超径向可视化技术及其在火箭设计中的应用

孙兴亮; 方杰; 蔡国飙

超径向可视化技术及其在火箭设计中的应用

北京航空航天大学宇航学院,北京 100191

计量
- 文章访问数: 1659
- HTML浏览量: 131
- PDF量: 952
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-30
- 刊出日期: 2013-03-28

Hyper-radial visualization and its application in launch vehicle design

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 针对传统可视化技术处理高维多目标设计优化问题的不足,对超径向可视化技术开展了研究.该技术将超空间Pareto前沿无损地显示于二维空间,有助于设计人员直观了解复杂的Pareto解集空间、并快速获得较好的权衡设计.此外,在超径向可视化过程中,通过采用权重因子和基于偏好区间的颜色标记原则引入设计偏好,可以辅助设计者选择出更加符合特定偏好的设计方案.将超径向可视化技术应用于近地空间火箭的多目标设计优化,验证了该技术处理高维多目标设计优化问题的可行性和高效性.
- 超径向可视化 /
- 偏好引入 /
- 多目标优化 /
- Pareto解集 /
- 固液火箭发动机
Abstract: Considering the deficiency of traditional visualization methods when dealing with high-dimensional multi-objective design optimization, the hyper-radial visualization (HRV) method was studied. HRV provided a lossless visualization way to represent the hyperspace Pareto frontier, enabled designers to realize the complex Pareto set intuitively, and identified a better trade-off design quickly as well. Besides, with the purpose of assisting designers to choose a more specific optimal design solution, the designers' preference was incorporated by the weights and color marks with range-based preferences. A multi-objective optimization design of a sub-orbit launch vehicle was accomplished by HRV, which indicates the HRV method is feasible and efficient for high-dimensional multi-objective design optimization.
- hyper-radial visualization(HRV) /
- preference incorporation /
- multi-objective optimization /
- Pareto set /
- hybrid rocket motor
