马赫数分布可控的基准流场灵敏度分析与优化设计
Sensitivity analysis and optimization design of basic flowfield with controllable Mach number distribution
-
摘要: 利用Isight软件对反正切马赫数分布可控的轴对称基准流场设计参数进行灵敏度分析,获得了设计参数对基准流场总体性能的影响规律,其中前缘压缩角和系数 c 的影响最为明显.针对该基准流场,建立了多项式响应面模型并在设计点进行三目标优化,得到了总体性能较优的轴对称基准流场.基于该优化结果设计了圆形进口的高超声速内收缩进气道并在 Ma=4~7进行数值分析,结果表明:进气道在设计点和非设计点均具有较高的压缩效率和良好的流量捕获能力, Ma=6和7时出口截面总压恢复系数分别为0.581和0.513,压比分别为20.01和24.73, Ma=4时流量系数达到0.880,说明该优化方法可行.Abstract: The sensitivity analysis of the design parameters of axisymmetric basic flowfield was performed using the software Isight,and the design parameters' effect on the overall performance was obtained,which shows that the leading edge compression angle and coefficient c affect most.The overall performance of the optimized basic flowfield was improved by optimization of three objectives of the polynomial response surface at design point.The hypersonic inward turning inlet with circular shape intake was designed based on the optimized basic flowfield.The numerical simulation results from when Mach number are 4~7 indicate that the inlet has relatively good mass capture ratio and compression efficiency,total pressure recovery coefficients are 0.581 and 0.513, and pressure ratios are 20.01 and 24.73 when Mach number are 6 and 7 respectively; the flow coefficient is 0.880 at the relay point of Mach number is 4, which verifies the feasibility of the optimization method.
-
[1] Mölder S,Szpiro J.Busemman inlet for hypersonic speeds [J].Journal of Spacecraft and Rockets,1966,3(8):1303-1304. [2] Vijay R,Lewis M,Starkey R.Performance of various truncation strategies employed on hypersonic Busemann inlets [R].AIAA-2009-7249,2009. [3] O’Brien T F.Viscous optimized length constrained axisymmetric geometries for streamline tracing [R].AIAA-2008-2511,2008. [4] Drayna T W,Nompelis I,Candler G V.Hypersonic inward turning inlets:design and optimization [R].AIAA-2006-297,2006. [5] SUN Bo,ZHANG Kunyuan,WANG Chengpeng,et al.Investigation on a streamtraced hypersonic Busemann inlet[J].Journal Aerospace Engineering,2010,224(1):57-63. [6] Gollan R J,Ferlemann P G.Investigation of REST-class hypersonic inlet designs [R].AIAA-2011-2254,2011. [7] YOU Yancheng.An overview of the advantages and concerns of hypersonic inward turning inlets [R].AIAA-2011-2269,2011. [8] Billig F S,Baurle R A,Tam C J,et al.Design and analysis of streamline traced hypersonic inlets .AIAA-1999-4974,1999. [9] Van Wie D,Mölder S.Applications of Busemann inlets design for flight at hypersonic speeds [R].AIAA-1992-1210,1992. [10] Smart M K.Design of Three-dimensional hypersonic inlets with rectangular-to-elliptical shape transition[J].Journal of Propulsion and Power,1999,15(3):408-416. [11] Matthews A J,Jones T V.Design and test of a modular waverider hypersonic intake [R].AIAA-2005-3379,2005. [12] 尤延铖,梁德旺.内乘波式进气道内收缩基本流场研究[J].空气动力学学报,2008,26(2):203-207. YOU Yancheng,LIANG Dewang.Investigation of internal compression flowfield for internal waverider-derived inlet[J].Acta Aerodynamica Sinica,2008,26(2):203-207.(in Chinese) [13] 南向军,张堃元,金志光,等.压升规律可控的高超声速内收 缩进气道设计[J].航空动力学报,2011,26(3):518-523. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Investigation on hypersonic inward turning inlets with controlled pressure gradient[J].Journal of Aerospace Power,2011,26(3):518-523.(in Chinese) [14] 李永洲,张堃元,南向军.基于马赫数分布规律可控概念的高超声速内收缩进气道设计[J].航空动力学报,2011,27(11):2484-2491. LI Yongzhou,NAN Xiangjun,ZHANG Kunyuan.Design concept of controllable Mach number distribution hypersonic inward turning inlets[J].Journal of Aerospace Power,2011,27(11):2484-2491.(in Chinese) [15] 吴先宇,刘睿,罗世彬,等.基于替代模型的 高超声速前体/进气道一体化设计[J].航空动力学报,2008,23(5):796- 802. WU Xianyu,LIU Rui,LUO Shibin,et al.An integrated optimization of hypersonic forebody/inlet based on surrogate models[J].Journal of Aerospace Power,2008,23(5):796-802.(in Chinese) [16] 向有志,张堃元,王磊,等.壁面压 升可控的高超轴对称进气道优化设计[J].航空动力学报,2011,26(10):2193-2199. XIANG Youzhi,ZHANG Kunyuan,WANG Lei,et al.Optimization design of hypersonic axisymmetric inlet with controllable law of wall pressure rise[J].Journal of Aerospace Power,2011,26(10):2193-2199.(in Chinese) [17] 王振国,陈小前,罗文彩,等.飞行器多学科设计优化理论与应用研究[M].北京:国防工业出版社,2006. [18] 南向军,张堃元,金志光.基于反正切曲线压升规律设计高超内收缩进气道[J].航空 动力学报,2011,26 (11):2571-2577. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang.Design of hypersonic inward turning inlets with basic flowfield using law of arc tangent pressure rise[J].Journal of Aerospace Power,2011,26 (11):2571-2577.(in Chinese) [19] NAN Xiangjun,ZHANG Kunyuan.Numerical and experimental investigation on hypersonic inward turning inlets with basic flow field using arc tangent curve law of pressure rise [R].AIAA-2011-2270,2011. [20] 南向军,张堃元,金志光,等.矩形转圆形高超声速内收 缩进气道数值及实验研究[J].航空学报,2011,32(6):988- 996. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Numerical and experimental investigation of hypersonic inward turning inlets with rectangular to circular shape transition[J].Acta Aeronautica et Astronautica Sinica,2011,32(6):988-996.(in Chinese)
