非线性谐波法在双级对转压气机中的进一步校检

刘波; 王雷; 黄建

非线性谐波法在双级对转压气机中的进一步校检

西北工业大学动力与能源学院, 西安 710072

基金项目: 国家自然科学基金(51236006)

计量
- 文章访问数: 1625
- HTML浏览量: 117
- PDF量: 969
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-27
- 刊出日期: 2013-06-28

Further validation of NHM in two-stage counter-rotating compressor

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 以双级对转压气机为研究对象,在与试验结果及常规非定常方法对比的基础上,对新型非定常模拟方法——非线性谐波法(NHM)进行了时域和频域中的校检分析,探索其相比常规非定常方法的适用性.研究结果表明:非线性谐波法在设计工况下能够较为可靠地模拟确定应力的大小及其分布规律,具有较高的建模精度.对于近失速状态,由于流场中的固有周期性被破坏,导致非线性谐波法在该工况下不再适用,其与常规非定常模拟结果存在明显差异.
- 非线性谐波法 /
- 对转 /
- 动-动干涉 /
- 确定应力 /
- 适用性
Abstract: The nonlinear harmonic method (NHM) has been used to examine and analyze the unsteady rotor-rotor interaction of the two-stage counter-rotating compressor.To validate the NHM simulation results,the predicted characteristics of aerodynamic parameters were compared with the measured data and rigorous full-annulus unsteady simulations at typical working conditions.Based on the NHM deterministic stresses have been post-processed to compare to the full-annulus simulation to analyze distinct sources of unsteadiness.The NHM deliver accurate results at design points compared to full annulus results.The limits of the NHM are reached as soon as rotating stall effects occur as the theory foundation of the NHM,Fourier transformation,is no longer valid.
- nonlinear harmonic method (NHM) /
- counter-rotating /
- rotor-rotor interaction /
- deterministic stress /
- suitability

HTML

参考文献(19)

[1]	He L.Method of simulating unsteady turbomachinery flows with multiple perturbations[J].AIAA Journal,1992,30(11):2730-2735.
[2]	Srivastava R,Bakhle M,Keith T G.Numerical simulation of aerodynamic damping for flutter analysis of turbomachinery blade rows[J].Journal of Propulsion and Power,2003,19(2):60-267.
[3]	Bakhle M,Thomas J,Reddy T.Fan flutter computations using the harmonic balance method.AIAA-2008-4743,2008.
[4]	He L,Chen T,Wells R G,et al.Analysis of rotor-rotor and stator-stator interferences in multi-stage turbomachines[J].Journal of Turbomachinery,2002,124(4):564-571.
[5]	Ning W,He L.Some modeling issues on trailing-edge vortex shedding[J].AIAA Journal,2001,39(5):787-793.
[6]	He L,Li Y S,Wells R G.Predicting bladerow interactions using a multistage time-linearized Navier-Stokes solver[J].Journal of Turbomachinery,2003,25(1):25-32.
[7]	Van der Weide E,Gopinath G,Jameson A.Turbomachinery applications with the time spectral method[R].AIAA-2005-4905,2005.
[8]	Im D K,Kwon J H,Park S H.Periodic unsteady flow analysis using a diagonally implicit harmonic balance method[J].AIAA Journal,2012,50(3):741-745.
[9]	Kwon H I,Yi S G,Im D K.Design of a low-noise open rotor using an implicit harmonic balance method[R].AIAA-2013-1090,2013.
[10]	Sicot F,Hassan D.A time-domain harmonic balance method for dynamic derivatives predictions[R].AIAA-2011-1242,2011.
[11]	赵军,柳阳威,刘宝杰.NASA67级非定常流场的频域分析[J].航空动力学报,2007,22(8):1371-1377. ZHAO Jun,LIU Yangwei,LIU Baojie.Frequency-domain analysis of NASA67 unsteady flow field[J].Journal of Aerospace Power,2007,22(8):1371-1377.(in Chinese)
[12]	Wang L,Liu B,Xiang X R,et al.Investigtion of the unsteady flow in a counter-rotating compresor using the nonlinear harmonic method[R].ISABE Paper-2011-1234,2011.
[13]	Hall E J.Aerodynamic modeling of multistage compressor flow fields:Part 2 modeling deterministic stresses[J].Journal of Aerospace Engineering,1998,212(2):91-107.
[14]	He L.Fourier modeling of steady and unsteady nonaxisymmetrical flows[J].Journal of Propulsion and Power,2006,22(2):197-201.
[15]	王雷,刘波.非线性谐波法在对转压气机中的校检分析[J].航空动力学报,2012,27(7):1448-1455. WANG Lei,LIU Bo.Validaton of nonlinear harmonic method in dual-stage counter-rotating compressor[J].Journal of Aerospace Power,2007,22(8):1371-1377.(in Chinese)
[16]	Chen Y Y,Liu B,Xuan Y,et al.A study of speed ratio affecting the performance of a contra-rotating axial compressor[J].Journal of Aerospace Engineering,2008,222(7):985-991.
[17]	He L.On circumferential phase-shift condition for turbomachinery aerodynamic and aeromechanical applications[R].AIAA-2005-0016,2005.
[18]	Hembera M,Loos A,Kau H P,et al.Comparing a 40 Mio gridpoints full-annulus computation with a 7 Mio gridpoints nonlinear harmonic computation[R].AIAA-2009-930,2009.
[19]	柳阳威,刘宝杰.跨音压气机确定应力场分析[J].航空学报,2007,28(增刊):1-6. LIU Yangwei,LIU Baojie.Analysis of deterministic stresses in a transonic compressor[J].Acta Aeronautica et Astronautica Sinica,2007,28(Sup.):1-6.(in Chinese)
