低压工况下10N姿控推力器燃烧室工作过程仿真

毛晓芳; 唐振宇; 蔡国飙

低压工况下10N姿控推力器燃烧室工作过程仿真

北京航空航天大学宇航学院,北京 100191

计量
- 文章访问数: 1816
- HTML浏览量: 93
- PDF量: 1111
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-28
- 刊出日期: 2013-03-28

Simulation on working process of 10N attitude-control thruster combustion chamber at lower-pressure condition

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 描述了发动机燃烧室工作过程仿真模型的主要参数,应用此模型对10N推力器在不同供应管路压强条件下燃烧室的脉冲工作过程进行了仿真.对比分析了长脉冲和短脉冲两种工作模式下管路压强逐渐降低时燃烧室压强、推力等参数的变化规律.通过长脉冲工况的仿真理论推力与实验测量推力反推出管路压强为1.48,1.0,0.6MPa时推力效率分别为94%,91%和90%.短脉冲工况仿真结果表明:管路压强为0.4MPa时推力器已经无法正常点火,应避免推力器工作于此工况.d:\PDF\.pdf
- 低供应管路压强 /
- 推力器 /
- 燃烧室 /
- 工作过程 /
- 数值仿真模型
Abstract: A simulation model for the working process of rocket engine combustion chamber was described. Simulation was implemented by using this model for a 10N thruster working at different lower supply pressures. Comparisons were made to find some characteristics of chamber pressure and thrust of the thruster when it worked in long-pulse and short-pulse modes at regular and lower supply pressures. According to the theoretical thrust obtained by simulation and the experimental thrust in long-pulse mode, it can be concluded that the thrust efficiencies are 94%, 91% and 90%, respectively, while supply pressures equal to 1.48, 1.0, 0.6MPa, separately. Meanwhile, simulation results of short-pulse mode cases show that, when the supply pressure decreases to 0.4MPa, the thruster cannot be ignited in short-pulse mode.
- lower pressure in supply pipe /
- thruster /
- combustion chamber /
- working process /
- numerical simulation model

HTML

参考文献(15)

[1]	Webber W T,Hoffman R J.A mechanistic model for analysis of pulse-mode engine operation[R].AIAA 72-1184,1972.
[2]	Trinks H.Experimental exhaust plume analysis with MBB 10N thruster[R].AIAA 83-1259,1983.
[3]	Trinks H,Hoffman R J.Experimental investigation of bipropellant exhaust plume flowfield,heating,and contamination,and comparison with the CONTAM computer model predictions[R].AIAA 83-1447,1983.
[4]	Hoffman R J,Webber W T,Oeding R G.An analytical model for the prediction of liquid rocket plume contamination effects on sensitive surfaces[R].AIAA 72-1172,1972.
[5]	Preclik D,Estublier D.An Eulerian-Lagrangian approach to spray combustion modeling for liquid bi-propellant rocket motors[R].AIAA 95-2779,1995.
[6]	Knab O,Preclik D,Estublier D.Flow field prediction within liquid film cooled combustion chambers of storable bi-propellant rocket engines[R].AIAA 98-3370,1998.
[7]	庄逢辰.液体火箭发动机喷雾燃烧的理论、模型及应用[M].长沙:国防科技大学出版社,1995.
[8]	庄逢辰.计算机数值模拟与仿真在液体火箭发动机喷雾燃烧设计中的应用[J].指挥技术学院学报,2000,11(1):1-7. ZHUANG Fengchen.The applicatio of computer numerical modeling and simulation technology in liquid rocket engine spray combustion design[J].Journal of Institute of Command and Technology,2000,11(1):1-7.(in Chinese)
[9]	刘娟,潘余,刘卫东,等.超燃冲压发动机双凹腔燃烧室氢气燃烧流场分析[J].航空动力学报,2009,24(11): 2501-2505. LIU Juan,PAN Yu,LIU Weidong,et al.Analysis of the hydrogen combustion field in scramjet dual-cavity combustor[J].Journal of Aerospace Power,2009,24(11): 2501-2505.(in Chinese)
[10]	苏龙斐,张黎辉,潘海林.卫星推进系统发动机启动过程数值仿真[J].航空动力学报,2005,20(4):698-701. SU Longfei,ZHANG Lihui,PAN Hailin.Numerical simulation on the starting process of satellite propulsion system[J].Journal of Aerospace Power,2005,20(4):698-701.(in Chinese)
[11]	李丹琳,田原,孙纪国.隔板对燃烧室声学特性的影响[J].航空动力学报,2012,27(3): 715-720. LI Danlin,TIAN Yuan,SUN Jiguo.Effects of baffle on combustion acoustic characteristics of liquid rocket engine[J].Journal of Aerospace Power,2012,27(3): 715-720.(in Chinese)
[12]	Webber W T.Calculation of low-frequency [JP+1]unsteady behavior of liquid rockets from droplet combustion parameters[J].Journal of Spacecraft and Rockets,1972,9:231-237.
[13]	Agosta V D,Seamans T F,Vanpee M.Development of a fundamental model of hypergolic ignition in space-ambient engines[J].AIAA Jounal,1967,5:1616-1624.
[14]	唐振宇,侯凤龙,蔡国飙.双组元姿控发动机燃烧室瞬态工作过程仿真模型[J].推进技术,2012,33(4):193-197. TANG Zhenyu,HOU Fenglong,CAI Guobiao.A model for simulating the transient process for combustion chamber of bipropellant attitude-control engine[J].2012,33(4):193-197.(in Chinese)
[15]	李宜敏,张中钦,张远君.固体火箭发动机原理[M].北京:北京航空航天大学出版社,1999.
