含分层损伤复合材料层合板振动特性

漆文凯; 程博; 刘磊

含分层损伤复合材料层合板振动特性

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1459
- HTML浏览量: 3
- PDF量: 917
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-11
- 刊出日期: 2013-04-28

Vibration characteristic of composite laminates with delamination

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 针对复合材料层合板分层损伤区域上、下子板的畸变模态,采用自定义矩阵单元模拟其损伤区的接触刚度,建立了一种合理的层合板分层损伤有限元振动分析模型;在此基础上研究了分层深度和分层大小对复合材料层合板振动特性的影响.数值模拟结果与实验结果的对比表明:采用的自定义矩阵单元可以有效地模拟层合板的分层损伤,模态计算值与实验值的最大误差为10.67%,最小误差为0.34%;分层深度和分层大小对复合材料层合板振动特性有较大影响,随分层深度变化,固有频率最多下降50%;随分层大小变化,前4阶固有频率最多下降12%.
- 复合材料层合板 /
- 分层损伤 /
- 自定义矩阵单元 /
- 有限元法 /
- 振动特性
Abstract: A reasonable finite element model was established to simulate composite laminates with delamination by using the user-defined matrix element to simulate contacting element in delamination region for distortion mode of the upper and lower sublaminates,and the selection of connection stiffness values was studied as well.This article focuses on the vibration performance of composite laminates with delamination depth and delamination size.The comparison of numerical simulation and experimental results indicates that it is feasible to simulate the delamination of composite laminates with the user-defined matrix elements; the maximum error of the modal calculation and the experimental values is 10.67%, and the minimum error is 0.34%; delamination depth and size have significant effects on vibration characteristic of composite laminates, and the natural frequency of laminates declines up to 50% with change of delamination depth; the first to fourth order natural frequencies of laminates decrease up to 12% with change of delamination size.
- composite laminates /
- delamination /
- user-defined matrix elements /
- finite element method /
- vibration characteristic

HTML

参考文献(16)

[1]	Mujumdar P M,Suryanarayan S.Flexural vibrations of beams with delaminations[J].Journal of Sound and Vibration,1988,125(3):441-461.
[2]	Rao M K,Desai Y M,Chitnis M R.Free vibrations of laminated beams using mixed theory[J].Composite Structure,2001,52(2):149-160.
[3]	Ju F,Lee H P,Lee K H.Free vibrations of composite plates with delaminations around cutout[J].Composite Structures,1995,31(2):177-183.
[4]	Hu N,Fukunaga H,Kameyama M.Vibration analysis of delaminated composite beams and plates using a high-order finite element[J].International Journal of Mechanical Sciences,2002,44(7):1479-1503.
[5]	Namita N,Sahub S K.Free vibration analysis of delaminated composite shells using different shell theories[J].International Journal of Pressure Vessels and Piping,2012,98:111-118.
[6]	Nag A,Mahapatra D R,Gopalakrishnan S,et al.A spectral finite element with embedded delamination for modeling of wave scattering in composite beams[J].Composites Science and Technology,2003,63(15):2187-2200.
[7]	Nilsson K F,Asp L E,Alpman J E,et al.Delamination buckling and growth for delaminations at different depths in a slender composite panel[J].International Journal of Solids and Structures,2001,38(17):3039-3071.
[8]	Wang T J S, Liu Y Y,Gibby J A.Vibrations of split beams[J].Journal of Sound and Vibration,1982,84(4):491-502.
[9]	Chang T P.Vibration analysis of delaminted composite plates under axial load[J].Mech Struct & Mach,1998,26(2):195-218.
[10]	Shu D,Mai Y W.Delamination buckling with bridging[J].Composites Science and Technology,1993,47(1):25-33.
[11]	刘红霞.复合材料分层损伤的数值模拟[D].西安:西北工业大学,2006. LIU Hongxia.Numerical simulation of delamination damage for composite [D].Xi'an:Northwestern Polytechnical University,2006.(in Chinese)
[12]	Tracy J J,Pardoen G C.Effect of delamination on the natural frequencies of composite laminates[J].Journal of Composite Materials,1989,23(12):1200-1215.
[13]	Chen H P,Tracy J J,Nonato R.Vibration analysis of delaminated composite laminates in prebuckled states based on a new constrained model[J].Journal of Composite Materials,1995,29(2):229-256.
[14]	洪明,陈浩然.含分层损伤复合材料层合板胶接振动特性影响[J].大连理工大学学报,2003,43(1):24-27. HONG Ming,CHEN Haoran.Effect of repair on vibration characteristics of laminated composite plate with delamitation[J].Chinese Journal of Dalian University of Technology,2003,43(1):24-27.(in Chinese)
[15]	吉桂秀.含多个分层损伤复合材料层合板的自由振动特性研究 [D].大连:大连理工大学,2006. JI Guixiu.Study on free vibration characteristics for com posite laminates and stiffened plates with multiple delaminations [D].Dalian:Dalian University of Technology,2006. (in Chinese)
[16]	孙先念,陈浩然,苏长健,等.含分层损伤复合材料层合板分层扩展研究[J].力学学报,2000,32(2):223-232. SUN Xiannian,CHEN Haoran,SU Changjian,et al.Delamination growth in composite laminates[J].Journal of Theoretical and Applied Mechanics,2000,32(2):223-232.(in Chinese)
