一种用于CT空间分辨率增强的图像重建方法

傅健; 谭忍泊; 赵峰

一种用于CT空间分辨率增强的图像重建方法

1.
北京航空航天大学机械工程及自动化学院数字辐射成像与生物医学成像实验室, 北京 100191
2.
内蒙古红峡化工厂, 呼和浩特 010010

基金项目: 国家自然科学基金(11179009, 50875013); 北京市自然科学基金(4102036); 北京市科技新星计划(2009A09)

计量
- 文章访问数: 2057
- HTML浏览量: 69
- PDF量: 1084
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-28
- 刊出日期: 2013-05-28

An image reconstruction method for improving CT spatial resolution

1.
Digital Radiation Imaging and Biomeidcal Imaging Laboratory, School of Mechanical Engineering and Automation, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Hongxia Chemical Plant in Inner Mongolia, Hohhot 010010, China

摘要

摘要: 为在既有硬件条件下提高工业计算机层析成像(computed tomography,CT)系统空间分辨率,分析了提高采样频率的半像素错位工业CT扫描方法,提出了一种基于代数迭代技术的直接重建算法,以面积权值对采集到的投影数据进行交替迭代,实现高分辨率图像重建.利用星型空间分辨率模型开展了计算机仿真分析,重建图像截止频率处的调制度达到0.8,表明了该方法提高空间分辨率的潜力.标准空间分辨率测试卡工业CT扫描重建实验结果进一步验证了其可行性和有效性.该方法简单、易行,在工业CT系统中有良好工程应用前景.
- 工业计算机层析成像 /
- 空间分辨率 /
- 半像素错位扫描 /
- 重建算法 /
- 代数迭代重建
Abstract: In order to improve the spatial resolution of industrial computed tomography (CT) without changing the hardware,the half-pixel offset scanning mode was analyzed and a direct reconstruction algorithm,which was based on the algebraic iteration technique,was proposed.This algorithm adopted area-weight to execute directly the iterative update of the reconstructed value using the acquired projection data.Computer simulation analysis with a star-type spatial resolution phantom was implemented and a modulation of 0.8 was reached at the cut-off frequency.It demonstrates that the proposed method has the potential of improving the spatial resolution.The industrial CT experimental results of a standard spatial resolution phantom validate the feasibility and the effect of the method.The proposed approach is easy to implement and has a promising application future.
- industrial computed tomography /
- spatial resolution /
- half-pixel offset scanning /
- reconstruction algorithm /
- algebraic iteration reconstruction

HTML

参考文献(15)

[1]	FU Jian,LU Hongnian,LI Bin.X-CT imaging method for large objects using double offset scan mode[J].Nuclear Instruments and Methods in Physics Research:Section A,2007,575(3):519-523.
[2]	FU Jian,LU Hongnian.Beam-hardening correction method based on original sinogram for X-CT[J].Nuclear Instruments and Methods in Physics Research:Section A,2006,556(1):379-385.
[3]	FU Jian,TAN Renbo,WANG Qianli.A cone beam computed tomography inspection method for fuel rod cladding tubes[J].Nuclear Instruments and Methods in Physics Research:Section A,2012,688:1-6.
[4]	FU Jian,JIANG Baihong,LI Bin.Methods determining the angular increment of a continuous scan cone-beam CT system[J].IEEE Transactions on Nuclear Science,2010,57(3):1071-1076.
[5]	Lima I,Assis J T,Apoloni C R.Non-destructive imaging materials investigation by microfocus 3D X-ray computed tomography[J].IEEE Transactions on Nuclear Science,2009,56(6):1448-1453.
[6]	傅健,李斌,肖迎春.航空发动机涡轮叶片工业CT图像降噪方法[J].航空动力学报,2010,25(4):857-860. FU Jian,LI Bin,XIAO Yingchun.Denoising method for aeronautical engine turbine blade X-ray industrial CT image[J].Journal of Aerospace Power,2010,25(4):857-860.(in Chinese)
[7]	李保磊,傅健,魏东波.工业计算机断层成像系统转台旋转中心的确定[J].航空动力学报,2009,24(7):1544-1548. LI Baolei,FU Jian,WEI Dongbo.Determination of rotation center in industrial computed tomography system[J].Journal of Aerospace Power,2009,24(7):1544-1548.(in Chinese)
[8]	傅健,路宏年.工业CT半扫描成像技术[J].北京航空航天大学学报,2005,31(9):966-969. FU Jian,LU Hongnian.Half-scan mode for industrial CT[J].Journal of Beijing University of Aeronautics and Astronautics,2005,31(9):966-969.(in Chinese)
[9]	傅健,路宏年,侯涛,等.基于ICT图像的航空发动机涡轮叶片壁厚尺寸精密测量方法[J].航空学报,2006,27(2):325-330. FU Jian,LU Hongnian,HOU Tao,et al.Wall thickness precision measurement method for air engine turbine blade on ICT images[J].Acta Aeronautica et Astronautica Sinica,2006,27(2):325-330.(in Chinese)
[10]	魏东波,傅健,李斌,等.提高三维ICT成像空间分辨率的扫描方式及其重建算法[J].航空动力学报,2007,22(5):768-772. WEI Dongbo,FU Jian,LI Bin,et al.Scan mode and its reconstruction algorithm for improving spatial resolution of 3D-ICT[J].Journal of Aerospace Power,2007,22(5):768-772.(in Chinese)
[11]	Lonn A H.Computed tomography system with translatable focal spot:USA,5173852[P].1992-12-22.
[12]	张朋,郭明焕.由相叠的低分辨扇形束投影数据重建高分辨CT图像[J].核技术,2002,25(10):805-810. ZHANG Peng,GUO Minghuan.Reconstruction high resolution image from overlapped low resolution fan beam projections data[J].Nuclear Techniques,2002,25(10):805-810.(in Chinese)
[13]	张慧滔,田娟,陈明,等.新的超分辨CT扫描模式和图像重建方法[J].中国体视学与图像分析,2005,10(3):154-157. ZHANG Huitao,TIAN Juan,CHEN Ming,et al.A novel scanning mode and image reconstruction method on super-resolution CT[J].Chinese Journal of Stereology and Image Analysis,2005,10(3):154-157.(in Chinese)
[14]	庄天戈.CT原理与算法[M].上海:上海交通大学出版社,1992:88-93.
[15]	American Socity for Testing and Materials (ASTM).E1441-00(2005) Standard guide for computed tomography (CT) imaging[S].West Conshohocker,US:ASTM,2005.
