基于自由尾迹方法的复合材料无铰式旋翼气弹稳定性分析

肖宇; 徐国华; 招启军

基于自由尾迹方法的复合材料无铰式旋翼气弹稳定性分析

南京航空航天大学航空宇航学院直升机旋翼动力学国家级重点实验室, 南京 210016

计量
- 文章访问数: 1445
- HTML浏览量: 100
- PDF量: 1127
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-23
- 刊出日期: 2013-05-28

Aeroelastic stability analysis of composite hingeless rotor based on free-wake model

National Key Laboratory of Rotorcraft Aeromechanics, College of Aeronautics and Astronautics, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 基于有限元理论及自由尾迹方法,建立了一套适用于各向异性复合材料无铰式旋翼的气弹稳定性分析方法.为了模拟复合材料旋翼气弹特性,截面特性参数采用二维线性有限元方法分析得到,展向一维梁则采用考虑剪切变形的23自由度非线性梁单元模拟,并将自由尾迹分析模型用于计算旋翼非均匀诱导速度场,基于升力线模型构建了一个高效且较为精细的气动分析模块.在此基础上开展了无铰式旋翼气弹稳定性分析,算例计算及验证表明建立的模型能有效地用于复合材料旋翼非定常气动载荷预估及进行气弹稳定性分析.最后细致分析并获得了复合材料铺层角对无铰式旋翼气弹稳定性参数的影响规律,结果表明:算例在小拉力系数(0.0025)下,截面竖直铺层角在10°到25°会发生气弹稳定性问题,这在真实型号设计中应当注意避免.
- 旋翼 /
- 自由尾迹 /
- 气弹稳定性 /
- 截面特性 /
- 复合材料
Abstract: Based on finite element method (FEM) and free-wake method, an aeroelastic stability analysis model of composite hingeless rotor was developed. In order to simulate the aeroelastic behavior of composite rotor, 2-D linear FEM analysis was employed to obtain the sectional properties, and 1-D beam was modeled by 23 degree of freedom (DOF) nonlinear beam element which included transverse shears. The free-wake model was adopted to calculate non-uniform induced velocity field, and a highly-efficient and accurate aerodynamics analysis module was established by using lifting-line theory. On the basis of these, the stability analysis for composite hingless rotor was carried out. It is demonstrated by numerical simulation that the present model is capable to predict unsteady airloads and aeroelastic stability characteristics of composite rotor. Finally, the effect of material ply orientation on hingless rotor aeroelastic stability was analyzed, and it can be seen from the results that under the condition of low thrust coefficient (0.0025), the rotor aeroelastic instability may occur when ply angle of the vertical wall varies between 10°and 25°, which should be avoided in rotor design.
- rotor /
- free-wake /
- aeroelastic stability /
- sectional properties /
- composite material

HTML

参考文献(15)

[1]	Hong C H,Chopra I.Aeroelastic stability analysis of a composite rotor blade[J].Journal of the American Helicopter Society,1985,30(2):57-67.
[2]	Smith E C,Chopra I.Aeromechanical stability of helicopters with composite rotor blades in forward flight[C]//Proceedings of the 48th American Helicopter Society Annual Forum.Phenix,Arizona,US:AHS,1992:57-73.
[3]	Friedmann P P,Yuan K A,De Terlizzi M.An aeroelastic model for composite rotor blades with straight and swept tips:Part Ⅰ aeroelastic stability in hover[J].International Journal of Non-linear Mechanics,2002,37(4/5):967-986.
[4]	Friedmann P P,Glaz B,Palacios R.A moderate deflection composite helicopter rotor blade model with an improved cross-sectional analysis[J].International Journal of Solids and Structures,2009,46(10):2186-2200.
[5]	Fulton M V,Hodges D H.Aeroelastic stability of composite hingeless rotor blades in hover:Part Ⅰ theory[J].Mathematical and Computer Modelling,1993,18(3/4):1-17.
[6]	Fulton M V,Hodges D H.Aeroelastic stability of composite hingeless rotor blades in hover:Part Ⅱ results[J].Mathematical and Computer Modelling,1993,18(3/4):19-35.
[7]	石庆华,向锦武.桨根柔性无铰旋翼桨叶气弹稳定性建模分析[J].北京航空航天大学学报,2007,33(7):793-797. SHI Qinghua,XIANG Jinwu.Analytical model of aeroelastic stability of hingeless rotor blade with com posite flexures[J].Journal of Beijing University of Aeronautics and Astronautics,2007,33(7):793-797.(in Chinese)
[8]	Giavotto V,Borri M,Mantegazza P,et al.Anisotropic beam theory and applications[J].Computers Structures,1983,16(4):403-413.
[9]	高文杰,向锦武.基于有限状态入流的无轴承旋翼气弹稳定性[J].华中科技大学学报,2011,39(12):58-62. GAO Wenjie,XIANG Jinwu.Aeroelastic stability of a bearingless rotor in hover with finite-state unsteady aerodynamics[J].Journal of Huazhong University of Science and Technology,2011,39(12):58-62.(in Chinese)
[10]	Borri M,Merlini T.A large displacement formulation for anisotropic beam analysis[J].Meccanica,1986,21(1):30-37.
[11]	赵景根,徐国华,招启军.基于自由尾迹分析的直升机旋翼下洗流场计算方法[J].兵工学报,2006,27(1):63-68. ZHAO Jinggen,XU Guohua,ZHAO Qijun.A calculating method of helicopter rotor downwash flowfield based on free wake analysis[J].Acta Armamentarii,2006,27(1):63-68.(in Chinese)
[12]	Yuan K A.Aeroelasticity and structural optimization of composite helicopter rotor blades with swept tips[D].Los Angeles:University of California,1994.
[13]	王海.计入桨叶结构弹性的新型桨尖旋翼流场数值模拟研究[D].南京:南京航空航天大学,2010. WANG Hai.Numerical simulation for the flowfield of new-tip rotors with effect of blade elasticity[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2010.(in Chinese)
[14]	Datta A,Sitaraman J,Chopra I,et al.CFD/CSD prediction of rotor vibratory loads in high-speed flight[J].Journal of Aircraft,2006,43(6):1698-1709.
[15]	Kosmatka J B,Friedmann P P.Vibration analysis of composite turbopropellers using a nonlinear beam-type finite element approach[J].AIAA Journal,1989,27(11):1606-1614.
