基于壁面马赫数梯度的高超声速弯曲激波二维进气道数值研究

张林; 张堃元; 王磊; 刘媛

基于壁面马赫数梯度的高超声速弯曲激波二维进气道数值研究

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国家自然科学基金(90916029,91116001)

计量
- 文章访问数: 1623
- HTML浏览量: 3
- PDF量: 1127
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-07
- 刊出日期: 2013-04-28

Computational investigation of hypersonic curved shock two-dimensional inlet with compression surface constant Mach number gradient

College of Energy and Power Engineering, Nanjing University Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 研究了一种壁面马赫数(Ma)呈线性分布规律的曲面压缩面,以此设计了高超声速弯曲激波二维进气道,并与同等条件下常规三楔压缩二维进气道进行了比较.数值研究结果表明:根据给定的壁面 Ma 线性分布规律和压缩面增压比,通过有旋特征线理论来设计压缩面的方法是可行的;与常规三楔压缩相比,此方法能改善压缩面附面层的稳定性,能有效缩短外压缩段的长度,并且其性能参数对来流 Ma 变化影响不敏感,特别是非设计状态下性能优势尤为突出.在接力点 Ma 下其流量系数达到0.783,比常规三楔压缩二维进气道提高13.2%,同时喉道截面总压恢复系数也提高4.5%.
- 超燃冲压发动机进气道 /
- 二维高超声速进气道 /
- Ma 线性分布规律 /
- 弯曲激波 /
- 数值仿真
Abstract: A type of curved compression surface with wall Mach number linear distribution was investigated,and a hypersonic curved shock two-dimensional inlet was designed.The performance was compared with normal three-ramp compression inlet designed under the same conditions.The result shows that:curved compression surface can be designed through rational characteristic linear theory according to the given wall Mach number linear distribution and pressure ratio.Compared with normal three-ramp compression,the new inlet has more stable boundary layer and much shorter external compression surface,but not very sensitive to the change of free stream Mach number.Especially,the inlet has an excellent performance under off-design conditions.The mass flow rate reaches 0.783 at relay point Mach number and is increased by 13.2% compared to normal three-ramp compression two-dimensional inlet, while the total pressure recovery of throat section is also increased by 4.5%.
- scramjet inlet /
- two-dimensional hypersonic inlet /
- Mach number linear distribution /
- curved shock /
- numerical simulation

HTML

参考文献(15)

[1]	Curran E T.Scramjet engines:the first forty years[J].Journal of Propulsion and Power,2001,17(6):1138-1148.
[2]	Connors J F,Woollett R R.Performance characteristics of several types of axially symmetric nose inlets at Mach number 3.85 [R].NACA RM E52I15,1952.
[3]	Sorensen N E,Smeltzer D B.Study of two axisymmetric inlets for Mach 3.5 [R].AIAA-1976-0204,1976.
[4]	Trexler C A.Performance of an inlet for an intergraded scramjet concept[J].Journal of Aircraft,1974,11(9):588-591.
[5]	Mölder S,Szpiro J.Busemman inlet for hypersonic speeds[J].Journal of Spacecraft and Rockets,1966,3(8):1303-1304.
[6]	Smart M K.Design of three-dimensional hypersonic inlets with rectangular to elliptical shape transition [R].AIAA-98-0960,1998.
[7]	金志光,张堃元.二维非常规压缩型面超/高超声速进气道的设计概念[J].推进技术,2004,25(3):226-229. JIN Zhiguang,ZHANG Kunyuan.Concept of a two-dimensional supersonic/hypersonic inlet with a non-conventional compression wall[J].Journal of Propulsion Technology,2004,25(3):226-229.(in Chinese)
[8]	PAN Jin,ZHANG Kunyuan.Experimental and numerical investigation of a curved compression system designed on constant pressure gradient [R].AIAA-2009-5270,2009.
[9]	南向军,张堃元,金志光,等.压升规律可控的高超声速内收缩进气道设计[J].航空动力学报,2011,26(3):518-523. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Investigation on hypersonic inward turning inlets with controlled pressure gradient[J].Journal of Aerospace Power,2011,26(3):518-523.(in Chinese)
[10]	NAN Xiangjun,ZHANG Kunyuan.Numerical and experimental investigation on hypersonic inward turning inlets with basic flowfield using arc tangent curve law of pressure rise [R].AIAA-2011-2270,2011.
[11]	张林,张堃元,王磊,等.新型高超弯曲激波二维进气道初步研究[J].航空动力学报,2011,26(11):2556-2562. ZHANG Lin,ZHANG Kunyuan,WANG Lei,et al.Preliminary study on hypersonic curved shock two-dimensional inlet[J].Journal of Aerospace Power,2011,26(11):2556-2562.(in Chinese)
[12]	向有志,张堃元,王磊,等.壁面压升可控的高超轴对称进气道优化设计[J].航空动力学报,2011,26(10):2193-2199. XIANG Youzhi,ZHANG Kunyuan,WANG Lei,et al.Optimization design of hypersonic axisymmetric inlet with controllable law of wall pressure rise[J].Journal of Aerospace Power,2011,26(10):2193-2199.(in Chinese)
[13]	Anderson B H.Design of supersonic inlets by a computer program incorporating the method of characteristics .NASA TN D-4960,1969.
[14]	金志光,张堃元.高超侧压式进气道M6高焓脉冲风洞实验[J].推进技术,2005,26(4):319-323. JIN Zhiguang,ZHANG Kunyuan.Test of a generic sidewall compression scramjet inlet in the high-enthalpy impulse wind tunnel[J].Journal of Propulsion Technology,2005,26(4):319-323.(in Chinese)
[15]	金志光,张堃元.带前体压缩的前掠侧压式进气道实验及数值研究[J].推进技术,2005,26(6):508-512. JIN Zhiguang,ZHANG Kunyuan.Experimental and numerical investigation of a forward sweep sidewall compression scramjet inlet with forebody compression[J].Journal of Propulsion Technology,2005,26(6):508-512.(in Chinese)
