涡扇发动机高空台惯性起动的试验

马前容; 郭昕; 吴虎

涡扇发动机高空台惯性起动的试验

马前容^1,2,
郭昕²,
吴虎¹

1.
西北工业大学动力与能源学院, 西安 710072
2.
中国航空工业集团公司中国燃气涡轮研究院航空发动机高空模拟重点实验室, 四川江油 621703

计量
- 文章访问数: 1638
- HTML浏览量: 2
- PDF量: 1439
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-06
- 刊出日期: 2013-04-28

Experiment on spooldown airstart performance of aero-turbofan engine in ATF

1.
School of Power and Energy, Northwest Polytechnical University, Xi'an 710072
2.
Aero-Engine Altitude Simulated Key Laboratory, China Gas Turbine Establishment, Aviation Industry Corporation of China, Jiangyou Sichuan 621703, China

摘要

摘要: 某型大流量涡扇发动机在高空台完成了飞行高度为5,8,10km的惯性起动.高空台试验结果表明:惯性起动过程中模拟的进气和排气压力存在着较明显的波动,偏离真实工况;利用不同的计算方法分析惯性起动数据,得到的飞行表速相差25~70km/h.以试验分析结果为基础,推荐了一种高空台惯性起动试验性能的评估方法,即成功起动以推杆时刻为起点3s内的平均值作为试验模拟飞行状态,起动失败以转速反转为起点到转速再次下降之间的平均值作为试验模拟飞行状态.
- 涡扇发动机 /
- 高空台 /
- 惯性起动 /
- 进排气压力 /
- 评估方法
Abstract: A aero-turbofan engine turbofan with great flow rate completed spooldown airstart tests in altitude test facility(ATF). The simulated altitude was at 5km, 8km and 10km. The results of test in AFT showed that simulated intake total pressure and exhaust pressure had obvious fluctuation during spooldown airstart process. So the engine operating condition of spooldown airstart test in ATF deviated from the real flight condition. Moreover, different airspeeds of 25-70km/h were obtained using a few calculation ways to analyze the test data. A performance evaluation method of spooldown airstart test in ATF was recommended based on the analysis results, namely, the simulation flight condition means the average in three seconds span from the beginning of the airstart sequence for the successful tests, or the average in the time from the rotor speed's return to drop down again for the failure tests. This is important to improve the performance evaluation level of test in ATF.
- aero-turbofan engine turbofan /
- altitude test facility (ATF) /
- spooldown airstart /
- intake total pressure and exhaust pressure /
- evaluation method

HTML

参考文献(15)

[1]	Casey W,Malloy D,Arnold S,et al.A method to compare tubine engine airstart times [R].ASME Paper GT2007-27036,2007.
[2]	张绍基,邴连喜.一项扩大涡扇发动机空中起动包线的有效措施:浅论航空发动机起动机辅助空中起动[J].航空发动机,2009,35(2):1-4. ZHANG Shaoji,BING Lianxi.An effective measure of enlargement airstart envelop for turbofan engine:summary of airstart for aeroengine starter[J].Aeroengine,2009,35(2): 1-4.(in Chinese)
[3]	Davis J B,Pollak R R.Criteria for optimizing starting cycles for high performance fighter engine [R].AIAA-83-1127,1983.
[4]	杜鹤龄.航空发动机高空模拟 [M].北京:国防工业出版社, 2002.
[5]	Patterson G,Cross M.Ground test simulation fidelity of turbine engine airstarts [R].AIAA-93-2173,1993.
[6]	Cho T K,Burcham F W.Preliminary flight evaluation of F100 engine model derivative airstart capability in an F-15 airplane .NASA-TM-86031,1984.
[7]	田金虎,马前容,刘志友,等.某型发动机起动试验点火特性分析[J].燃气涡轮试验与研究,2005,18(4):34-36. TIAN Jinhu,MA Qianrong,LIU Zhiyou,et al.Start ignition characteristic analysis of a turbofan engine test[J].Gas Turbine Experiment and Research,2005,18(4):34-36.(in Chinese)
[8]	马燕荣,马明明.某型发动机空中起动故障分析[J].航空发动机,2010,36(6):28-31. MA Yanrong,MA Mingming.Failure analysis of an aeroengine airstart[J].Aeroengine,2010,36(6):28-31.(in Chinese)
[9]	王兆铭,王福德,左伟,等.某型航空发动机空中起动供油规律的研究[J].航空动力学报,2010,25(5):1163-1168. WANG Zhaoming,WANG Fude,ZUO Wei,et al.Research on fuel supply control law of airstart for an aero-engine[J].Journal of Aerospace Power,2010,25(5):1163-1168.(in Chinese)
[10]	马燕荣,王小峰,马明明,等.某型燃气涡轮起动机空中起动调整试验[J].燃气涡轮试验与研究,2009,22(1):13-15. MA Yanrong,WANG Xiaofeng,MA Mingming,et al.Adjustment test on a gas turbine starter in altitude starting[J].Gas Turbine Experiment and Research,2009,22(1):13-15.(in Chinese)
[11]	朴英.燃气涡轮发动机起动特性分析[J].航空动力学报,2003,18(6):778-782. PIAO Ying.An analysis of the starting characteristics of aeroengine[J].Journal of Aerospace Power,2003,18(6):778-782.(in Chinese)
[12]	周文祥,黄金泉.涡扇发动机高空起动模型研究[J].航空动力学报,2007,22(8):1384-1390. ZHOU Wenxiang,HUANG Jinquan.Research on the startup model of turbofan engine at high altitude[J].Journal of Aerospace Power,2007,22(8):1384-1390.(in Chinese)
[13]	吴虎,冯维林.某型发动机起动过程数值模拟[J].航空动力学报,2007,22(12):2069-2072. WU Hu,FENG Weilin.Numerical simulation of the start-up process of augmented turbofan engines[J].Journal of Aerospace Power,2007,22(12):2069-2072.(in Chinese)
[14]	尉询楷,李应红.航空发动机约简遗传规划起动非线性动态模型[J].航空动力学报,2006,21(4):760-766. WEI Xunkai,LI Yinghong.Aeroengine nonline dynamic starting model based on parsimonious genetic programming[J].Journal of Aerospace Power,2006,21(4):760-766.(in Chinese)
[15]	苏伟生,孙健国,程蓝,等.基于扭矩特性的航空发动机起动系统数学模型[J].航空动力学报,2005,20(3):500-503. SU Weisheng,SUN Jianguo,CHENG Lan,et al.Study on mathematic model of aeroengine starting systems based on moment characteristics[J].Journal of Aerospace Power,2005,20(3):500-503.(in Chinese)
