某驻涡燃烧室性能数值模拟

翟晓磊; 彭日亮; 樊未军; 张荣春; 王伟俭

某驻涡燃烧室性能数值模拟

1.
北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191
2.
大唐国际发电股份有限公司山西大唐国际云冈热电有限责任公司, 山西大同 037039

计量
- 文章访问数: 1707
- HTML浏览量: 111
- PDF量: 933
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-16
- 刊出日期: 2013-05-28

Numerical simulation on a certain trapped vortex combustor

1.
National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Datang International Yungang Thermal Power Limited Liability Company, Datang International Power Generation Corporation Limited, Datong Shanxi 037039, China

摘要

摘要: 设计了适用于某驻涡燃烧室模型的喷油杆,对该喷油杆进行了冷态雾化试验,在不同的气液比、不同的气体和液体压力下研究了喷油杆的雾化性能.通过计算流体动力学(CFD)方法对驻涡燃烧室进行了冷态和热态的数值模拟,得到了燃烧室内部的速度场、温度场和质量分数分布.计算结果表明:该燃烧室设计合理,结构紧凑,燃料燃烧充分,凹腔试验件的壁温分布较为理想.得到了总压损失和出口温度分布的变化规律:燃烧室的总压损失略偏大,出口温度分布较为均匀.并对出口温度分布的规律进行了试验验证,研究结果可以为驻涡燃烧室的工程应用提供参考.
- 驻涡燃烧室 /
- 燃烧性能 /
- 出口温度分布 /
- 凹腔 /
- 数值模拟
Abstract: A fuel injector was designed for a certain type of trapped vortex combustor.Then,experiments were conducted to check its atomizing performance under various conditions,including different gas to liquid ratios,gas pressures and liquid pressures.The cold and hot simulations of the combustor were conducted to study the performance,and the velocity field,the temperature field and mass fraction distribution of the combustor were obtained.The simulation results show that the combustor is reasonably designed with compact structure and high combustion efficiency.The wall temperature distribution of the cavity is ideal.The changing regularity of the pressure loss and the outlet temperature distribution were obtained by numerical simulation and experimental research.The total pressure loss of the combustor is a bit larger and the temperature distribution of outlet is uniform.The results can provide relevent reference for the engineering application of the trapped vortex combustor.
- trapped vortex combustor /
- combustion performance /
- outlet temperature distribution /
- cavity /
- numerical simulation

HTML

参考文献(15)

[1]	Roquemore W M,Shousese D,Burrus D,et al.Trapped vortex combustor concept for gas turbine engines[R].AIAA 2001-0483,2001.
[2]	Hsu K Y,Goss L P,Trump D D.Performance of a trapped-vortex combustor[R],AIAA-95-0810,1995.
[3]	Brankovic A,Ryder R.Emissions prediction and measurement for liquid-fueled TVC combustor with and without water injection[R].AIAA 2005-0215,2005.
[4]	Hendricks R C,Shouse D T,Roquemore W M,et al.Experimental and computational study of trapped vortex combustor sector rig with tri-pass diffuser[R].NASA/TM 2004-212507,2004.
[5]	Hendricks R C,Shouse D T,Roquemore W M,et al.Computational parametric study of fuel distribution in an experimental trapped vortex combustor sector rig[R].ASME GT 2004-53225,2004.
[6]	易琦.驻涡燃烧室流动和燃烧特性研究[D].北京:北京航空航天大学,2006. YI Qi,Trapped vortex combustor flow and combustion characterizes research[D].Beijing:Beijing University of Aeronautics and Astronautics,2006.(in Chinese)
[7]	孔昭健.驻涡燃烧室燃烧特性及结构优化研究[D].北京:北京航空航天大学,2007. KONG Zhaojian.Trapped vortex combustor combustion characterizes and structure optimization research[D].Beijing:Beijing University of Aeronautics and Astronautics,2007.(in Chinese)
[8]	Burrus D,Johnson A W,Roquemore W M.Performance assessment of a prototype trapped vortex combustor concept for gas turbine application[R].ASME 2001-GT-0087,2001.
[9]	邢菲.级间驻涡燃烧室燃烧组织及性能优化研究[D].北京:北京航空航天大学,2009. XING Fei.Research on combustion organization and performance optimization of trapped vortex combustor between blades of turbine[D].Beijing:Beijing University of Aeronautics and Astronautics,2009.(in Chinese)
[10]	邢菲,樊未军,柳杨,等.油气匹配及后体进气量对TVC燃烧性能的影响[J].航空动力学报,2008,23(5):871-876. XING Fei,FAN Weijun,LIU Yang,et al.Effect of different fuel-air matching forms on combustion performance of trapped vortex combustor[J].Journal of Aerospace Power,2008,23(5):871-876.(in Chinese)
[11]	《航空发动机设计手册》总编委会.航空发动机设计手册:第11册[M].北京:航空工业出版社,2001.
[12]	Mellor A M.Design of modern turbine combustors[M].Nashville,Tennessee,US:Vanderbilt University,1990.
[13]	顾恒祥.燃料与燃烧[M].西安:西北工业大学出版社,1993.
[14]	《航空发动机设计手册》总编委会.航空发动机设计手册:第9册[M].北京:航空工业出版社,2001.
[15]	黄勇,林宇震,樊未军,等.燃烧与燃烧室[M].北京:北京航空航天大学出版社,2007.
