推进剂管路充填过程的数值模拟

陈宏玉; 刘红军; 刘上

推进剂管路充填过程的数值模拟

中国航天科技集团公司西安航天动力研究所,西安 710100

计量
- 文章访问数: 1939
- HTML浏览量: 399
- PDF量: 1072
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-19
- 刊出日期: 2013-03-28

Numerical simulation of priming process of propellant pipelines

Xi'an Aerospace Propulsion Institute, China Aerospace Science and Technology Corporation, Xi'an 710100, China

摘要

摘要: 基于一维管路瞬变流理论,利用特征线有限差分法,建立了推进剂供应系统管路充填过程的数学模型.利用坐标变换方法,将管路内液体与时间相关的求解区域变换为求解较方便的固定求解区域,很好地处理了模型的移动边界问题.对由贮箱、隔离阀、管道组成的系统充填过程进行了仿真计算,并将计算结果与传统的采用特征线方法获得的结果进行对比分析,验证了方法的有效性.进一步研究了最大压力峰值的影响因素,结果表明:增多初始气体压力、减小贮箱压力、增多多变指数可有效减小最大压力峰值.
- 液体推进剂火箭发动机 /
- 推进剂输送 /
- 特征线方法 /
- 坐标交换 /
- 数值模拟
Abstract: A mathematical model of the priming process of propellant pipelines was presented based on one-dimensional fluid theory using the method of characteristics (MOC) and finite deference.Coordinate transformation technique was employed to change fluid motion in time-dependent domains to ones in time-independent domains.The details of the method were presented with an illustration of the priming process of a simple piping system (system consisted of a tank,a pipe and a isolation valve).The results exhibited greater consistency with conventional method of characteristic calculations.The influence factors to the surge pressure of priming process have been studied future.The results show that the surge pressure can be effectively reduced by increasing the initial gas pressure, decreasing the tank pressure and increasing the polytrophic exponenting.
- liquid propellant rocket engine /
- propellant transfer /
- method of characteristics /
- coordinate transformation /
- numerical simulation

HTML

参考文献(15)

[1]	Yaggy K L.Analysis of propellant flow into evacuated and pressurized lines[R].AIAA 84-1346,1984.
[2]	Beliav E N,Chevanov V K,Chervakov V V.Mathematical modeling of working process in liquid propellant rocket engines[M].Moscow:MAI Publications,2009.
[3]	刘昆,张育林.液体推进系统充填过程的有限元状态变量模型[J].推进技术,2001,22(1):19-21. LIU Kun,ZHANG Yulin.Finite element state-variable models for the priming process of feed lines[J].Journal of Propulsion Technology,2001,22(1):19-21.(in Chinese)
[4]	刘昆,程谋森,张育林.低温推进剂供应管道系统充填过程的动力学模型[J].国防科技大学学报,2003,25(3):1-5. LIU Kun,CHENG Mousen,ZHANG Yulin.Dynamic model of priming processes of cryogenic propellant feed lines[J].Journal of National University of Defense Technology,2003,25(3):1-5.(in Chinese)
[5]	程谋森,刘昆,张育林.低温推进剂供应管路预冷充填瞬变流计算[J].推进技术,2000,21(5):38-41. CHENG Mousen,LIU Kun,ZHANG Yulin.Numerical analysis of pre-cooling and priming transients in cryogenic propellant feed systems[J]. Journal of Propulsion Technology,2000,21(5):38-41.(in Chinese)
[6]	高芳,陈阳,张振鹏.低温液体推进剂充填管路的数值模拟[J].航空动力学报,2007,22(1):108-113. GAO Fang,CHEN Yang,ZHANG Zhenpeng.Numerical simulation of filling pipe of cryogenic liquid propellant[J].Journal of Aerospace Power,2007,22(1):108-113.(in Chinese)
[7]	Lin T Y,Baker D.Analysis and testing of propellant feed system priming process[J].Journal of Propulsion and Power,1995,11(3):505-512.
[8]	程谋森,张育林.推进剂供应管路充填过程研究[J].推进技术,1997,18(2):70-74. CHENG Moushen,ZHANG Yulin.An analysis on prepressurized and evacuated feedline priming process[J].Journal of Propulsion Technology,1997,18(2):70-74.(in Chinese)
[9]	程谋森,张育林.航天器推进系统管路充填过程动态特性(Ⅰ):理论模型与仿真结果[J].推进技术,2000,21(2):25-28. CHENG Moushen,ZHANG Yulin.Dynamic characteristics of priming process in spacecraft propulsion system (Ⅰ):theoretical model and simulation results[J].Journal of Propulsion Technology,2000,21(2):25-28.(in Chinese)
[10]	程谋森,张育林,姜春林,等.航天器推进系统管路充填过程动态特性(Ⅱ):实验模拟与结果评估[J].推进技术,2000,21(3):1-5. CHENG Moushen,ZHANG Yulin,JIANG Chunlin,et al.Dynamic characteristics of priming process in spacecraft propulsion system (Ⅱ):experimental results and reliability analysis[J].Journal of Propulsion Technology,2000,21(3):1-5.(in Chinese)
[11]	薛科,张黎辉,苏龙斐,等.卫星推进系统真空充填过程数值仿真[J].航空动力学报,2007,22(2):323-326. XUE Ke,ZHANG Lihui,SU Longfei,et al.Numerical simulation of the priming process of satellite propulsion system[J].Journal of Aerospace Power,2007,22(2):323-326.(in Chinese)
[12]	Wylie E B,Streeter V L.Fluid transient in systems[M].Endlewood Cliffs,USA:Prentice Hall,1993.
[13]	陈宏玉,刘红军,陈建华,等.基于谱方法的管路充填过程仿真研究[J].航空动力学报.2012,27(9):2134-2139. CHEN Hongyu,LIU Hongjun,CHEN Jianhua,et al.Investigation of priming process of propellant lines using Fourier spectral method[J].Journal of Aerospace Power,2012,27(9):2134-2139.(in Chinese)
[14]	ZHANG Yongliang,Vairavamoorthy K.Transient flow in rapidly filling air-entrapped pipelines with moving boundaries[J].Tsinghua Science and Technology,2006,11(3):313-323.
[15]	ZHANG Yongliang,Vairavamoorthy K.Application of method-of-lines to charging-up process in pipelines with entrapped air[J].Tsinghua Science and Technology,2006,11(3):324-331.
