声能喷嘴供油级间驻涡燃烧室的性能试验

谭米; 樊未军; 张荣春; 宋双文; 邢菲

声能喷嘴供油级间驻涡燃烧室的性能试验

1.
北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191
2.
中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002
3.
厦门大学物理与机电工程学院, 福建厦门 361005

计量
- 文章访问数: 1812
- HTML浏览量: 235
- PDF量: 1001
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-05
- 刊出日期: 2013-05-28

Experiment on performance of interstage turbine trapped vortex combustor with acoustic energy nozzle

1.
National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China
3.
School of Physics and Mechanical and Electrical Engineering, Xiamen University, Xiamen Fujian 361005, China

摘要

摘要:
对一种采用声能喷嘴供油方式的级间燃烧室进行了性能试验研究.试验结果表明:当进口马赫数为0.20~0.40,燃烧室的熄火余气系数为25~35,燃烧室的稳定工作范围较宽;随余气系数增大,出口温度分布均匀性提高;燃烧效率为96%~98%,随余气系数减小,燃烧效率降低;进口马赫数对点火性能、熄火性能、出口温度分布和燃烧效率的影响较小;壁面热点温度出现在凹腔的后壁面;总压损失系数为0.03~0.11,热态时比冷态时高0.015左右; CO和NOx的排放指数分别为20~46和0.9~2.1,进口马赫数、余气系数均对污染物排放有较大影响.
- 级间燃烧室 /
- 驻涡燃烧室 /
- 声能喷嘴 /
- 燃烧性能 /
- 性能试验
Abstract:
Performance of an interstage turbine burner with an acoustic energy nozzle was investigated experimentally.The experimental result shows that the air excess coefficient of lean blowout is in the range of 25~35 under the condition of Mach number being 0.20~0.40,and the range of stable combustion is relatively wide.The uniformity of outlet temperature distribution is improved with the increase of air excess coefficient.The combustion efficiency is in the range of 96%~98%,and it decreases as the air excess coefficient decreases.Inlet Mach number has little effect on ignition performance,lean blowout performance,outlet temperature distribution and combustion efficiency.The maximum wall temperature locates on the after-wall of the cavity.The total pressure loss coefficient is in the range of 0.03~0.11,and it is about 0.015 higher in hot state than in cold state.The emission index of CO is in the range of 20~46 and that of NOx is in the range of 0.9~2.1.The inlet Mach number and air excess coefficient both have significant effect on the pollutant emission.
- interstage turbine burner /
- trapped vortex combustor /
- acoustic energy nozzle /
- combustion performance /
- performance experiment

HTML

参考文献(18)

[1]	Sirignano W A,Liu F.Performance increases gas-turbine engines through combustion inside the turbine[J].Journal of Propulsion and Power,1999,15(1):111-118.
[2]	Chen G,Myron A H,Roger L D.Gas-turbine performance improvements through the use of multiple turbine interstage burners[J].Journal of Propulsion and Power,2004,20(5):828-834.
[3]	Liew K H,Urip E,Yang S L.Parametric cycle analysis of a turbofan engine with an interstage turbine burner[J].Journal of Propulsion and Power,2005,21(3):546-551.
[4]	邢菲.级间驻涡燃烧室燃烧组织及性能优化研究[D].北京:北京航空航天大学,2009. XING Fei.Research on combustion organization and performance optimization of trapped vortex combustor between blades of turbine[D].Beijing:Beijing University of Aeronautics and Astronautics,2009.(in Chinese)
[5]	Liew K H,Urip E,Yang S L.Performance cycle analysis of turbofan engine with interstage turbine burner[J].Journal of Propulsion and Power,2006,22(2):411-416.
[6]	Siow Y K,Yang S L.Numerical study and of interstage turbine burner[R].AIAA 2002-3727,2002.
[7]	Lee A S,Singh R,Probert S D.Two-combustor engines performances under design and off-design conditions[R].AIAA 2009-4838,2009.
[8]	Hsu K Y,Goss L P.Performance of a trapped-vortex combustor[R].AIAA-95-0810,1995.
[9]	Roquemore W M,Shousese D,Burrus D,et al.Trapped vortex combustor concept for gas turbine engines[R].AIAA 2001-0483,2001.
[10]	张荣春,樊未军,邢菲.涡轮级间单涡燃烧室壁温研究[J].航空动力学报,2010,25(7):1512-1517. ZHANG Rongchun,FAN Weijun,XING Fei.Study of wall temperature on the interstage turbine single vortex combustor[J].Journal of Aerospace Power,2010,25(7):1512-1517.(in Chinese)
[11]	张韬,宋双文,樊未军.双涡/贫油驻涡燃烧室的贫油熄火特性试验[J].航空动力学报,2011,26(6):1328-1333. ZHANG Tao,SONG Shuangwen,FAN Weijun.Experimental study on lean-blow-out of double/fuel-lean trapped vortex combustor[J].Journal of Aerospace Power,2011,26(6):1328-1333.(in Chinese)
[12]	孙晓霞.超声波雾化喷嘴的研究进展[J].工业炉,2004,26(1):19-23. SUN Xiaoxia.Recent research advances of ultrasonic atomizer[J].Industrial Furnace,2004,26(1):19-23.(in Chinese)
[13]	侯凌云,侯晓春.喷嘴技术手册[M].北京:中国石化出版社,2002.
[14]	金义,何小民,吴泽俊,等.超声波/离心组合喷嘴性能研究[J].航空动力学报,2012,27(2):335-342. JIN Yi,HE Xiaomin,WU Zejun,et al.Investigation on the performance of an ultrasonic/pressure-swirt hybrid injector[J].Journal of Aerospace Power,2012,27(2):335-342.(in Chinese)
[15]	梁荣,党新安,赵小娟.超声波雾化喷嘴的设计[J].上海有色金属,2006,27(4):14-17. LIANG Rong,DANG Xinan,ZHAO Xiaojuan.Research on design of ultrasonic atomizer[J].Shanghai Nonferrous Metals,2006,27(4):14-17.(in Chinese)
[16]	张荣春,樊未军,宋双文.驻涡燃烧室蒸发管供油装置的雾化蒸发性能试验[J].航空动力学报,2011,26(11):2495-2502. ZHANG Rongchun,FAN Weijun,SONG Shuangwen.Atomization and evaporation performance experiment of evaporating tube for trapped vortex combustor[J].Journal of Aerospace Power,2011,26(11):2495-2502.(in Chinese)
[17]	中国航空工业总公司.HB 7485—97燃烧室性能试验[S].北京:中国航空工业总公司,1997.
[18]	中华人民共和国航空工业部.HB 6117—87航空燃气涡轮发动机气态污染物的连续取样及测量程序规范[S].北京:中华人民共和国航空工业部,1987.
