离子发动机羽流特性的数值模拟

任军学; 顾左; 郭宁; 仇钎; 汤海滨

离子发动机羽流特性的数值模拟

1.
北京航空航天大学宇航学院, 北京 100191
2.
兰州物理研究所真空低温技术与物理重点实验室, 兰州 730000

基金项目: 国家自然科学基金(10805004)

计量
- 文章访问数: 1731
- HTML浏览量: 188
- PDF量: 1068
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-14
- 刊出日期: 2013-06-28

Numerical simulation of characteristics of ion thruster plume

1.
School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Science and Technology on Vacuum and Cryogenics Technology and Physics Laboratory, Lanzhou Institute of Physics, Lanzhou 730000, China

摘要

摘要: 离子发动机羽流中产生的交换电荷(CEX)离子返流会影响航天器的正常工作.建立离子发动机羽流模型,采用单元内粒子方法(PIC)对羽流场进行数值模拟计算.结合DS-1探测器飞行实验的测量结果,分析了卫星电势、电子温度、卫星几何尺寸、推力器工作特性等对相关因素对CEX离子返流特性的影响.结果表明:从推力器出口附近到卫星背面,CEX离子密度为10⁸~10¹²m^-3.当卫星电势从-15V变化到27V,测量点位置处CEX离子密度从0.65×10¹²m^-3变化到1.5×10¹²m^-3.羽流中CEX离子密度和电势结构随电子温度变化不大,但电势大小随电子温度成比例地变化.同一位置处不同工况下CEX离子的密度可根据CEX离子生成率与工作点参数间的关系式准确地估计.卫星安装推力器的表面起着对CEX离子返流屏蔽和降低的作用.
- 离子发动机 /
- 羽流 /
- 单元内粒子 /
- 交换电荷离子 /
- 数值模拟
Abstract: The back flow of charge-exchange (CEX) ions in the ion thruster plume affects normal operation of the satellite.The ion thruster plume model was established and a numerical simulation using particle-in-cell (PIC) method was adopted to obtain CEX ions distribution in the plume.The simulation results agree well with the flight measurement results of deep space one spacecraft.Influential factors to the distribution characteristic of CEX ions surrounding the spacecraft were analyzed,including:spacecraft potential,electron temperature,thruster operation parameter and size of spacecraft.It shows that CEX ion density surrounding the spacecraft varies from 10⁸m^-3 to 10¹²m^-3.The CEX ion density in the measurement point varies from 0.65×10¹²m^-3 to 1.5×10¹²m^-3 when the spacecraft potential varies from -15V to 27V.The distribution of CEX ion density and electrical potential structure varies slightly with the electronic temperature.However,the magnitude of the electrical potential is proportional to the electronic temperature.The CEX ion density at different thruster operation points can be induced accurately according to the relationship between the CEX ion generation rate and the thruster's operation parameter.The surface of the spacecraft onto which the thruster is installed in fact shields the backflow of CEX ions.
- ion thruster /
- plume /
- particle in cell /
- charge-exchange(CEX) ion /
- numerical simulation

HTML

参考文献(15)

[1]	Wang J,Brinza D,Young M.Three-dimensional particle simulation modeling of ion propulsion plasma environment for deep space 1[J].Journal of Spacecraft and Rockets,2001,38(3):433-440.
[2]	Samanta R I,Hastings D E,Gatsonis N A.Ion-thruster plume modeling for backflow contamination[J].Journal of Spacecraft and Rockets,1996,33(4):525-534.
[3]	Samanta R I,Hastings D E,Taylor S.Three-dimensional plasma particle-in-cell calculations of ion thruster backflow contamination[J].Journal of Computation Physics,1996,128(1):6-18.
[4]	Wang J,Brinza D,Young M,et al.Deep space 1 investigations of ion propulsion plasma environment[J].Journal of Spacecraft and Rockets,2000,37(5):545-555.
[5]	Brinza D,Wang J,Polk J,et al.Deep space 1 measurements of ion propulsion contamination[J].Journal of Spacecraft and Rockets,2001,38(3):426-432.
[6]	Van Gilder D B,Font G I,Boyd I D.Hybrid Monte Carlo-particle-in-cell simulation of an ion thruster plume[J].Journal of Propulsion and Power,1999,15(4):530-538.
[7]	Fergason S D.Ion thruster plume simulation using clustered PC workstations[R].AIAA 2005-966,2005.
[8]	Mandell M J,Kuharski R A,Gardner B M et al.Ion engine plume interaction calculations for prototypical prometheus 1[R].AIAA 2005-4047,2005.
[9]	Polk J E,Anderson J R,Brophy J R.An overview of the results from 8200 hour wear test of the NSTAR Ion thruster[R].AIAA 99-2446,1999.
[10]	Wang J,Cao Y,Kafafy R,et al.Simulations of ion thruster plume-spacecraft interactions on parallel supercomputer[J].IEEE Transactions on Plasma Science,2006,34(5):2148-2158.
[11]	Mikellides G,Kuharski R A,Mandell M J,et al.Assessment of spacecraft systems integration using the electric propulsion interaction code(EPIC)[R].AIAA 2002-3667,2002.
[12]	Hilgers A,Thiebault B,Estublier,et al.A simple model of SMART-1 electric potential variation[J].IEEE Transactions on Plasma Science,2006,34(5):2159-2165.
[13]	UranakaT M,Hosoda S,Kim J H,et al.Development of multi-utility spacecraft charging analysis tool (MUSCAT)[J].IEEE Transactions on Plasma Science,2008,36(5):2336-2349.
[14]	任军学,王艳,仇钎,等.离子发动机羽流二维轴对称数值模型与验证[J].北京航空航天大学学报,2011,37(12):189-194. REN Junxue,WANG Yan,QIU Qian,et al.Validation of two-dimensional axisymmetric plume model for ion thruster[J].Journal of Beijing University of Aeronautics and Astronautics,2011,37(12):189-194.(in Chinese)
[15]	钟凌伟,刘宇,任军学,等.离子发动机栅极系统中束流离子的三维模拟[J].航空动力学报,2010:25(9):2125-2131. ZHONG Lingwei,LIU Yu,Ren Junxue,et al.Three dimensional simulation of beam ions in ion thruster optics system[J].Journal of Aerospace Power,2010:25(9):2125-2131.(in Chinese)
