某型飞机短舱辐射换热计算

吴宇; 钟剑龙; 吕其明

某型飞机短舱辐射换热计算

中国航空工业集团公司第一飞机设计研究院, 西安 710089

计量
- 文章访问数: 1773
- HTML浏览量: 165
- PDF量: 960
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-15
- 刊出日期: 2013-05-28

Numerical investigation of thermal radiation in a nacelle

The First Aircraft Institute, Aviation Industry Corporation of China, Xi'an 710089, China

摘要

摘要: 针对某飞机地面慢车工况,进行了短舱内复合换热数值计算研究,分别运用球谐函数法、离散坐标法和蒙特卡洛法计算辐射换热.结果显示:不同计算方法所得结果总体上趋于一致,热辐射与自然对流耦合作用明显.与单纯自然对流的计算结果相比,舱内温度显著升高,各区域温度值上升7%~30%.考虑空气介质对不同波段热辐射的选择性吸收后,短舱内各计算点温度进一步上升.综合分析表明:地面条件下飞机短舱换热分析过程中热辐射的影响不可忽略.
- 短舱 /
- 热辐射 /
- 球谐函数 /
- 离散坐标 /
- 蒙特卡洛 /
- 数值计算
Abstract: Based on computational fluid dynamics method,airplane in idle condition was studied in conjunction with heat transfer in a nacelle.And different radiation computation methods including spherical harmonics,discrete ordinate and Monte Carlo method were adopted to simulate thermal radiation.The result shows that coupling effect of radiation and convection is obvious.In addition,compared with the simulation result of pure convection,nacelle ambient temperature predicted by coupling way is 7%~30% higher.While selective absorption of air under infrared radiation is taken into account,the ambient temperature rises further.Thus the effect of thermal radiation should not be ignored to simulate nacelle hear transfer in ground condition.
- nacelle /
- thermal radiation /
- spherical harmonics /
- discrete ordinate /
- Monte Carlo /
- numerical investigation

HTML

参考文献(15)

[1]	Larson D W,Viskanta R.Transient combined laminar free convection and radiation in a rectangular enclosure[J].J Fluid Mech,1976,78(1):65-85.
[2]	Lauriat G.Combined radiation-convection in gray fluids enclosed in vertical cavities[J].Journal of Heat Transfer,1982,104(4):609-615.
[3]	Lauriat G.Numerical study of interaction of natural convection with radiation in non-gray gases in a narrow ver- tical cavity[C]//Proceedings of Seventh International Heat Transfer Conference.San Francisco,California,US:1982:153-157.
[4]	Tan H P,Lallemand M.Transient radiative-conductive heat transfer in flat glasses submitted to temperature,flux and mixed boundary conditions[J].International Journal of Heat and Mass Transfer,1989,32(5):795-810.
[5]	季经纬,李全峰,陈金林,等.火焰与烟气层热辐射的实验与蒙特卡洛法模拟[J].中国矿业大学学报,2008,37(1):53-56. JI Jingwei,LI Quanfeng,CHEN Jinlin,et al.Experiments and Monte-Carlo simulation of heat radiation flux from flame and hot smoke layers[J].Journal of China University of Mining & Technology.2008,37(1):53-56.(in Chinese)
[6]	战乃岩,杨茉,徐沛巍.封闭腔导热辐射与自然对流耦合换热的数值研究[J].中国科学:技术科学,2010,40(9):1052-1060. ZHAN Naiyan,YANG Mo,XU Peiwei.A two-dimensional study on natural convection and heat transfer in the enclosure with heat transfer and radiation coupled in natural convection[J].Sci China:Tech Sci,2010,40(9):1052-1060.(in Chinese)
[7]	刘林华,赵军明,谈和平.辐射传递方程数值模拟的有限元和谱元法[M].北京:科学出版社,2008.
[8]	谈和平,刘林华,易红亮,等.计算热辐射学的进展[J].科学通报,2009,54(18):2627-2637. TAN Heping,LIU Linhua,YI Hongliang,et al.Recent progress in computational thermal radiative transfer[J].Chinese Sci Bull,2009,54(18):2627-2637.(in Chinese)
[9]	Jeans J H.The equations of radiative transfer of energy[J].Monthly Notices Royal Astronomical Society,1917,78:28-36.
[10]	Modest M F.The modified differential approximation for radiative transfer in general three-dimensional media[J].Journal of Thermophysics and Heat Transfer,1989,3(3):283-488.
[11]	Howell J R.Application of Monte Carlo to heat transfer problems[M]//Advance in heat transfer.New York:Academic Press,1968:1-54.
[12]	罗森诺 W M.传热学基础手册:下册[M].北京:科学出版社,1992:436-441.
[13]	严兆大,沈季胜,刘震涛,等.用蒙特卡洛法计算柴油机缸内多元热辐射[J].内燃机学报,2000,18(2):133-136. YAN Zhaoda,SHEN Jisheng,LIU Zhentao,et al.Calculation of the radiation heat transfer in cylinder of diesel engine by the Monte-Carlo method[J].Transactions of CSICE,2000,18(2):133-136.(in Chinese)
[14]	Chandrasekhar S.Radiative transfer[M].New York:Dover Publications Inc.,1960.
[15]	谈和平,夏新林,刘新华,等.红外辐射特性与传输的数值计算:计算热辐射学[M].哈尔滨:哈尔滨工业大学出版社,2006:174-176.
