型航空涡轮轴发动机尾气静电监测探索性实验[J].航空学报,2010,31(11):2174-2181. LI Yaohua,ZUO Hongfu,LIU Pengpeng.Gas path electrostatic monitoring of turbo-shaft engine:an exploratory experiment[J].Acta Aeronautica et Astronautica Sinica,2010,31(11):2174-2181.(in Chinese)
[14]	孙见忠,左洪福,詹志娟,等.涡轴发动机尾气静电信号影响因素分析[J].航空学报,2012,33(3):412-420. SUN Jianzhong,ZUO Hongfu,ZHAN Zhijuan,et al.Analysis of the influencing factors on the exhaust gas electrostatic monitoring signal of a turbo-shaft engine[J].Acta Aeronautica et Astronautica Sinica,2012,33(3):412-420.(in Chinese)
[15]	Sorokin A,Arnold F.Electrically charged small soot particles in the exhaust of an aircraft gas turbine engine combustor:comparison of model and experiment[J].Atmospheric Environment,2004,38(17):2611-2618.
[16]	Haverkamp H,Wilhelm S,Sorokin A,et al.Positive and negative ion measurements in jet aircraft engine exhaust:concentration,size and implications for aerosol formation[J].Atmospheric Environment,2004,38(18):2879-2884.
