内加热式N2O单组元推力器预热过程仿真与试验

吴靖,  孙威,  蔡国飙

downloadPDF
文章导航 > 航空动力学报  > 2013 >  28(3): 556-560
吴靖, 孙威, 蔡国飙. 内加热式N2O单组元推力器预热过程仿真与试验[J]. 航空动力学报, 2013, 28(3): 556-560.
引用本文: 吴靖, 孙威, 蔡国飙. 内加热式N2O单组元推力器预热过程仿真与试验[J]. 航空动力学报, 2013, 28(3): 556-560.
shu
WU Jing, SUN Wei, CAI Guo-biao. Simulation and experiment for preheating process of N2O monopropellant thruster with inner-heater[J]. Journal of Aerospace Power, 2013, 28(3): 556-560.
Citation: WU Jing, SUN Wei, CAI Guo-biao. Simulation and experiment for preheating process of N2O monopropellant thruster with inner-heater[J]. Journal of Aerospace Power, 2013, 28(3): 556-560.
shu

内加热式N2O单组元推力器预热过程仿真与试验

  • 北京航空航天大学 宇航学院,北京 100191

Simulation and experiment for preheating process of N2O monopropellant thruster with inner-heater

  • School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

    摘要
  • 摘要: 为了提高N2O单组元推力器预热效果,对推力器结构做出改进,引入内加热的预热模式.在模拟真空环境下开展了内加热式推力器预热试验,以10W功率加热5800s,使催化剂温度达到260℃(533K),证明了内加热模式的可行性及优越性.开展了内加热式N2O单组元推力器系统的三维建模,并利用有限元软件对推力器预热过程进行了分析,得到了推力器结构温度场随时间的变化情况.数值分析结果与试验数据吻合良好,验证了所用仿真模型的准确性.进一步对简化结构后的内加热式推力器在模拟太空环境下分别施加10,5,3W加热功率时的预热过程开展了数值仿真研究,结果表明:10W和5W加热功率能使催化剂在3600s内达到工作温度250℃,可为N2O单组元推力器的实际应用提供参考.



    Abstract: In order to promote the preheating effect of N2O monopropellant thruster, the structure of the thruster was improved and inner-heating mode was set up. The preheating experiment of the thruster with inner-heater was conducted in a vacuum chamber, and the catalyst was heated to 260℃(533K) with 10W after 5800s, confirming the feasibility and advantage of the inner-heating mode. 3-D model of the thruster was built and finite element software was utilized to analyze the preheating process. Time-dependent temperature filed of the structure was obtained. Numerical result agrees well with the experimental data, which demonstrates the accuracy of the simulation model. Then a simplified system model of the thruster with inner-heater was designed and 10,5,3W power were utilized to simulate the preheating process in space environment. The result shows that the catalyst will be heated to 250℃ with 10W and 5W power in 3600s, which can provide some references for the practical application of N2O monopropellant thruster.



    • HTML
    • 参考文献(15)
  • [1] Chigier N,Gemci T.A review of micro propulsion technology[R].AIAA-2003-670,2003.
    [2] Reichbach J G,Sedwick R J,Martinez-Sanchez M.Micropropulsion system selection for precision formation flying satellites[R].AIAA-2001-3646,2001.
    [3] 贾永刚,赵勇,汤海滨.微推进技术及研究发展现状[C]//中国宇航学会年固体火箭推进剂第22届年会论文集.成都:中国宇航学会,2005:242-248.
    [4] Zakiov V,Zhang H.A model for the operation of nitrous oxide monopropellant[J].Aerospace Science And Technology,2008,12(4):318-323.
    [5] Tiliakos N,Tyll J S.Development and testing of a nitrous oxide/propane rocket engine[R].AIAA-2001-3258,2001.
    [6] 禹天福,贾月.一氧化二氮催化分解的研究与应用[J].化学推进剂与高分子材料,2006,4(2): 6-10. YU Tianfu,JIA Yue.Research and application on the catalytic decomposition of nitrous oxide[J].Chemical Propellants and Polymeric Materials,2006,4(2):6-10.(in Chinese)
    [7] 孙威,方杰,张佳,等.N2O单组元推力器预热过程有限元分析[J].航空动力学报,2009,24(9):2152-2156. SUN Wei,FANG Jie,ZHANG Jia,et al.Finite element analysis on preheating process of N2O monopropellant thruster[J]. Journal of Aerospace Power,2009,24(9):2152-2156.(in Chinese)
    [8] 霍雪亮,韦迪,李路明.N2O单组元推进器预热过程的建模[J].推进技术,2005,26(1):80-83. HUO Xueliang,WEI Di,LI Luming.Modeling of N2O monopropellant thruster pre-heating[J].Journal of Propulsion Technology,2005,26(1):80-83.(in Chinese)
    [9] 方杰,田辉,蔡国飙.N2O单组元微推进系统及其喷管流场的初步研究[J].推进技术,2005,26(6):495-498. FANG Jie,TIAN Hui,CAI Guobiao.Preliminary study on a N2O micro propulsion system and its nozzle flow field[J].Journal of Propulsion Technology,2005,26(6):495-498.(in Chinese)
    [10] 孙威,方杰,蔡国飙,等.N2O单组元微推力器性能分析及试验[J].北京航空航天大学学报,2008,34(12):1469-1472. SUN Wei,FANG Jie,CAI Guobiao,et al.Performance analysis and experimental research on nitrous oxide monopropellant micro-thruster[J].Jounal of Beijing University of Aeronautics and Astronautics,2008,34(12):1469-1472.(in Chinese)
    [11] 孙威,方杰,郑力铭,等.N2O微推力器性能及喷管热结构分析[J].火箭推进,2008,34(5):5-9. SUN Wei,FANG Jie,ZHENG Liming,et al.N2O micro-thruster performance and the nozzle thermo-structure analysis[J].Journal of Rocket Propulsion,2008,34(5):5-9.(in Chinese)
    [12] 沈军,刘伟强,汤建华.单组元发动机推力室在轨温度数值仿真[J].推进技术,2003,24(3):201-203. SHEN Jun,LIU Weiqiang,TANG Jianhua.Numerical simulation for temperature in a monopropellant thrust chamber on the orbit[J].Journal of Propulsion Technology,2003,24(3):201-203.(in Chinese)
    [13] 韩乐,李茂,方杰,等.N2O单组元微推力器真空试验设计与分析[J].航空动力学报,2011,26(10):2358-2363. HAN Yue,LI Mao,FANG Jie,et al.Vacuum experiment study on a N2O monopropellant micro-thruster[J].Journal of Aerospace Power,2011,26(10):2358-2363.(in Chinese)
    [14] 李茂,韩乐,方杰,等.N2O单组元微推力器高空模拟实验研究[J].推进技术,2011,32(3):307-311. LI Mao,HAN Yue,FANG Jie,et al.Simulated altitude experimental investigation for N2O monopropellant micro-thruster[J].Journal of Propulsion Technology,2011,32(3):307-311.(in Chinese)
    [15] 马庆芳.使用热物理性质手册[M].北京:中国农业机械出版社,1986.
