基于相对流面理论的液体火箭发动机泵内部流动计算

马冬英; 雷宗琪; 梁国柱

基于相对流面理论的液体火箭发动机泵内部流动计算

北京航空航天大学宇航学院, 北京 100191

计量
- 文章访问数: 1734
- HTML浏览量: 237
- PDF量: 1137
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-21
- 刊出日期: 2013-03-28

Calculation of internal flow in pump of liquid rocket engine based on theory of relative stream surface

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 应用相对流面理论对某液体火箭发动机离心泵内叶轮机械部件的内部流动进行计算和分析.流面的求解采用流线曲率法.根据不同部件内的流动数值模拟编制了模块化计算程序,使各部件的计算相对独立.不同部件之间采用混合平面法进行处理,将非定常问题转化为定常问题,简化计算.黏性的影响通过几种损失系数进行修正.数值计算的结果显示诱导轮和离心叶轮增加了液体的压强,而导流通道主要改变了液体的流动方向,这与理论分析一致
- 液体火箭发动机 /
- 离心泵 /
- 相对流面理论 /
- 流线曲率法 /
- 混合平面法
Abstract: The theory of relative stream surface was applied to calculate and analyze the internal flow in a centrifugal pump of a liquid rocket engine.Streamline curvature method was used for calculation.Modularized calculation programs were developed to simulate the flow process in different parts of the pump,which allowed the calculation of every part to be conducted independently.The interaction between different parts was dealt with by the idea of mixing plane to convert the unsteady problem to steady problem.The effect of viscosity was corrected by several loss coefficients.The result shows that the inducer and the centrifugal impellers increase the pressure while the guide vane remains only changes the direction of the velocity, which consist with theoretical analysis.
- liquid rocket engine /
- centrifugal pump /
- relative stream surface theory /
- streamline curvature method /
- mixing plane

HTML

参考文献(15)

[1]	Wu C H.A general theory of three-dimensional flow in subsonic and supersonic turbomachines of axial-,radial-,and mixed-flow types[R].NASA TN2604,1952.
[2]	刘高联,王甲升.叶轮机械气体动力学基础[M].北京:机械工业出版社,1980.
[3]	舒士甄,朱力,柯玄龄,等.叶轮机械原理[M].北京:清华大学出版社,1991.
[4]	Katsanis T.Use of arbitrary quasi-orthogonals for calculating flow distribution in the meridional plane of a trubomachine[R].NACA TND-2546,1964.
[5]	Katsanis T.Use of arbitrary quasi-orthogonals for calculating flow distribution on a blade-to-blade surface in a turbomachine[R].NACA TND-2809,1965.
[6]	Katsanis T.Use of arbitrary quasi-orthogonals for calculating flow distribution in a turbomachine[R].NACA TM X-52094,1965.
[7]	王平洽,黄兰洁.轴流燃气叶轮机械气动设计程序[J].电子计算机动态,1975(8):34-52. WANG Pingqia,HUANG Lanjie.An aerodynamic design program for axial turbomachinery[J].Journal of Computer Research and Development,1975(8):34-52.(in Chinese)
[8]	赵晓路.离心压气机转子内部流场S₁／S₂全三元迭代解[J].工程热物理学报,1994,15(3):257-263. ZHAO Xiaolu.A full-3d S₁/S₂ iterative solution in a centrifugal compressor impeller [J].Journal of Engineering Thermophysics,1994,15(3):257-263.(in Chinese)
[9]	黄虹宾,李惠珍,陆孝宽.利用两类相对流面理论设计内燃机冷却风扇[J].内燃机学报,1996,14(2):205-210. HUANG Hongbin,LI Huizhen,LU Xiaokuan.Designing the cooling fan of internal combustion engine employing the S₁,S₂ relative flow surface theory[J].Transactions of CSICE,1996,14(2):205-210.(in Chinese)
[10]	雷向阳,曹淑珍,刘建平.流线曲率法三元流离心压缩机的设计[J].风机技术,2004(4):15-17. LEI Xiangyang,CAO Shuzhen,LIU Jianping.Design of centrifugal compressor of three-dimensional flow by streamline method of curvature[J].Compressor Blower & Fan Technology,2004(4):15-17.(in Chinese)
[11]	Casey M,Robinson C.A new streamline curvature throughflow method for radial turbomachinery[J].ASME Journal of Turbomachinery,2010,132(3):031021.1-031021.10.
[12]	马冬英,梁国柱.基于S₁,S₂流面理论的液体火箭发动机涡轮内部流场计算[J].推进技术,2008,29(4):401-406. MA Dongying,LIAGN Guozhu.Calculation of the internal now for turbine of liquid rocket engine based on the theory of S₁,S₂ stream surface[J].Journal of Propulsion Technology,2008,29(4):401-406.(in Chinese)
[13]	Giles M B.Nonreflecting boundary condition for Euler equation calculation[J].AIAA Journal,1990,28(12):2050-2058.
[14]	孟庆国,季路成,周盛.关于叶轮机多级流动模拟的模型讨论[J].工程热物理学报,1996,17(增刊):56-59. MENG Qingguo,JI Lucheng,ZHOU Sheng.On the model discussion of multistage turbomachine flow simulation[J].Journal of Engineering Thermophysics,1996,17(Sup.):56-59.(in Chinese)
[15]	袁宁,张振家,王松涛,等.某型两级涡轮变比热容三维定常流场的数值模拟[J].推进技术,1999,20(1):57-61. YUAN Ning,ZHANG Zhenjia,WANG Songtao,et al.Numerical simulation of three dimensional steady flow field with varing specific heat in a two stage turbine[J].Journal of Propulsion Technology,1999,20(1):57-61.(in Chinese)
