某粉末冶金高温合金涡轮盘破裂转速分析

冯引利; 吴长波; 高鹏; 陈伟

某粉末冶金高温合金涡轮盘破裂转速分析

冯引利^1,2,
吴长波^1,2,
高鹏²,
陈伟¹

1.
南京航空航天大学能源与动力学院,南京 210016
2.
中国航空工业集团公司中国燃气涡轮研究院强度技术研究室,成都 610500

计量
- 文章访问数: 1952
- HTML浏览量: 70
- PDF量: 1332
- 被引次数: 0
出版历程
- 收稿日期: 2012-04-08
- 刊出日期: 2013-03-28

Analysis of power metallurgy superalloy turbine disc's burst speed

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
The Strength Research Office, China Gas Turbine Establishment, Aviation Industry Corporation of China, Chengdu 610500, China

摘要

摘要: 介绍了平均应力法、平均径向应力修正法、残余变形法、局部塑性应变法等破裂转速预测方法,并采用这些方法对某粉末冶金高温合金涡轮盘破裂转速进行了分析.通过理论预测与试验结果的对比得知:采用平均径向应力修正法、残余变形法、局部塑性应变法预测的破裂转速与试验结果吻合较好,而采用基于径向应力分布均匀假设的平均应力法推算的破裂转速与试验结果相差较大.
- 破裂转速 /
- 平均应力 /
- 平均径向应力修正 /
- 残余变形 /
- 局部塑性应变法
Abstract: The average stress method,modified average radial stress method,residual deformation method,and local plastic strain method which were used for burst speed forecast were introduced.power metallurgy(P/M) superalloy turbine disc's burst speed was analyzed with these methods.By comparing the forecast results with test results,it can be found that the forecast results agreed well with the test results using the modified average radial stress method,residual deformation method and local plastic strain method.However,the forecast burst speed by the average stress method based on radial stress distributing equably are not in agreement with test results.
- burst speed /
- average stress /
- modified average radial stress /
- residual deformation /
- local plastic strain

HTML

参考文献(15)

[1]	吕文林, 陈俊粤, 田德义.航空涡喷、涡扇发动机结构设计准则(研究报告):第二册轮盘[M].北京:中国航空工业总公司发动机系统工程局,1997.
[2]	陈光.航空发动机结构设计分析[M].北京:北京航空航天大学出版社,2006.
[3]	Standard M.MIL-STD-1783 engine structure integrity program (ENSIP)[M].Washington,USA:United Sates Air Force,1984.
[4]	国防科学技术工业委员会.GJB241A-2010航空涡轮喷气和涡轮风扇发动机通用规范[M].北京:国防科学技术工业委员会,2010.
[5]	吴长波,卿华,冯引利,等.某高压涡轮整体叶盘破裂转速计算方法及试验验证[J].燃气涡轮试验与研究,2006,19(3):33-36. WU Changbo,QING Hua,FENG Yinli,et al.Investigation on the prediction and experiment of high- pressure turbine blisk burst speed[J].Gas Turbine Experiment and Research,2006,19(3):33-36.(in Chinese)
[6]	洪其麟,王屏.计算轮盘破裂转速的大变形解析法[J].航空动力学报,1990,5(4):321-324. HONG Qiling,WANG Ping.A large analytical deformation method for prediction of disk burst speed[J].Journal of Aerospace Power,1990,5(4):321-324.(in Chinese)
[7]	王屏,刘思永.用大变形解析法和小变形解析法计算轮盘破裂转速的比较[J].机械强度,1998,20(2):95-98. WANG Ping,LIU Siyong.A comparison of disk burst speeds calculated by analytical large deformation method and analytical mini-deformation method[J].Journal of Mechanocal Strength,1998,20(2):95-98.(in Chinese)
[8]	郑祺选.轮盘破裂转速试验研究[J],航空动力学报,1990,5(4):318-320. ZHENG Qixuan.An experimental study on disc bursting speed[J].Journal of Aerospace Power,1990,5(4):318-320.(in Chinese)
[9]	孙国维.几种材料和结构的轮盘转子破裂准则的试验应用[J].热能动力工程,1988,3(3):30-35. SUN Guowei.Experimental application of the fracture criteria of disk rotors of different matericals and structures[J].Journal of Engineering for Thermal Energy and Power,1988,3(3):30-35.(in Chinese)
[10]	古爱军,张学仁,王屏,等.轴流式轮盘破裂转速的数值计算方法[J].航空动力学报,2001,16(3):287-290. GU Aijun,ZHANG Xueren,WANG Ping,et al.Numerical method for calculating the burst speed of axial-flow-type discs[J].Journal of Aerospace Power,1990,5(4):318-320.(in Chinese)
[11]	赵俊生,马朝臣,胡辽平.车用涡轮增压器叶轮破裂转速的弹塑性数值分析[J].机械科学与技术,2008,27(1):45-49. ZHAO Junsheng,MA Chaochen,HU Liaoping.Elastoplasticity numerical analysis of the burst speed of vehicular turbocharger impeller[J].Mechanical Science and Technology for Aerospace Engineering,2008,27(1):45-49.(in Chinese)
[12]	万江艳,周柏卓.轮盘模拟件破裂试验及其有限元描述[J].航空发动机,2008,34(2):19-21. WAN Jiangyan,ZHOU Baizhuo.Fracture test of disk simulated specimen and its description of finite element[J].Aeroengine,2008,34(2):19-21.(in Chinese)
[13]	万江艳,周柏卓.轮盘弹塑性盘破裂准则的建立及变厚度轮盘破裂转速预测[J].航空发动机,2011,37(5):4-6. WAN Jiangyan,ZHOU Baizhuo.Elastic-plastic disc burst criteria establishment and variable thickness disk burst rotational speed prediction[J].Aeroengine,2011,37(5):4-6.(in Chinese)
[14]	《航空发动机设计手册》总编委会.航空发动机设计手册:第18册[M].北京:航空工业出版社,2001.
[15]	马健,黄文周.涡轮盘与挡板的无螺栓连接结构[J].燃气涡轮试验与研究,2008,21(2):24-26. MA Jian,HUANG Wenzhou.Non-bolted joint between turbine disk and side plate[J].Gas Turbine Experiment and Research.2008,21(2):24-26.(in Chinese)
