超声速磁流体加速实验及一维模型分析

张百灵; 陈峰; 李益文; 朱涛; 张杨

超声速磁流体加速实验及一维模型分析

张百灵¹,
陈峰^1,2,
李益文¹,
朱涛^1,3,
张杨¹

1.
空军工程大学工程学院等离子体动力学重点实验室, 西安 710038
2.
中国空气动力研究与发展中心高速空气动力学研究所, 四川绵阳 622661
3.
中国人民解放军94710部队, 江苏无锡 214141

基金项目: 国家自然科学基金(10972236)

计量
- 文章访问数: 1929
- HTML浏览量: 140
- PDF量: 939
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-10
- 刊出日期: 2013-06-28

Experimental demonstration and one-dimensional model analysis of supersonic magnetohydrodynamic acceleration

1.
Science and Technology on Plasma Dynamics Laboratory, The Engineering Institute, Air Force Engineering University, Xi'an 710038, China
2.
High Speed Aerodynamics Research Institute, China Aerodynamics Research and Development Center, Mianyang Sichuan 622661, China
3.
Unit 94710, The Chinese People's Liberation Army, Wuxi Jiangsu 214141, China

摘要

摘要: 为了获得负载系数、电导率等参数变化对超声速磁流体加速效果的影响规律,利用激波风洞,采用氩气与碳酸钾作为工质,电容提供电能的方式,在磁感应强度为0.5T的条件下,进行了不同电容充电电压下的超声速磁流体加速实验研究,并对一维定常理想分段法拉第型磁流体加速模型进行了分析.通过实验获得了不同电容充电电压下#10电极间的电压、电流、负载系数、电导率及#20电极开路电压等数据,在300, 400V电容充电电压下,气流速度分别增加11.4%和24.0%,在500V电容充电电压下气流速度减小11.1%.实验及模型分析得出不同的负载系数会使超声速磁流体处于加速或减速的不同状态,而电导率会影响注入总能量的大小,使磁流体流动的速度梯度大小发生改变.
- 超声速 /
- 磁流体加速 /
- 负载系数 /
- 电导率 /
- 磁作用数
Abstract: In order to investigate the influence of load factor and conductivity on the performance of supersonic magnetohydrodynamic (MHD) accelerator.The experiments under the conditions of a magnetic field of 0.5 T and different voltages applied to capacitors were carried out,which used shock tunnel drive MHD accelerator,took Ar and potassium carbonate as the working fluid and capacitors as the power sources.And a one-dimensional steady ideal segmented Faraday type MHD accelerator model was analyzed.The voltages across electrodes, currents,load factors and conductivities at #10 electrodes,and open-circuit voltage at #20 electrodes were acquired from the experiments.The MHD flow velocity was increased by 11.4% and 24.0% respectively with capacitors charging voltages of 300 V and 400 V,while the velocity decreased by 11.1% with the voltage of 500 V.Experiments and model analysis show the different load factors would make the supersonic MHD flow into different modes,the conductivity influences the magnitude of the energy deposition,would make the velocity gradient of the magnetic fluid change.
- supersonic /
- magnetohydrodynamic acceleration /
- load factor /
- conductivity /
- magnetic interaction parameter

HTML

参考文献(15)

[1]	Fraishtadt V L,Kuranov A L,Sheikin E G.Use of MHD system in hypersonic aircraft[J].Technical Physics,1998,43:1309.
[2]	Litchford R J,Cole J W,Lineberry J T,et al.Magnetohydrodynamic augmented propulsion experiment:Ⅰ performance analysis and design[R].AIAA 2002-2184,2002
[3]	Lineberry J T,Rosa R J,Bityurin V A,et al.Prospects of MHD flow control for hypersonics[R].AIAA 2000-3057,2000.
[4]	于达仁,唐井峰,鲍文.用于高超声速推进的MHD-Ar-Ramjet联合循环[J].航空学报,2007,28(4):769-775. YU Daren,TANG Jingfeng,BAO Wen.MHD-arc-ramjet combined cycle for hypersonic propulsion[J].Acta Aeronautica et Astronautica Sinica,2007,28(4):769-775.(in Chinese)
[5]	郑小梅,杨兴宇.三维磁流体强化超燃冲压发动机数值模拟[J].航空动力学报,2012,27(10):2390-2400. ZHENG Xiaomei,YANG Xingyu.Simulation of three-dimensional magnetohydrodynamic enhanced scramjet[J].Journal of Aerospace Power,2012,27(10):2390-2400.(in Chinese)
[6]	Gurijanov E P,Harsha P T.AJAX:new directions in hypersonic technology[R].AIAA 1996-4609,1996.
[7]	Kuranov A L,Sheikin E G.Magnetodydrodynamic control on hypersonic aircraft under "AJAX" concept[J].Journal of Spacecraft and Rockets,2003,40(2):174-182.
[8]	毛根旺,唐金兰.航天器推进系统及其应用[M].西安:西北工业大学出版社,2009.
[9]	王新月,胡春波,张堃元,等.气体动力学基础[M].西安:西北工业大学出版社,2006.
[10]	李益文,李应红,张百灵,等.基于激波风洞的超声速磁流体动力技术实验系统[J].航空学报,2011,32(6):1015-1024. LI Yiwen,LI Yinghong,ZHANG Bailing,et al.Supersonic magnetohydrodynamic (MHD) technical experimental system based on shock tunnel[J].Acta Aeronautica et Astronautica Sinica,2011,32(6):1015-1024.(in Chinese)
[11]	陈强.激波管流动的理论和实验技术[M].北京:高等教育出版社,1979.
[12]	李益文,李应红,张百灵,等.超声速气流磁流体加速初步实验研究[J].力学学报,2012,44(2):238-244. LI Yiwen,LI Yinghong,ZHANG Bailing,et al.Preliminary experimental investigation on supersonic flow magnetohydrodynamic (MHD) acceleration[J].Chinese Journal of Theoretial and Applied Mechanics,2012,44(2):238-244.(in Chinese)
[13]	Bogdanoff D W,Mehta U B.Experimental demonstration of magneto-hydro-dynamic(MHD) acceleration[R].AIAA 2003-4285,2003.
[14]	郑小梅.高超声速飞行器磁流体技术数值模拟研究[D].北京:北京航空航天大学,2010. ZHENG Xiaomei.Numerical investigation of the MHD technology in hypersonic vehicle application[D].Beijing:Beijing University of Aeronauics and Astronautics,2010.(in Chinese)
[15]	陈峰,张百灵,张杨,等.电弧放电诱导喷气流偏转数值模拟研究[J].空军工程大学学报,2012,13(4):11-15. CHEN Feng,ZHANG Bailing,ZHANG Yang,et al.Numerical simulation of arc discharge induction jet flow deflection[J].Journal of Air Force Engineering University,2012,13(4):11-15.(in Chinese)
