二元高超声速变几何进气道气动特性研究
Research on aerodynamic characteristics of 2-D hypersonic inlet
-
摘要: 设计了一种唇罩可沿来流方向平移的二元高超声速变几何进气道,对进气道开展了三维数值仿真研究,就气动特性与相应定几何进气道进行了对比.结果表明:通过迎着来流方向平移唇罩,进气道内收缩比由1.80下降至1.57,自起动马赫数由4.9下降至3.4.在来流马赫数为4.0~7.0范围内,变几何进气道与定几何进气道隔离段出口马赫数和增压比相差不大,变几何进气道流量系数和总压恢复系数可实现提升最大值分别为21%和9%.二元高超声速变几何进气道综合气动性能明显高于定几何进气道.Abstract: A kind of 2-D hypersonic variable geometry inlet with movable lip along flow direction was designed.Three-dimensional computational fluid dynamics computation was carried out to simulate the flowfield of the inlet.Comparison of the aerodynamics characteristics was made between variable geometry inlet and fixed geometry inlet.Results indicate:by translating lip upstream,the contraction ratio (CR) of the variable geometry inlet decreases from 1.80 to 1.57 and the self-start Mach number decreases from 4.9 to 3.4.Within the Mach number range of 4.0~7.0,no major difference of the isolator exit Mach number and static pressure ratio of both inlets are observed.The mass flow rate and total pressure recovery coefficient of variable geometry inlet are at most 21% and 9% higher respectively compared with fixed geometry inlet.The variable geometry inlet has superior aerodynamic performance.
-
[1] Seddon J, GoldSmith E L.Intake aerodynamics[M].2nd ed.Oxford:Blackwell Science Ltd.,1999. [2] Blockley R,Shyy W.Encyclopedia of aerospace engineering:Volume 2 propulsion and power[M].New York:John Wiley & Sons,Ltd.,2011. [3] Davis M.The standard handbook for aeronautical and astronautical engineers[M].London: McGraw-Hill Standard Handbooks,2003. [4] Falempin F,Scherrer D,Laruelle G,et al.French hypersonic propulsion program PREPHA:results,lessons and perspectives [R].AIAA-98-1565,1998. [5] Falempin F,Serre L.LEA flight test program-status in 2004 [R].AIAA-2004-3344,2004. [6] Kojima T,Tanatsugu N,Sato T,et al.Development study on axisymmetric air inlet for ATREX engine [R].AIAA-2001-1895,2001. [7] 袁化成,滕健,郭荣伟.内收缩比可控的二元高超声速变几何进气道研究[J].航空动力学报,2012,27(11):2468-2474. YUAN Huacheng,TENG Jian,GUO Rongwei.Research on variable geometry technology of 2-D hypersonic inlet with contract ratio controlled[J].Journal of Aerospace Power,2012,27(11):2468-2474.(in Chinese) [8] 袁化成,郭荣伟.矩形截面高超声速进气道高焓风洞实验[J].航空动力学报,2010,25(12):2748-2755. YUAN Huacheng, GUO Rongwei.High enthalpy wind tunnel tests of hypersonic inlets with rectangular section[J].Journal of Aerospace Power,2010,25(12):2748-2755.(in Chinese) [9] 袁化成,郭荣伟.矩形截面高超声速进气道气动设计及实验验证[J].南京航空航天大学学报,2009,41(4):423-428. YUAN Huacheng,GUO Rongwei.Design and experimental verification of hypersonic inlet with rectangular section[J].Journal of Nanjing University of Aeronautics and Astronautics,2009,41(4):423-428.(in Chinese) [10] Herrmann C D,Koschel W W.Experimental investigation of the internal compression of a hypersonic intake [R].AIAA-2002-4130,2002. [11] Mrozinski D P,Hayes J R.Numerical and experimental analysis of a hypersonic variable geometry inlet [R].AIAA-99-0899,1999. [12] Okai K,Taguchi H,Kojima T.Futamura numerical analysis of variable intake and nozzle for hypersonic engine [R].AIAA-2003-7069,2003. [13] Van Wie D M,Kwok F T,Walsh R F.Starting characteristics of supersonic inlets [R].AIAA-96-2914,1996. [14] Ferlauto M,Larocca F,Zannetti L.Integrated design and analysis of intakes and nozzles in air-breathing engines[J].Journal of Propulsion and Power,2002,18(1):28-34. [15] Smart M K.How much compression should a scramjet inlet do[J].AIAA Journal,2012,50(3):610-619.
