轴承腔油气两相流数值模拟的试验验证

汪友勇; 王锁芳; 艾俊峰; 李斌

轴承腔油气两相流数值模拟的试验验证

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1982
- HTML浏览量: 326
- PDF量: 973
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-28
- 刊出日期: 2013-03-28

Experimental verification of numerical simulation of oil-air two-phase flow in bearing chamber

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为探索一种适于模拟轴承腔油气两相流流动特性的数值计算模型,建立了一套简化结构的轴承腔试验装置,通过试验研究获得了不同工况对轴承腔通风口出气比例和回油口滑油温升的影响规律.应用Fluent软件,采用Mixture多相流模型和Eulerian多相流模型分别搭配标准k-ε湍流模型和RNG(renormalization group) k-ε湍流模型对选定试验工况进行数值模拟.对比结果表明:当转速为2200r/min时,使用Mixture多相流模型搭配RNG k-ε湍流模型计算的滑油温升与试验值的相对误差仅为2.72%,体现了该计算模型在高转速时的精确性,并在此基础上获得了油气两相流速度场、压力场和温度场的分布特征.
- 轴承腔 /
- 油气两相流 /
- 数值模拟 /
- 试验验证 /
- 多相流模型 /
- 湍流模型
Abstract: In order to search a reasonable numerical model to simulate the flowing characteristic of the oil-air two-phase flow in a bearing chamber, a simplified test rig was set up. Various rules of air flow proportion at the vent and oil temperature rise at the scavenger under different operating conditions were obtained through this experimental investigation. Based on Mixture multiphase model and Eulerian multiphase model with standard k-ε turbulence model and RNG (renormalization group) k-ε turbulence model respectively, the universal computational fluid dynamics software Fluent was used to simulate the two-phase flow in a bearing chamber under some given operating conditions. The comparison shows that the relative error of oil temperature rise between the test result and the computational result under Mixture multiphase model with RNG k-ε turbulence model is only 2.72 percent when rotate speed is 2200r/min. Therefore, this computational model is accurate at high speed, based on which the distribution characteristics of oil-air two-phase flow velocity field, pressure field and temperature field are acquired.
- bearing chamber /
- oil-air two-phase flow /
- numerical simulation /
- experimental verification /
- multiphase model /
- turbulence model

HTML

参考文献(15)

[1]	林基恕,常春江.航空发动机设计手册(第12册):传动及润滑系统[M].北京:航空工业出版社,2002.
[2]	陈观慈. 航空发动机主轴高速滚动轴承热分析[D]. 哈尔滨:哈尔滨工业大学,2008. CHEN Guanci.Thermal analysis of high-speed rolling bearing used in main shaft of aeroengine[D].Harbin:Harbin Institute of Technology,2008.(in Chinese)
[3]	林基恕, 张振波.21世纪航空发动机动力传输系统的展望[J]. 航空动力学报, 2001,16(2):108-114,118. LIN Jishu,ZHANG Zhenbo.Prospects of aeroengine power transmission system in the 21st century[J].Journal of Aerospace Power,2001,16(2):108-114,118.(in Chinese)
[4]	Gorse P,Busam S,Dullenkopf K.Influence of operating condition and geometry on the oil film thickness in aero-engine bearing chambers[J].Journal of Engineering for Gas Turbines and Power, 2006,128(1):103- 110.
[5]	Williams J.Thin film rimming flow subject to droplet impact at the surface[D].United Kingdom:The University of Nottingham,2008.
[6]	Glahn A,Busam S,Blair M F.Droplet generation by disintegration of oil films at the rim of rotating disk[J].Journal of Engineering for Gas Turbines and Power,2002,124(1):117-124.
[7]	Glahn A,Busam S,Blair M F.Disintegration of oil films emerging from radial holes in a rotating cylinder[J].Journal of Engineering for Gas Turbines and Power,2003,125(4):1011-1020.
[8]	Glahn A,Busam S,Blair M F.Disintegration of oil jets emerging from axial passages at the face of a rotating cylinder[J].Journal of Engineering for Gas Turbines and Power,2003,125(4):1003-1010.
[9]	Farrall M,Simmons K,Hibberd S.A numerical model for oil film flow in an aeroengine bearing chamber and comparison to experimental data[J].Journal of Engineering for Gas Turbines and Power,2006,128(1):111-117.
[10]	Farrall M,Hibberd S,Simmons K.The effect of initial injection conditions on the oil droplet motion in a simplified bearing chamber[J].Journal of Engineering for Gas Turbines and Power,2008,130(1):1-7.
[11]	应伟,冯艳,王锁芳.基于小波和神经网络的流型辨识研究[J].机床与液压,2008,36(10):61-62. YING Wei,FENG Yan,WANG Suofang.Research on discrimination gas-liquid two phase flow patterns based on wavelets and BP neural networks[J].Machine ToolL & Hydraulics,2008,36(10):61-62.(in Chinese)
[12]	李斌,王锁芳,刘勇.轴承腔内油气两相流动与换热的数值模拟[J].重庆理工大学学报:自然科学版,2010,24(11):38-43. LI Bin,WANG Suofang,LIU Yong.Numerical simulation of air-oil two phase flow and heat transfer in a bearing chamber[J].Journal of Chongqing University of Technology:Natural Science,2010,24(11):38-43.(in Chinese)
[13]	李斌,王锁芳,刘勇.轴承腔综合分析平台与两相流数值模拟[C]//中国航空学会第二届航空发动机数值仿真与数字化设计学术交流会论文集.北京:中国航空学会动力专业分会,2011:130-135.
[14]	江帆,黄鹏.Fluent高级应用与实例分析[M].北京:清华大学出版社, 2008.
[15]	张凯,王瑞金,王刚.Fluent技术基础与应用实例[M].北京:清华大学出版社,2010.
