短周期风洞中导叶表面压力和换热测量

李红才; 朱惠人; 付猛

短周期风洞中导叶表面压力和换热测量

西北工业大学动力与能源学院, 西安 710072

计量
- 文章访问数: 1543
- HTML浏览量: 152
- PDF量: 1025
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-20
- 刊出日期: 2013-04-28

Pressure and heat transfer measurement of vane surface in short duration wind tunnel

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 在发动机典型雷诺数和压比状态下对一种放大导叶叶型进行了表面静压和换热测量.雷诺数对表面压力系数的影响较小,压比增大使压力系数减小,并且吸力面压力系数最低点后移.雷诺数增大时叶片表面传热系数增加,并且吸力面上边界层转捩位置提前.压比主要影响吸力面传热系数,小雷诺数时压比增大会推迟吸力面上边界层转捩点位置,大雷诺数且吸力面后半段为超声速流动时,增大压比使该区域传热系数降低.保持主流总温不变,叶片表面绝热壁温随叶栅压比增大而降低,相同压比下,叶片表面处于层流状态时绝热壁温比处于湍流状态时低.
- 短周期风洞 /
- 叶栅压比 /
- 表面压力系数 /
- 表面传热系数 /
- 绝热壁温
Abstract: Surface pressure and heat transfer measurements of an enlarged vane were conducted at engine's typical Reynolds numbers and pressure ratios.The pressure coefficients decreased and the lowest point of the suction surface moved backward with an increasing pressure ratio,while the Reynolds number had small effect on the surface pressure coefficients.With increase of the Reynolds number,the surface heat transfer coefficients rose,and the transition occurred earlier at suction surface.The pressure ratio mainly affected the heat transfer of suction surface.The transition occurred later when the pressure ratio increased in small Reynolds number state.When supersonic flow appeared at the suction's rear region in large Reynolds number state,the heat transfer coefficients at large pressure ratio were lower than those at small pressure ratio.The local adiabatic wall temperatures decreased with increase of pressure ratio.In the case of constant pressure ratio,the local adiabatic wall temperature of laminar flow was lower than that of turbulent flow.
- short duration wind tunnel /
- pressure ratio /
- surface static pressure coefficient /
- surface heat transfer coefficient /
- adiabatic wall temperature

HTML

参考文献(15)

[1]	Oldfield M L G,Jones T V,Schultz D L.On-line computer for transient turbine cascade instrumentation[J].IEEE Transactions on Aerospace and Electronic Systems,1978,14(5):738-749.
[2]	Nix A C,Diller T E,Ng W F.Experimental measurements and modeling of the effects of large-scale freestream turbulence on heat transfer .ASME Paper GT2004-53260, 2004.
[3]	Coton T,Arts T,Lefebvre M,et al.Unsteady and calming effects investigation on a very high lift LP turbine blade:Part Ⅰ experimental analysis [R].ASME Paper GT-2002-30227,2002.
[4]	Didier F,Denos R,Arts T.Unsteady rotor heat transfer in a transonic turbine stage [R].ASME Paper GT-2002-30195, 2002.
[5]	Ligrani P M,Saumweber C,Schulz A,et al.Shock wave:film cooling interactions in transonic flows [R].ASME Paper 2001-GT-0133,2001.
[6]	Smith A C,Hatchett J H,Nix A C,et al.Effectiveness of normal and angled slot cooling [R].ASME Paper GT2004-53248,2004.
[7]	Haldeman C W,Dunn M G,Barter J W,et al.Aerodynamic and heat-flux measurements with predictions on a modern one and 1/2 stage high pressure transonic turbine [R].ASME Paper GT2004-53478,2004.
[8]	李静美,赵润民,王吉南.用短周期风洞进行涡轮叶片传热实验初探[J].航空动力学报,1987,2(2):18-22. LI Jingmei,ZHAO Renmin,WANG Jinan.Turbine blade surface heat transfer measurements in short-duration facility[J].Journal of Aerospace Power,1987,2(2):18-22.(in Chinese)
[9]	周勇,赵晓路,徐建中.短周期实验台涡轮机匣换热实时测量初探[J].工程热物理学报,2008,29(2):208-302. ZHOU Yong,ZHAO Xiaolu,XU Jianzhong.Time-resolved heat transfer measurements on turbine outer endwall in a blow-down transient test facility[J].Journal of Engineering Thermophysics,2008,29(2):208-302.(in Chinese)
[10]	朱彦伟.短周期传热风洞气动特性模拟与控制方法研究 [D].西安:西北工业大学,2007. ZHU Yanwei.Simulation and control of the high speed transient blade wind tunnel's pneumatic characteristics [D].Xi'an:Northwestern Polytechnical University,2007.(in Chinese)
[11]	朱惠人,成文娟,李红才.短周期风洞叶栅瞬态换热实验数据处理[J].航空动力学报,2011,26(6):1301 -1309. ZHU Huiren,CHENG Wenjuan,LI Hongcai.Data processing of blade's transient heat transfer experiment in short duration wind tunnel [J].Journal of Aerospace Power,2011,26(6):1301-1309.(in Chinese)
[12]	Oldfield M L G.Impulse response processing of transient heat transfer gauge signals[J].Journal of Turbomach,2008,130(2):021023-1-9.
[13]	Giel P W,Bunker R S,Fossen G J V,et al.Heat transfer measurements and predictions on a power generation gas turbine blade [R].ASME Paper 2000-GT-0209,2000.
[14]	向安定.涡轮叶片型面气膜冷却的研究 [D].西安:西北工业大学,2003. XIANG Anding.Investigation of film cooling on the surface of blade in a turbine cascade [D].Xi'an:Northwestern Polytechnical University,2003.(in Chinese)
[15]	朱谷君.工程传热传质学[M].北京:航空工业出版社,1989.
