基于容积法的某涡扇发动机动态建模方法

唐世建; 童万军

基于容积法的某涡扇发动机动态建模方法

中国航空工业集团公司中国燃气涡轮研究院,成都 610500

计量
- 文章访问数: 2203
- HTML浏览量: 120
- PDF量: 1100
- 被引次数: 0
出版历程
- 收稿日期: 2012-04-06
- 刊出日期: 2013-03-28

Turbofan engine transient modeling based on inter-component volume method

Gas Turbine Establishment of China, Aviation Industry Corporation of China, Chengdu 610500, China

摘要

摘要: 考虑了容腔的质量和能量的储能效应,提出了基于容积法的涡扇发动机实时数学模型建模方法,建立了容腔压力和温度的微分方程,容腔的压力和温度可以用不迭代的数值法求解.同时,利用C++面向对象编程语言,建立了某涡扇发动机动态模型.用建立的发动机动态模型和商用软件Gasturb 10分别计算了发动机性能,并进行了对比,结果表明:该模型与Gasturb 10的运算结果具有良好的一致性,高压压气机转速、涡轮进口温度及压气机喘振裕度的响应结果最大相对误差小于1%.容积法避免了数值迭代,可以保证模型计算的实时性.
- 容积法 /
- 涡扇发动机 /
- 发动机动态建模 /
- 建模方法 /
- 实时
Abstract: The effect of mass and energy storage in a volume was considered. A modeling approach for real time turbofan engine model was presented by employed inter-component volume (ICV) method. The pressure and temperature differential equations were established. The pressure and temperature were calculated through numerical integral without iterative. A turbofan engine transient model was coded by means of employing the solver equations and C++ programming language. By comparison, the calculation results have quite remarkable consistency with those results calculated by Gasturb 10 which is famous commercial software in aero-engine. The simulation results show that the maximum relative errors of high pressure compressor,turbine inlet temperature and the surge margin of compressor are within 1% and ICV method avoids iterative so the computer's running time is evidently reduced.
- inter-component volume (ICV) method /
- turbofan engine /
- engine transient modeling /
- modeling approach /
- real time

HTML

参考文献(12)

[1]	Walsh P P,Fletcher P.Gas turbine performance[M].2nd ed, Oxford: Blackwell Science,2004.
[2]	童万军,唐世建. 基于流量法的齿轮传动涡扇发动机动态建模[J].航空动力学报,2011,26(6):1377-1383. TONG Wanjun,TANG Shijian.Geared turbofan engine transient modeling research based on CMF method[J].Journal of Aerospace Power,2011,26(6):1377-1383.(in Chinese)
[3]	Munson B R,Young D F,Okiishi T H.Fundamentals of fluid mechanics[M],3rd ed,New York:Wiley,1998.
[4]	Emanuel G.Analytical fluid dynamics[M].Boca Raton:CRC Press,1994.
[5]	White F M.Fluid mechanics[M].5th ed,New York:McGraw-Hill Education ISE Editions,2003.
[6]	Fox R W,McDonald A T,Pritchard P J.Introduction to fluid mechanics[M] 6th ed,Hoboken:Wiley,2004.
[7]	Cambel A B,Jennings B H.Gas dynamics[M],New York:McGraw-Hill,1958.
[8]	Holman J P.Thermodynamics[M].3d ed,New York:McGraw-Hill,1980.
[9]	Society of Automotive Engineers.Gas turbine engine performance station identification and nomenclature[M].Warrendale,PA:Aerospace Recommended Practice,ARP 755A,SAE,1974.
[10]	Society of Automotive Engineers.Gas turbine engine transient performance presentation for digital computer programs[M].Warrendale,PA:Aerospace Recommended Practice,ARP 1257,SAE,1989.
[11]	Lippman S B.Inside the C++ object model[M].[S.l.]:Addison Wesley Longman Inc.,1996.
[12]	Kurzke J.Gasturb10 technical reference[EB/OL].[2008-10-15].http://www.gasturb.de.
