基于临界面法的燕尾榫连接结构微动疲劳寿命预测

徐友良; 崔海涛; 陈伟

基于临界面法的燕尾榫连接结构微动疲劳寿命预测

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1948
- HTML浏览量: 133
- PDF量: 1347
- 被引次数: 0
出版历程
- 收稿日期: 2012-07-09
- 刊出日期: 2013-03-28

Fretting fatigue life prediction based on critical plane approach for dovetail joint

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 以航空发动机叶片/轮盘之间的燕尾榫连接结构为研究对象,分析了燕尾榫连接结构接触应力与应变的变化.根据多轴疲劳临界损伤平面原理,在燕尾榫连接结构的微动疲劳寿命预测研究中引入多轴临界平面法的疲劳损伤参数CCB (Chu-Conle-Bonnen),FS (Fatemi-Socie),MSSR (modified shear stress rang)和SWT (Smith-Watson-Topper).将预测寿命与试验寿命进行对比,结果表明:在预测微动疲劳寿命时,4个参数中寿命预测的最大误差为23%,可较好地预测低周微动疲劳寿命.其中基于临界平面法的SWT参数预测误差最小,为1.23%;4个参数均预测裂纹萌生位置在接触区末端,与试验结果一致.在预测裂纹萌生角度上,FS,MSSR,SWT参数预测结果与试验较一致,CCB参数预测结果与试验结果相差较大.说明基于临界平面法的寿命预测模型具有较好的预测能力.
- 燕尾榫连接 /
- 多轴疲劳 /
- 临界平面法 /
- 微动疲劳 /
- 寿命预测
Abstract: The contact stress and strain of the dovetail joint of aeroengine were analyzed. According to the critical plane approach of multiaxial fatigue theory, the multiaxial fatigue damage parameters: CCB (Chu-Conle-Bonnen), FS (Fatemi-Socie), MSSR (modified shear stress rang), and SWT (Smith-Watson-Topper), were introduced to predict the fretting fatigue life of the dovetail joint. By comparing the predicted fatigue life with the experimental life, the results show that: the maximum prediction error of fretting fatigue life was 23%, helping to predict satisfactorily low-cycle fretting fatigue life. And, the minimum prediction error was 1.23% based on SWT parameter. The predicted crack tip initiated at the end of contact area in agreement with the experiment test. In general, the critical plane approach can be used to predict the fretting fatigue effectively. The models based on FS, MSSR and SWT can predict the fretting fatigue crack position, while the models based on MSSR and SWT can predict the fretting fatigue life more correctly.
- dovetail joint /
- multiaxial fatigue /
- critical plane approach /
- fretting fatigue /
- life prediction

HTML

参考文献(14)

[1]	Conner B P,Nicholas T.Using a dovetail fixture to study fretting fatigue and fretting palliatives[J].Journal of Engineering for Gas Turbines and Power,2006,128(1):133-141.
[2]	古远兴, 温卫东, 崔海涛.高低周载荷作用下燕尾榫结构的微动疲劳寿命预测[J]. 推进技术, 2008, 29(2):240-243. GU Yuanxing,WEN Weidong,CUI Haitao.Fretting fatigue prediction of dovetail fixture under high cycle load and low cycle load[J].Journal of Propulsion Technology,2008,29(2):240-243.(in Chinese)
[3]	Golden P J,Calcaterra J R.A fracture mechanics life prediction methodology applied to dovetail fretting[J].Tribology International,2006,39(10):1172-1180.
[4]	Brown M W,Miller K J.A theory for fatigue failure under multiaxial stress and strain conditions[J].Proceedings of the Institute of Mechanical Engineers,1973,187(5):745-755.
[5]	尚德广,王德俊.多轴疲劳强度[M].北京:科学出版社,2007.
[6]	Socie D F.Critical plane approaches for multiaxial fatigue damage assessment[C]//McDowell D L,Ellis R.Advances in multiaxial fatigue.Philadelphia,PA:ASTM,1993:7-36.
[7]	Fatemi A,Socie D F.A critical plane approach to multiaxial fatigue damage including out-of-phase loading[J].Fatigue and Fracture of Engineering Materials and Structures,1988,11(3):149-165.
[8]	Namjoshi S A,Mall S,Jain V K,et al.Fretting fatigue crack initiation mechanism in Ti-6Al-4V[J].Fatigue and Fracture of Engineering Materials and Structures,2002,25(10):955-964.
[9]	Lykins C D,Mall S, Jain V.A shear stress-based parameter for fretting fatigue crack initiation[J].Fatigue and Fracture of Engineering Materials and Structures,2001,24(3):461-473.
[10]	Sabelkin V,Martinez S A,Mall S,et al.Effects of shot-peening intensity on fretting fatigue crack-initiation behaviour of Ti-6Al-4V[J].Fatigue and Fracture of Engineering Materials and Structures,2005,28(2):321-332.
[11]	Smith K N,Watson P,Topper T H.A stress strain function for the fatigue of metals[J].Journal of Mechanics,1970,15(4):767-778.
[12]	Szolwinski M P,Harish G,Farris T N.Comparison of fretting fatigue crack nucleation experiments to multiaxial fatigue theory life predictions[C]//Proceedings of the ASME Symposium on High Cycle Fatigue,Dallas,US:[s.n.],1997:449-457.
[13]	Farris T N,Murthy H.High-temperature fretting fatigue of single-crystal nickel[R].AFRL-ML-WP-TR-2006-4081,2006.
[14]	汪震.燕尾榫结构微动疲劳寿命可靠性分析研究[D].南京:南京航空航天大学,2008. WANG Zhen.Fretting fatigue life reliability analysis of dove-tail fixture[D].Nanjing:Nanjing University of Aeronautics and Astronautics, 2008.
