一种考虑齿轮副连续啮合过程的接触有限元动力学分析方法

吴勇军; 王建军

一种考虑齿轮副连续啮合过程的接触有限元动力学分析方法

北京航空航天大学能源与动力工程学院, 北京 100191

计量
- 文章访问数: 1972
- HTML浏览量: 237
- PDF量: 1282
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-02
- 刊出日期: 2013-05-28

A contact finite element method for dynamic analysis of continuous engaged gear pairs

School of Energy and Power Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 在系统分析齿轮副连续啮合过程不同典型啮合状态特点的基础上,提出了一种可以考虑齿轮副连续啮合过程中啮合齿对变化,受载弹性变形以及滑动摩擦等影响因素的接触有限元分析方法.利用该方法对三种考虑不同因素的齿轮副模型进行了对比分析,并得到了各种因素对齿轮副连续啮合过程动态传递误差及动态接触力特性的影响.研究表明:该方法可以真实模拟齿轮副连续啮合过程中单、双齿对啮合及其交替啮合状态的动力学特性,包括滑动摩擦引起的节点冲击,受载弹性变形引起的啮入、啮出冲击以及时变刚度等激励特性;并可以得到啮入、啮出冲击的大小及作用时间,以及滑动摩擦和齿廓修形对动态啮合特性的影响;动态啮合特性分析结果与齿轮副连续啮合状态的特征完全吻合.
- 齿轮副 /
- 动态啮合特性 /
- 接触有限元分析方法 /
- 时变刚度 /
- 啮合冲击 /
- 滑动摩擦
Abstract: Based on the analysis of the characteristics for different typical meshing states, a dynamic contact finite element analysis method, considering the variation of the engaged tooth pairs, the loaded elastic deformations and the sliding friction, was presented for the continuous engaged gear pairs. Then the dynamic transmission errors and the dynamic contact force for three kinds of continuous engaged gear models were compared using the presented method, and the effects of each factor on the dynamic meshing characteristics were obtained. The results show that the presented method is effective on simulating the more actual dynamic meshing characteristics of continuous engaged gear pairs in single or double tooth pair contact, including the pitch point impact caused by sliding friction, the meshing impact and the time-varying meshing stiffness excitation caused by elastic deformation. The impact force and time of the approach and recess meshing impact, the influence of the sliding friction and tooth profile modification on dynamic meshing characteristics were also obtained by the presented method. And the dynamic meshing characteristics gotten from the presented method is quite accordant with the characteristics of the continuous engaged gear drives for typical meshing states.
- gear pairs /
- dynamic meshing characteristics /
- contact finite element analysis(FEA) method /
- time-varying meshing stiffness /
- meshing impact /
- sliding friction

HTML

参考文献(18)

[1]	李润方,王建军.齿轮系统动力学[M].北京:科学出版社,1997.
[2]	WANG Jianjun,LI Runfang,PENG Xianghe.A survey to non-linear vibration of gear transmission system[J].Journal of Applied Mechanics Review,2003,56(3):309-329.
[3]	Kahraman A,Singh R.Non-linear dynamics of a spur gear pair[J].Journal of Sound and Vibration,1990,142(1):49-75.
[4]	Vaishya M,Singh R.Analysis of periodically varying gear mesh systems with coulomb friction using Floquet theory[J].Journal of Sound and Vibration.2001,243(3):525-545.
[5]	李润方,陶泽光,林腾蛟,等.齿轮啮合内部激励数值模拟[J].机械传动,2001,25(2):1-3. LI Runfang,TAO Zeguang,LIN Tengjiao,et al.Numerical simulation for inner dynamic excitation of gearing[J].Mechanical Transmission,2001,25(2):1-3.(in Chinese)
[6]	林腾蛟,杨妍妮,李润方,等.弧齿锥齿轮传动内部动态激励数值仿真[J].重庆大学学报,2009,32(6):609-613. LIN Tengjiao,YANG Yanni,LI Runfang,et al.Numerical simulation of the internal dynamic excitation of a spiral bevel gear transmission[J].Journal of Chongqing University,2009,32(6):609-613.(in Chinese)
[7]	HE Song,Gunda R,Singh R.Effect of sliding friction on the dynamics of spur gear pair with realistic time-varying stiffness[J].Journal of Sound and Vibration.2007,301(3/4/5):927-949.
[8]	欧垣安,李润方,龚剑霞. 三维冲击:动力接触问题的有限元混合算法[J].重庆大学学报,1994,17(2):52-57. OU Hengan,LI Runfang,GONG Jianxia.A mixed finite element algorithm of three-dimensional impact-dynamic contact problems[J]. Journal of Chongqing University,1994,17(2):52-57.(in Chinese)
[9]	LIN Tengjiao,LI Runfang,CHEN Bingkui,et al.Nonlinear dynamic contact analysis of meshing gears[C]//Proceedings of The International Conference on Mechanical Transmission (ICMT2001).Chongqing,China:Chongqing University,2001:248-251.
[10]	LIN Tengjiao,OU Hengan,LI Runfang.A finite element method for 3D static and dynamic contact/impact analysis of gear drives[J].Computer Methods in Applied Mechanics and Engineering,2007,196(9/10/11/12):1716-1728.
[11]	Bajer A,Demkowicz L.Dynamic contact/impact problems,energy conservation,and planetary gear trains[J].Computer Methods in Applied Mechanics and Engineering,2002,191(37/38):4159-4191.
[12]	Lundvall O,Stromberg N,Klarbing A.A flexible multi-body approach for frictional contact in spur gears[J].Journal of Sound and Vibration,2004,278(3):479-499.
[13]	Parker R G,Vijayakar S M,Imajo T.Non-linear dynamic response of a spur gear pair: modelling and experimental comparisons[J].Journal of Sound and Vibration,2000,237(3):435-455.
[14]	Parker R G,Agashe V,Vijayakar S M.Dynamic response of a planetary gear system using a finite element/contact mechanics model[J].Transactions of the ASME,2000,122(3):304-310.
[15]	Ambarisha V K,Parker R G.Nonlinear dynamics of planetary gears using analytical and finite element method[J].Journal of Sound and Vibration,2007,302(3):577-595.
[16]	HU Yumei,SHAO Yimin,CHEN Zaigang,et al.Transient meshing performance of gears with different modification coefficients and helical angles using explicit dynamic FEA[J].Mechanical System and Signal,2011,25(5):1786-1802.
[17]	王勖成.有限单元法[M].北京:清华大学出版社,2010.
[18]	孙桓, 陈作模.机械原理[M].6版.北京:高等教育出版社, 2003.
