带扫气蜗壳的整体式惯性粒子分离器仿真

童悦; 谭慧俊; 曾平君

带扫气蜗壳的整体式惯性粒子分离器仿真

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
南京航空航天大学民航/飞行学院, 南京 210016

基金项目: 教育部新世纪优秀人才支持计划(NCET-110831)

计量
- 文章访问数: 1550
- HTML浏览量: 87
- PDF量: 987
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-30
- 刊出日期: 2013-05-28

Numerical simulation of inertial particle separator with scavenge scroll

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
College of Civil Aviation, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 对一种带有扫气蜗壳的整体式惯性粒子分离器进行了仿真研究,获得了该粒子分离器的流动及粒子分离特性.结果表明:原型方案中粒子分离器扫气通道顶部和底部流动不畅,使得扫气蜗壳不能周向均匀进气并且局部出现倒流.当扫气比为19%时,主流道出口截面总压恢复系数为0.982,AC砂和C砂分离效率较差,分别为64.8%和76.6%.而在扫气蜗壳内收集管上游加装隔板后,其进气特性的周向均匀性及蜗壳内旋涡结构得到改善,粒子分离效率也得到显著提高:相同扫气比下,AC砂和C砂的分离效率分别提高了18.1%和20.9%,且主流道出口截面的总压恢复系数基本不下降.
- 扫气蜗壳 /
- 整体式惯性粒子分离器 /
- 分离效率 /
- 隔板 /
- 旋涡结构
Abstract: An inertial particle separator with scavenge scroll was numerically studied to obtain its flow structure and scavenge efficiency performance characteristics.Results indicate that the flow fields at the top and bottom of the scavenge path are not smooth.Thus,the gas from the circular inlet can not flow into the scavenge scroll equably.When the bypass rate is 19%,the total pressure recovery coefficient of the core flow is 0.982;AC coarse and C-spec separator efficiencies are 64.8% and 76.6%,respectively.The flow structure and performance characteristics of the inertial particle separator are improved,and especially the vortical structures in scavenge scroll are of advantage to sand separating when the flow divider is added to the top of the scavenge scroll.With the same bypass rate,AC coarse and C-spec separation efficiencies increase 18.1% and 20.9%,respectively.Besides,the total pressure recovery coefficient of the core flow does not decrease much.
- scavenge scroll /
- inertial particle separator /
- separation efficiency /
- flow divider /
- vortical structure

HTML

参考文献(16)

[1]	Filippone A,Bojdo N.Turboshaft engine air particle separation[J].Progress in Aerospace Sciences,2010,46(5/6):224-245.
[2]	Robert J D,Bernard F S.Integral engine inlet particle separator:VolumeⅡ design guide[R].USAAMRDL-TR-75-31B,1975.
[3]	Hamed A.Particle dynamics of inlet flow fields with swirling vanes[R].AIAA 1981-0001,1981.
[4]	Breitman D S,Dueck E G,Habashi W G.Analysis of a split flow inertial particle separator using finite elements[J].Journal of Aircraft,1985,22(2):135-140.
[5]	Vittal B V R,Tipton D L,Bennett W A.Development of an advanced vaneless inlet particle separator for helicopter engines[R].AIAA 85-1277,1985.
[6]	Zedan M.Viscous flow analysis of advanced particle separators[J].Journal of Propulsion and Power,1992,8(4):843-848.
[7]	Tabakoff W.Measured particle rebound characteristics on materials used in gas turbines[R].AIAA 89-1693,1989.
[8]	Eroglu H,Tabakoff W.3-D LDV measurements of particle rebound characteristics[R].AIAA 91-0011,1991.
[9]	侯凌云,严传俊.二维粒子分离器的流场及分离效率的数值模拟[J].航空动力学报,1997,12(4):374-376. HOU Lingyun,YAN Chuanjun.Numerical simulation of two-dimensional flow field and separator effectiveness in the particle separator[J].Journal of Aerospace Power,1997,12(4):374-376.(in Chinese)
[10]	侯凌云,严传俊.直升机粒子分离器三维两相流场的数值模拟[J].航空动力学报,2000,15(2):215-217. HOU Lingyun,YAN Chuanjun.Numerical simulation of three-dimensional two-phase flows field in the particle separator[J].Journal of Aerospace Power,2000,15(2):215-217.(in Chinese)
[11]	侯凌云,严传俊.多区域多重网格法在直升机粒子分离器中的应用[J].航空学报,2000,21(3):238-240.HOU Lingyun,YAN Chuanjun.Application of multiblock/multigrid method to inlet particle separator in helicopter[J].Acta Aeronautica et Astronautica Sinica,2000,21(3):238-240.(in Chinese)
[12]	吴恒刚,王锁芳.整体式粒子分离器数值模拟[J].航空学报,2007,28(15):1073-1079. WU Henggang,WANG Suofang.Numerical simulation investigation of inertial particle separator[J].Acta Aeronautica et Astronautica Sinica,2007,28(15):1073-1079.(in Chinese)
[13]	吴恒刚.无叶片整体式粒子分离器性能研究[D].南京:南京航空航天大学,2007. WU Henggang.Numerical simulation of vaneless inertial particle separator[D].Nanjing:Nanjing University of Aeronautices and Astronautics,2007.(in Chinese)
[14]	Andrew S.Shifting sands:using image analysis and laser technology to study coastal sand dispersal[EB/OL].[2012-5-29].Http://www.dipa2000.com/pdfs/shifting-sands.pdf.
[15]	Wakeman T,Tabakoff W.Measured particle rebound characteristics useful for erosion prediction[C]//Proceedings of Gas Turbine Conference.London:ASME,1982:83-95.
[16]	Johannes P W,Alan N.Life prediction of helicopter engines fitted with dust filters[J].AIAA Journal,1995,32(1):118-123.
