某型燃气轮机燃烧室出口温度场的调试

刘凯; 张宝诚; 马洪安

某型燃气轮机燃烧室出口温度场的调试

沈阳航空航天大学航空航天工程学部, 沈阳 110136

基金项目: 国家高技术研究发展计划(2002AA503010)

计量
- 文章访问数: 1637
- HTML浏览量: 112
- PDF量: 884
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-06
- 刊出日期: 2013-06-28

Experiment on outlet temperature field of a gas turbine combustor

Department of Aerospace Engineering, Shenyang Aerospace University, Shenyang 110136, China

摘要

摘要: 试验研究了某型燃气轮机燃烧室掺混孔孔径比、相对孔距对出口温度场的影响.试验结果表明:随孔径比的增加,出口温度分布系数逐渐减小,但过大的孔径比易形成局部阻塞,使热点温度升高;孔径比对径向温度分布系数影响较小,仅使温度分布曲线位置移动而不会改变其形状.相对孔距与径向温度分布系数相关性较强,过大(大于0.33)、过小(小于0.29)均不利于掺混.该研究情况下,相对孔距为0.31、孔径比为0.32左右基本合理.
- 燃气轮机 /
- 燃烧室 /
- 掺混孔 /
- 出口温度场 /
- 射流
Abstract: The influence of aperture ratio and center distance of a gas turbine combustor mixing system on outlet temperature field was studied experimentally.Experimental results indicate:the outlet temperature distribution coefficient reduces gradually with the increase of aperture ratio.But too large aperture ratio will lead to partial obstruction and also hot spot temperature rise;aperture ratio does not change the radial temperature distribution curve shape,but only bring about shift of its position.Relative center distance and the radial temperature distribution coefficient have a strong correlation,too large (more than 0.33) or too small (less than 0.29) is not helpful for dilution.Relative center distance of 0.31 and aperture ratio of 0.32 are basically reasonable in this case.
- gas turbine /
- combustor /
- dilution hole /
- outlet temperature field /
- jet

HTML

参考文献(15)

[1]	张宝诚.航空发动机试验和测试技术[M].北京:北京航空航天大学出版社,2005.
[2]	Maurya D,Jayaprakash G N. Challenges in aero gas turbine combustor development[J].ASME Paper GT2009-59429.
[3]	胡好生,赵坚行.一种新颖的燃烧室出口温度场调试方法[J].航空动力学报,2007,22(8):1222-1226. HU Haosheng,ZHAO Jianxing.A new adjustment method of combustor outlet temperature field[J].Journal of Aerospace Power,2007,22(8):1222-1226.(in Chinese)
[4]	张征,杨阳,樊未军,等.掺混孔参数影响燃烧室出口温度场的计算方法[J].燃烧科学与技术,2006,12(6):502-506. ZHANG Zheng,YANG Yang,FAN Weijun,et al.Calculation methods of main impact factor to exit temperature of turbine combustor[J].Journal of Combustion Science and Technology,2006,12(6):502-506.(in Chinese)
[5]	彭云晖,林宇震,刘高恩.三旋流器燃烧器燃烧室出口温度分布的初步试验研究[J].航空动力学报,2007,22(4):554-558. PENG Yunhui,LIN Yuzhen,LIU Gaoen.A preliminary experimental study of pattern factor for a triple swirle combustor[J].Journal of Aerospace Power,2007,22(4):554-558.(in Chinese)
[6]	Lefebvre A H.Gas turbine combustion[M].Washington:Taylor & Francis Press,1998.
[7]	Mori G,Razore S,Ubaldi M,et al.Integrated experimental and numerical approach for fuel-air mixing prediction in a heavy-duty gas turbine LP burner[J].Journal of Engineering for Gas Turbine and Power,2001,123(4):803-809.
[8]	Mohammad B S,Cai J,Jeng S M.Gas turbine combustor flow structure control through modification of the chamber geometry[J].Gas Turbines Power,2011,133(2):324-331.
[9]	Masi M,Gobbato P,Toffolo A,et al.Numerical and experimental analysis of the temperature distribution in a hydrogen fuelled combustor for a 10 MW gas turbine[J].Journal of Engineering for Gas Turbines and Power,2011,133(2):432-440.
[10]	Sierra F Z,Kubiak J,Gonzalez G,et al.Prediction of temperature front in a gas turbine combustion chamber[J].Applied Thermal Engineering,2005,25(8/9):1127-1140.
[11]	Maughan J R,Elward K M,De Pietro S M,et al.Field test results of a dry low NOx combustion system for the MS3002J regenerative cycle gas turbine[J].Journal of Engineering for Gas Turbines and Power,1997,119(1):50-57.
[12]	Barringer M D,Thole K A,Polanka M D.Effects of combustor exit profiles on vane aerodynamic loading and heat transfer in a high pressure turbine[J].Journal of Turbomachinery,2009,131(2):021008.1-021008.10.
[13]	Qureshi I,Beretta A,Povey T.Effect of simulated combustor temperature nonuniformity on HP vane and end wall heat transfer:an experimental and computational investigation[J].Journal of Engineering for Gas Turbines and Power,2011,133(3):031901.1-031901.13.
[14]	Povey T,Chana K S,Jones T V,et al.The effect of hot-streaks on HP vane surface and endwall heat transfer:an experimental and numerical study[J].Journal of Turbomachinery,2007,129(1):32-43.
[15]	Stickles R W,Dodds W J,Koblish T R,et al.Innovative high-temperature aircraft engine fuel nozzle design[J].Journal of Engineering for Gas Turbines and Power,1993,115(3):439-446.
