涡轴发动机性能在线监测技术研究及试验验证
Study and test validation of turboshaft engine on-line performance monitoring technology
-
摘要: 研究了基于模型的涡轴发动机性能在线监测技术,开发了涡轴发动机性能在线监测软件,并进行了真实台架试车试验验证.试验结果表明:软件能够自动判断发动机是否已进入准稳态工况,并根据当前的大气条件、燃气涡轮转速、动力涡轮转速,实时计算发动机其它状态量与性能量,如压气机增压比、动力涡轮前温度、轴输出功率、耗油率等.与模型计算结果相比,被试发动机压气机增压比稳态测量值最大偏低2.3%左右,反映了被试发动机与基准发动机之间的性能差异,验证了涡轴发动机地面台架试车性能在线监测技术的有效性.Abstract: A model based on-line turboshaft engine(TSE) performance monitoring technology was studied, while an on-line TSE performance monitoring software was developed and subsequently applied to an actual TSE land rig test. Test results show that the software could automatically distinguish the working state of TSE on rig test. With use of the atmosphere pressure and temperature, gas turbine rotor speed and power turbine rotor speed, the software could calculate the TSE performance parameters such as compressor pressure ratio, power turbine inlet gas total temperature, output shaft power and specific fuel consumption et al. The calculation error of compressor pressure ratio between TSE model and the specific engine in rig test is less than 2.3%, which shows the significant performance difference between testing engine and baseline engine, and the effectiveness of the on-line TSE performance monitoring technology is confirmed.
-
Key words:
- turboshaft engine(TSE) /
- performance monitoring /
- test validation /
- rig test /
- modeling
-
[1] 焦天佑,陆宝富.建设满足大型飞机发动机试验需求的露天试车台区技术论证[J].燃气涡轮试验与研究,2008,21(1):1-9. JIAO Tianyou,LU Baofu.Technical demonstration of constructing open-air test bed for large transport aircraft engines[J].Gas Turbine Experiment and Research,2008,21(1):1-9.(in Chinese) [2] Roemer M J,Kacprzynski G J,Schoeller M.Advanced test cell diagnostics for gas turbine engines [R].Montana:IEEE Aerospace Conference,2001. [3] Bechini G.Performance diagnostics and measurement selection for on-line monitoring of gas turbines [D].Cranfield,England:Cranfield University,2007. [4] Kong C,Koo Y,Kho S,et al.Development of on-line performance diagnostics program of a helicopter turboshaft engine[J].Journal of Aeronautical & Space Sciences,2009,10(2):34-42. [5] Kallappa P A.Gas turbine engine systems and methods involving vibration monitoring:US,2009/0301055 A1 [P].2009-12-10. [6] 张永国,李威,朱焕勤,等.某型涡轴航空发动机磨损状态及趋势预测研究[J].润滑与密封,2008,33(8):66-68. ZHANG Yongguo,LI Wei,ZHU Huanqin,et al.Research on wear status and wear prediction for a type of turbo-shaft aviation engine[J].Lubrication Engineering,2008,33(8):66-68.(in Chinese) [7] Golden D L.An experimental study of water injection into a Rolls-Royce model 250-C20B turboshaft gas turbine [R].OMB 074-0188,2008. [8] 旷桂兰,王道波,单晓明,等.某型航空涡轴发动机整机吞水性能试验[J].航空动力学报,2009,24(11):2415-2420. KUANG Guilan,WANG Daobo,SHAN Xiaoming,et al.Swallowing water capability experiment of one turbine-shaft overall aviation engine[J].Journal of Aerospace Power,2009,24(11):2415-2420.(in Chinese) [9] 旷桂兰,姚峥嵘,王道波,等.某涡轴发动机整机逼喘试验研究[J].航空动力学报,2009,24(3):588-595. KUANG Guilan,YAO Zhengrong,WANG Daobo,et al.Surge experimentation research for a whole turbine-shaft engine[J].Journal of Aerospace Power,2009,24(3):588-595.(in Chinese) [10] 李本威,王卫华.某航空涡轴发动机健康状况监视与分析[J].推进技术,2002,23(2):105-108. LI Benwei,WANG Weihua.Monitoring and analyzing for turbo-shaft engine health[J].Journal of Propulsion Technology,2002,23(2):105-108.(in Chinese) [11] 李本威,胡国才,高国胜,等.涡轴发动机监视参数选择与诊断方法研究[J].航空动力学报,2002,17(2):160-164. LI Benwei,HU Guocai,GAO Guosheng,et al.Study of selecting parameters and fault diagnosis for turboshaft[J].Journal of Aerospace Power,2002,17(2):160-164.(in Chinese) [12] Kong C,Koo Y,Kho S,et al.Study on a GUI type fault diagnostic program for a turboshaft engine using fuzzy and neural networks .ASME Paper GT-2010-22537,2010. [13] Green M D,Duyar A,Litt J S.Model-based fault diagnosis for turboshaft engines [R].NASA TM-1998-208825, 1998. [14] Yedavalli R K,LI Wenfei.Aircraft engine fault detection using dynamic-adaptive threshold approach [R].ASME Paper GT-2007-28180,2007. [15] Li Y G,Nilkitsaranont P.A gas path diagnostic and prognostic approach for gas turbine applications [R].ASME Paper GT-2007-27275,2007. [16] Moller J C,Litt J S,Guo T.Neural network-based sensor validation for turboshaft engines [R].NASA TM-1998-208824,1998. [17] Litt J,Kurtkaya M,Duyar A.Sensor fault detection and diagnosis for a T700 turboshaft engine [R].NASA TM-1995-111814,1995. [18] Li Y G,Singh R.An advanced gas turbine gas path diagnostics system-PYTHIA [R].ISABE-2005-1284,2005. [19] Ghafir M F A,Li Y G,Singh R.Impact of operating and health conditions on areo gas turbine hot section a creep life using a creep factor approach [R].ASME Paper GT-2010-22332,2010.
