基于T-S模糊模型的航空发动机非线性分布式控制系统故障诊断

翟旭升; 谢寿生; 苗卓广; 彭靖波; 张子阳; 王磊

基于T-S模糊模型的航空发动机非线性分布式控制系统故障诊断

1.
空军工程大学航空航天工程学院, 西安 710038
2.
空军第一航空学院航空机械工程系, 河南信阳 464000

基金项目: 中国博士后科学基金(20100481498)

计量
- 文章访问数: 1688
- HTML浏览量: 119
- PDF量: 1030
- 被引次数: 0
出版历程
- 收稿日期: 2012-06-27
- 刊出日期: 2013-06-28

Fault detection of aero-engine non-linear distributed control system based on T-S fuzzy model

1.
The Aeronautical and Astronautical Engineering Institute, Air Force Engineering University, Xi'an 710038, China
2.
The Aero-Mechanical Engineering Department The First Aeronautical College of Air Force, Xinyang Henan 464000, China

摘要

摘要: 针对航空发动机非线性分布式控制系统的故障诊断问题,首先提出了一种基于飞行包线划分的航空发动机非线性Takagi-Sugeno(T-S)建模方法,建立了具有网络诱导时延的航空发动机非线性分布式控制系统模型,然后将该系统视为离散切换系统,为其建立了具有时延补偿功能的故障观测器,给出了使得观测器误差系统渐近稳定的充分条件.故障检测仿真时间为20s,当第12s时,设定系统发生幅值为0.0025的阶跃型突变故障,仿真结果表明:12s之前,故障观测器保持渐近稳定,当第12s时,残差迅速增大并超过所设定阈值,从而检测到故障的发生.
- 时延 /
- T-S模糊模型 /
- 飞行包线 /
- 隶属度函数 /
- 故障检测
Abstract: The problem of fault detection for aero-engine no-liner distributed control system was studied.Firstly,a new non-linear modeling method for aero-engine based on Takagi-Sugeno(T-S) fuzzy model and flight envelop division was proposed,and the model of the distributed control system with network derivational time-delay was established by using this method.Secondly,if the distributed control system was regarded as a discrete switch system,a fault detection observer with time-delay compensation was designed,and the sufficient conditions of asymptotically stability for the observer-based residual system were presented.The total simulation took 20 seconds, a step fault with 0.0025 amplitude happened at the 12th second, the simulation results show that: the fault observer was asymptotic stable for preceding 12 seconds, and the residuals rapidly increased and exceeded the threshold value at the 12th second, thereby the fault would be detected.
- time-delay /
- T-S fuzzy model /
- flight envelop /
- membership function /
- fault detection

HTML

参考文献(16)

[1]	Culley D E,Thomas R,Saus J.Concepts for distributed engine control[R].AIAA-2007-5709,2007.
[2]	Pakmehr M,Mounier M,Fitzgerald N,et al.Distributed control of turbofan engines[R].AIAA-2009-5532,2009.
[3]	Yedavalli R K,Belapurkar R K,Behbahani A R.Stability analysis of distributed engine control systems under communication packet drop.AFRL-RZ-WP-TP-2008-2189,2008.
[4]	郭迎清,章泓.航空发动机分布式控制系统综述[J].航空发动机,2003,29(3):52-55. GUO Yingqing,ZHANG Hong.Survey of the distribute control system for an aero-engine[J].Aeroengine,2003,29(3):52-55.(in Chinese)
[5]	何鹄环,郭迎清.基于DSP和CAN的航空发动机分布式控制系统设计[J].航空计算技术,2006,36(1):30-32. HE Huhuan,GUO Yingqing.Design of distributed control system for aero-engines based on DSP and CAN[J].Aeronantical Computing Technique,2006,36(1):30-32.(in chinese)
[6]	黄金泉,徐科.航空发动机分布式控制系统结构分析[J].航空动力学报,2003,18(5):698-704. HUANG Jinquan,XU Ke.A survey of distributed control systems for aero-engines[J].Journal of Aerospace Power,2003,18(5):698-704.(in Chinese)
[7]	吴勇.基于分布式系统的航空发动机综合控制研究[D].西安:空军工程大学,2010. WU Yong.Research of aero-engine integrated control based on DCS[D].Xi'an:Air Force Engineering University,2010.(in Chinese)
[8]	蔡开龙,谢寿生,吴勇.基于T-S模糊模型的航空发动机模型辨识[J].推进技术,2007,28(2):194-198. CAI Kailong,XIE Shousheng,WU Yong.Identification of aero-engines model based on T-S fuzzy mode [J].Journal of Propulsion Technology,2007,28(2):194-198.(in Chinese)
[9]	许哲,许化龙.基于T-S模糊模型的导弹网络化控制系统建模与控制[J].上海航天,2010,27(2):49-54. XU Zhe,XU Hualong.Model and control for missile networked control system based on T-S fuzzy model[J] Aerospace Shanghai,2010,27(2):49-54.(in Chinese)
[10]	许域菲,姜斌,齐瑞云,等.基于模糊T-S自适应观测器的近空间飞行器故障诊断与容错控制[J].东南大学学报,2009,39(增刊1):189-194. XU Yufei,JIANG Bin,QI Ruiyun,et al.T-S fuzzy adaptive observer based fault diagnosis and fault tolerant control for near space vehicle[J].Journal of Southeast University,2009,39(Sup.1):189-194.(in Chinese)
[11]	王宇雷,李传江,马广富.T-S模型和H_∞观测器在卫星故障诊断中的应用[J].哈尔滨工业大学学报,2010,42(9):1345-1350. WANG Yulei,LI Chuanjiang,MA Guangfu.Fault diagnosis of Takagi-Sugeno fuzzy systems using H_∞ observers in satellite attitude control[J].Journal of Harbin Institute of Technology,2010,42(9):1345-1350.(in Chinese)
[12]	黄鹤,谢德晓,张登峰,等.基于T-S 模糊模型的网络控制系统鲁棒H_∞容错控制[J].系统工程与电子技术,2010,32(6):1292-1297. HUANG He,XIE Dexiao,ZHANG Dengfeng,et al.T-S fuzzy model-based robust H_∞ fault tolerant control for networked control systems[J].Systems Engineering and Electronics,2010,32(6):1292-1297.(in chinese)
[13]	李炜,蒋栋年.基于T-S模糊模型的非线性网络化控制系统的H_∞鲁棒容错控制[J].控制与决策,2010,25(4):598-604. LI Wei,JIANG Dongnian.Robust H_∞ fault-tolerant control for nonlinear networked control system based on Takagi-Sugeno fuzzy model[J].Control and Decesion,2010,25(4):598-604.(in Chinese)
[14]	Takagi T,Sugeno M.Fuzzy identification of systems and its application to modeling and control[J].IEEE Transaction on Systems,Man,Cybernetics,1985,15(1):116-132.
[15]	胡卫红,李述清,孙健国.控制问题中航空发动机飞行包线区域最优划分[J].推进技术,2011,32(3):391-395. HU Weihong,LI Shuqing,SUN Jianguo.Flight envelope optimization partition for aeroengines control[J].Journal of Propulsion Technology,2011,32(3):391-395.(in Chinese)
[16]	张捷.网络控制系统的故障检测与诊断技术[D].南京:南京理工大学,2010. ZHANG Jie.Fault detection and diagnosis methods for networked control systems[D].Nanjing:Nanjing University of Science and Technology,2010.(in Chinese)
