镍基高温合金GH4169磨削参数对表面完整性影响

黄新春; 张定华; 姚倡锋; 任敬心

镍基高温合金GH4169磨削参数对表面完整性影响

西北工业大学机电学院现代设计与集成制造技术教育部重点实验室,西安 710072

基金项目: 国家自然科学基金(50975237,51005184)

计量
- 文章访问数: 2080
- HTML浏览量: 170
- PDF量: 1058
- 被引次数: 0
出版历程
- 收稿日期: 2012-04-05
- 刊出日期: 2013-03-28

Effects of grinding parameters on surface integrity of GH4169 nickel-based superalloy

Ministry of Education Key Laboratory of Contemporary Design and Integrated Manufacturing Technology, School of Mechatronics, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 研究了用单晶刚玉砂轮磨削镍基高温合金GH4169时,磨削参数对表面完整性中的表面特征(表面粗糙度、表面形貌、表面显微硬度和表面残余应力)的影响,以期优化磨削参数.砂轮速度依次选择15,20,25m/s,磨削深度分别选择50,100,150μm,工件速度分别选择5,10,15m/min.研究结果表明:表面粗糙度对工件速度的变化最敏感,表面显微硬度对砂轮速度变化最敏感,表面残余应力对砂轮速度变化最敏感;同时表明了磨削参数对磨削表面形貌、显微硬度梯度、微观组织、残余应力梯度的影响,揭示了表面完整性中的变质层形成规律.其塑性变形层在5～10μm,显微硬度变化影响层为80～100μm,残余应力影响层厚度为80～200μm,其为磨削镍基高温合金表面完整性控制研究提供相关的实验数据基础.
- GH4169高温合金 /
- 表面完整性 /
- 表面粗糙度 /
- 表面形貌 /
- 显微硬度 /
- 残余应力
Abstract: The influence rules of grinding parameters on the surface topographic characters, including surface roughness, surface topography, surface microhardness and surface residual stresses of the surface integrity, were studied to optimize the grinding parameters when grinding the GH4169 nickel-based superalloy by using single crystal corundum grinding wheel. The wheel speed was selected as 15, 20, 25m/s, the grinding depth selected as 50, 100, 150μm, and the workpiece speed selected as 5, 10, 15m/min. The results show that, the surface roughness is most sensitive to the workpiece speed, the surface microhardness and the surface residual stresses are most sensitive to the wheel speed. And the influence rules of grinding parameters on the surface morphology, the gradient of microhardness, microstructure and the gradient of residual stress were studied, revealing the formation rules of metamorphic layer of the surface integrity. The plastic deformation layer is in range of 5～10μm, the depth of the microhardness change is 80～100μm, the residual stress affected layer thickness is 80～200μm,thus providing relevant experimental data base for research of the surface integrity control in grinding nickel-based superalloy.
- GH4169 superalloy /
- surface integrity /
- surface roughness /
- microstructure /
- surface topography /
- microhardness

HTML

参考文献(15)

[1]	任敬心,康仁科,王西彬.难加工材料磨削技术[M].北京:电子工业出版,2011.
[2]	Paulo D J.Surface integrity in machining[M]. New York:Springer London Dordrecht Heidelberg,2010.
[3]	Kumar S,Choudhury S K.Prediction of wear and surface roughness in electro-discharge diamond grinding [J].Journal of Materials Processing Technology,2007,191(1/2/3): 206-209.
[4]	Hecker R L,Liang S Y.Predictive modeling of surface roughness in grinding[J].International Journal of Machine Tools & Manufacture,2003,43(8):755-761.
[5]	Peter J,Snoey R. Residual stress in plunge and cylindrical grinding [J].Int.Conf.on Manufacturing Engineering,1980,80(5):172-177.
[6]	Guo C,Shi Z,Attia H,et al.Power and wheel wear for grinding nickel alloy with plated CBN wheels [J].CIRP Annals-Manufacturing Technology,2007,56(1):343-346.
[7]	何玉怀,于慧臣,郭伟彬,等.直接时效GH4169高温合金疲劳裂纹扩展性能试验[J].航空动力学报,2006,21(2):49-53.HE Yuhuai,YU Huichen,GUO Weibin,et al.Experimental study on fatigue crack growth behavior of direct aging GH4169 superalloy[J].Journal of Aerospace Power,2006,21(2):49-53.(in Chinese)
[8]	Xu X P,Yu Y Q,Xu H J.Effect of grinding temperatures on the surface integrity of a nickel-based superalloy[J]. Journal of Materials Processing Technology,2002,129(1/2/3):359-363.
[9]	周志雄,毛聪,周德旺,等.平面磨削温度及其对表面质量影响的实验研究[J].中国机械工程,2008,19(8):980-984.ZHOU Zhixiong,MAO Cong,ZHOU Dewang,et al.Experimental investigation of grinding temperature and its effects on surface quality in surface grinding[J].China Mechanical Engineering,2008,19(8):980-984.(in Chinese)
[10]	康仁科,原京庭,任敬心.陶瓷结合剂CBN 砂轮磨削难加工材料时磨削液的作用[J].西北工业大学学报,2000,18(4):527-530.(in Chinese) KANG Renke,YUAN Jingting,REN Jingxin. Effect of grinding fluid on grinding properties of vitrified bonded CBN wheel[J].Journal of Northwestern Polytechnical University,2000,18(4):527-530.(in Chinese)
[11]	任敬心,孟庆国,陈景蕙.GH33A高温合金的磨削温度与残余应力[J].航空工艺技术,1995,1(1):3-7.REN Jingxin,MENG Qingguo,CHEN Jinghui.Grinding temperature and residual stress of grinding superalloy GH33A[J].Aeronautical Manufacturing Technology,1995,1(1):3-7.(in Chinese)
[12]	任敬心,杨茂奎,李雅清,等.镍基高温合金的磨削特征[J].航空学报,1999 ,18(6):755-758.REN Jingxin,YANG Maokui,LI Yaqing,et al.Grinding characteristic of nickel besed superalloy[J].Acta Aeronautica et Astronautica Sinica,1999,18(6):755-758.(in Chinese)
[13]	杨茂奎,李雅卿,史兴宽,等.陶瓷结合剂CBN 砂轮磨削GH4169高温合金的磨削加工性与磨削表面完整性[J].工具技术,1996,30(11):6-10.YANG Maokui,LI Yaqing,SHI Xingkuan,et al.The grindability and grinding surface integrity of nickel-based superalloy GH4169 using CBN wheel[J].Tool Engineering 1996,30(11):6-10.(in Chinese)
[14]	黄新春,张定华,杨振朝,等.GH4169磨削表面粗糙度影响参数的敏感性研究[J].航空制造技术,2012,1(8):83-86.HUANG Xinchun,ZHANG Dinghua,YANG Zhenchao,et al.Study of sensitivity of parameter affecting surface roughness in grinding superalloy GH4169[J].Aeronautical Manufacturing Technology,2012,1(8):83-86.(in Chinese)
[15]	美国可切削性数据中心.机械加工切削数据手册[M].北京:机械工业出版社,1989.
