柯恩达效应对涡轮叶栅气动性能及流场的影响

冯岩岩; 宋彦萍; 陈焕龙; 陈浮

柯恩达效应对涡轮叶栅气动性能及流场的影响

哈尔滨工业大学能源科学与工程学院,哈尔滨 150001

基金项目: 国家自然科学基金(50876023);高等学校博士学科点专项基金(200802130017)

计量
- 文章访问数: 1666
- HTML浏览量: 85
- PDF量: 963
- 被引次数: 0
出版历程
- 收稿日期: 2012-04-07
- 刊出日期: 2013-03-28

Conanda effect on aerodynamic performance and flow field of turbine cascade

School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 以某实际燃气轮机涡轮进口导向器叶栅为研究对象,在出口为高亚声速及超声速条件下,对具有不同柯恩达表面的环量控制叶栅进行二维数值模拟,通过对比分析叶栅的气动性能和流场细节,探讨了柯恩达效应在涡轮叶栅中的作用机理.结果表明:当叶栅出口马赫数为0.60时,射流对主流有很好的携带作用,损失小于原型叶栅;叶栅出口马赫数增加到0.85时,射流仍有较强的携带主流折转的能力;当叶栅出口为超声速时,在初始阶段小曲率的柯恩达表面上,由于激波的作用,射流向流道中心折转并提前脱离壁面,初始阶段大曲率的柯恩达表面射流附壁较好,但由于叶片吸力面与射流口之间圆角的作用,射流与主流掺混不理想.
- 涡轮叶栅 /
- 柯恩达效应 /
- 数值模拟 /
- 柯恩达表面曲率 /
- 马赫数 /
- 射流参数
Abstract: Based on a real turbine inlet guide vane, the two-dimensional flow field of a turbine cascade was simulated by using the circulation control blade profile with different Coanda surfaces. At the cascade exit being high subsonic and supersonic conditions, the aerodynamic performance and the detailed flow fields of different blade profiles were explored. The mechanism of Coanda effect on turbine cascade was discussed. When Mach number at the cascade exit was 0.60, the jet entrained the mainstream well and the loss reduced. When Mach number at the cascade exit increased to 0.85, the ability of the jet carrying the mainstream was still fine. When the cascade exit was at supersonic flow condition, on the Coanda surface with a small curvature in front, the jet turmed to the center of the flow channel and detached the wall in advance on account of the shock wave. On the Coanda surface with a large curvature in front, the jet adhered to the blade quite well. However, it did not mix with the mainstream for good due to the fillet between the jet exit and the suction surface.
- turbine cascade /
- Coanda effect /
- numerical simulation /
- curvature of Coanda surface /
- Mach number /
- jet parameters

HTML

参考文献(15)

[1]	Wood N J,Nielsen J N.Circulation control airfoils past,present,future[R].AIAA 85-0204,1985.
[2]	Abramson J,Rogers E O.High-speed characteristics of circulation control airfoils[R].AIAA 83-0265,1983.
[3]	Englar R J,Huson G G.Development of advanced circulation control wing high lift airfoils[R].AIAA 83-1847,1983.
[4]	Rogers E O.Development of compressible flow similarity concepts for circulation control airfoils[R].AIAA 87-0153,1987.
[5]	Slomski J F,Gorski J J,Miller R W,et al.Numerical simulation of circulation control airfoils as affected by different turbulence models[R].AIAA-2002-0851,2002.
[6]	Liu Y,Sankar L N.Computational evaluation of controlling flap edge vortex and tip vortex effects with circulation control technique [R].AIAA-2007-0473,2007.
[7]	王春雨,孙茂.多喷口高效能厚翼的研究[J].力学学报,1999,31(5):611-617. WANG Chunyu,SUN Mao.Efficient boundary laner control on thick airfoils using multiple slots blowing at small speeds[J].Acta Mechanica Sinica, 1999,31(5):611-617. (in Chinese)
[8]	王春雨, 孙茂. 多喷口环量控制翼型流动的研究[J]. 空气动力学学报,1999,17(4):378-383. WANG Chunyu,SUN Mao.Aerodynamic properties of circulation control airfoil with multi slot blowing[J].Acta Aerodynamic Sinica, 1999,17(4):378-383.(in Chinese)
[9]	Lord W K,MacMartin D G,Tillman G.Flow control opportunities in gas turbine engines [R].AIAA-2000-2234,2000.
[10]	Hill H E,Ng W F,Vlachos P P,et al.2D CFD studies using different turbulence models of a circulation control inlet guide vane[R].ASME Paper GT-2007-28058, 2007.
[11]	姚玉,张靖周,何飞,等.涡轮叶片吸力面气膜冷却效率的数值研究[J].航空动力学报,2010,25(6):1245-1250. YAO Yu,ZHANG Jingzhou,HE Fei,et al.Numerical investigation on film cooling effectiveness at suction surface of stator blade[J].Journal of Aerospace Power,2010,25(6):1245-1250.(in Chinese)
[12]	李广超,张魏,项松,等.双出口气膜孔冷却效率数值模拟[J].航空动力学报,2010,25(6):1233-1237. LI Guangchao,ZHANG Wei,XIANG Song,et al.Numerical simulation of cooling effectiveness with injection of double-outer hole [J]. Journal of Aerospace Power, 2010,25(6):1233-1237.(in Chinese)
[13]	王掩刚,刘波,姜健,等.涡轮叶片尾缘开缝喷气的数值模拟和试验研究[J].航空动力学报,2006,21(3):474-479. WANG Yangang,LIU Bo,JIANG Jian,et al.Experiment and numerical simulation investigation of turbine blade with trailing edge ejection [J].Journal of Aerospace Power,2006,21(3):474-479.(in Chinese)
[14]	周超,常海萍,崔德平,等.斜劈缝涡轮导向叶片尾缘出流气体流动特性数值分析[J].航空动力学报,2006,21(2):268-274. ZHOU Chao,CHANG Haiping,CUI Deping,et al.Numerical investigation of the cooling flow downstream of a turbine guide vane trailing edge slot[J].Journal of Aerospace Power,2006,21(2):268-274.(in Chinese)
[15]	SONG Yanping,LI Yachao,CHEN Huanlong,et al.Two-dimensional simulation of circulation control turbine cascade[J].Journal of Aerospace Engineering, 2011,225(7):761-767.
