齿距啮合偏差对准双曲面齿轮传动误差的影响

邓效忠; 徐爱军; 张静; 李聚波; 杨建军

齿距啮合偏差对准双曲面齿轮传动误差的影响

河南科技大学机电工程学院,河南洛阳 471003

基金项目: 国家自然科学基金(50675061,51205108)

计量
- 文章访问数: 1799
- HTML浏览量: 129
- PDF量: 1691
- 被引次数: 0
出版历程
- 收稿日期: 2012-04-06
- 刊出日期: 2013-03-28

Effect of meshed pitch deviation on transmission error in hypoid gears

School of Mechatronics Engineering, Henan University of Science and Technology, Luoyang Henan 471003, China

摘要

摘要: 由齿轮机构的总体传动误差概念引申出含有齿距啮合偏差的单齿传动误差,并根据齿面的几何关系,给出齿距啮合偏差对单齿传动误差曲线影响的偏移式;然后,在Y9550型滚动检验机的基础上搭建传动误差检测平台并进行测量试验,得到准双曲面齿轮副两种传动误差的测量结果;最后,利用JD45+型齿轮测量机所测的齿距偏差数据对理论传动误差曲线进行修正,进而分析了轮齿的啮合状态.通过对理论与实际传动误差曲线的对比,验证了齿距啮合偏差对传动误差的影响方式.试验结果表明:在轻载条件下,实际单齿传动误差可近似由理论设计曲线和齿距啮合偏差组成的综合仿真曲线来替代,从而为进一步研究实际工况下齿轮传动的运动精度和工作平稳性奠定了基础.
- 齿轮机构 /
- 传动误差 /
- 单齿传动误差 /
- 齿距啮合偏差 /
- 齿轮测量
Abstract: One measurement approach of tooth-tooth transmission error(TE) containing the meshed pitch deviation(MPD) was derived from the concept of the total transmission error in gear driving,and the TE offset formula of the effect of the MPD was proposed with the geometric relationship of the gear surface and the MPD.Then,the TE result of hypoid gears was obtained through the measurment experiments built on the platform of Y9550 type rolling tester.Finally,the TE curve was simulated by the MPD data gained by the JD45+gear measurement center,and the meshing state of gear teeth was analyzed.The effect of MPD on TE was verified by the contrast of the theory and practical TE curve.Experimental results show that the actual tooth-tooth TE curve can be replaced by the theoretical curve which includes the meshed pitch deviation at light loads,so as to lay the foundation for further study of the movement accuracy and stability of the gear transmission under actual working condition.
- gear /
- transmission error /
- tooth-tooth transmission error(TE) /
- meshed pitch deviation(MPD) /
- gear measurement

HTML

参考文献(16)

[1]	邓效忠,方宗德,杨宏斌,等.高重合度弧齿锥齿轮的强度分析[J].航空动力学报,2002,17(3):367-372.DENG Xiaozhong,FANG Zongde,YANG Hongbing,et al.Strength analysis of spiral bevel gears with high contact ratio[J].Journal of Aerospace Power,2002,17(3): 367-372.(in Chinese)
[2]	Smith J D.Gear noise and vibration[M].2nd ed.New York:Marcel Dekker Inc.,2003.
[3]	邓效忠,方宗德,魏冰阳,等.高重合度弧齿锥齿轮加工参数设计与重合度测定[J].机械工程学报,2004,40(6):95-99.DENG Xiaozhong,FANG Zongde,WEI Bingyang,et al.Design and experiment of spiral bevel gears with high contact ratio [J].Chinese Journal of Mechanical Engineering,2004,40(6):95-99.(in Chinese)
[4]	杨建军,邓效忠,魏冰阳,等.弧齿锥齿轮激励研齿的动态研磨分析与试验[J].航空动力学报,2010,25(12):2839-2845.YANG Jianjun,DENG Xiaozhong,WEI Bingyang,et al.Study and experiments of dynamic mechanism of excited gear lapping of spiral bevel gear[J].Journal of Aerospace Power,2010,25(12):2839-2845.(in Chinese)
[5]	石照耀,张旭.齿轮单面啮合测量技术的发展及其应用[J].工具技术,2008,42(3):10-15.SHI Zhaoyao,ZHANG Xu.Development and application of gear single-flank testing technology[J].Tool Engineering,2008,42(3):10-15.(in Chinese)
[6]	徐爱军,邓效忠,徐恺,等.基于时钟细分法的弧齿锥齿轮传动误差测量研究[J].机械传动,2012(8):1-5.XU Aijun,DENG Xiaozhong,XU Kai,et al.The research of the transmission error measurement of spiral bevel and hypoid gears based on the clock subdivision[J].Journal of Mechanical Transmission,2012(8):1-5.(in Chinese)
[7]	Litvin F L.Gear geometry and applied theory[M].Englewood Cliffs,NJ:Prentice Hall,1994.
[8]	Michael F P.Troubleshooting gear noise[J].Gear Solutions,2011(1):39-44.
[9]	AGMA.ANSI/AGMA 2009-B01 Bevel gear classification tolerances,and measuring methods[S].Alexanria,Virginia,USA:AGMA,2001.
[10]	邓效忠,方宗德,任东锋,等.弧齿锥齿轮的齿距误差对传动性能的影响研究[J].航空动力学报,2002,17(2):268-271.DENG XiaoZhong,FANG Zongde,REN Dongfeng,et al.Study on contact ratio of spiral bevel gears and influence of pitch error[J].Journal of Aerospace Power,2002,17(2): 268-271.(in Chinese)
[11]	周彦伟,邓效忠,方宗德,等.齿距误差对弧齿锥齿轮齿间载荷分配和强度的影响[J].中国机械工程,2002,13(7):1518-1520.ZHOU Yanwei,DENG Xiaozhong,FANG Zongde,et al.Influence of pitch error on load share between teeth and bending strength of spiral bevel gears[J].China Mechanical Engineering,2002,13(7):1518-1520.(in Chinese)
[12]	XU Aijun,DENG Xiaozhong,ZHANG Jing,et al.Design of multichannel card oriented to hypoid gear measurement [J].CSSS US:IEEE Computer Society,2011(4):3164-3167.
[13]	XU Aijun,DENG Xiaozhong,ZHANG Jing,et al.A new numerical algorithm for transmission error measurement at gears meshing [R].Germany: Trans Tech Publications,2012.
[14]	Gosselin C,Guertin T,Bremond D,et al.Simulation and experimental measurement of the transmission error of real hypoid gears under load[J].Journal of Mechanical Design,2000,3(122):109-122.
[15]	李天兴,邓效忠,李聚波,等.螺旋锥齿轮齿面误差分析与自动反馈修正[J].航空动力学报,2011,26(5):1194-1200.LI Tianxing,DENG Xiaozhong,LI Jubo,et al.Automatic feedback correction and deviation analysis for tooth surface of spiral bevel and hypoid gear[J].Journal of Aerospace Power,2011,26(5):1194-1200.(in Chinese)
[16]	唐进元,卢延峰,周超.调整参数误差对齿面接触质量的影响[J].航空动力学报,2008,23(9):1718-1723.TANG Jinyuan,LU Yanfeng,ZHOU Chao.Effect of machine tool adjustment parameter errors on spiral bevel gears tooth contact quality[J].Journal of Aerospace Power,2008,23(9):1718-1723.(in Chinese)
