发动机稳态与过渡态控制集成设计仿真验证

吴君凤; 郭迎清

发动机稳态与过渡态控制集成设计仿真验证

西北工业大学动力与能源学院, 西安 710072

基金项目: 航空基金(2011ZB53)

计量
- 文章访问数: 1932
- HTML浏览量: 163
- PDF量: 921
- 被引次数: 0
出版历程
- 收稿日期: 2012-09-21
- 刊出日期: 2013-06-28

Design and simulation of aero-engine steady-state and transient-state control integration

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 研究了某型涡扇发动机全飞行包线稳态与过渡态控制集成设计问题.首先利用根轨迹分析法和时域分析法设计了从慢车状态到最大状态的多个比例积分(PI)设定点控制器,并利用增益调参和换算参数得到了全飞行包线的稳态控制器参数.然后将加减速控制计划与稳态控制通过max/min逻辑进行集成,考虑了抗积分饱和功能及设计了相应的抗积分饱和模块,最后得到的集成控制系统在软件MATLAB/Simulink下进行了仿真验证.仿真结果表明集成控制系统稳态时抗扰动性能良好,过渡过程中曲线平滑,有效利用了各种限制条件还兼有抗积分饱和功能并且能进行平滑切换.
- 涡扇发动机 /
- 集成控制 /
- 加减速控制计划 /
- 抗积分饱和模块 /
- MATLAB/Simulink
Abstract: The issue of synthesizing steady-state and transient-state control laws for a turbofan engine was studied.Firstly,a number of steady-state point PI(proportional integral) controllers were designed using root locus analysis and time domain method from ground idle power to take-off power,and furthermore full flight envelope controllers were designed using interpolation method and corrected parameters.Secondly,the synthesis control system was acquired by integrating schedule-based transient control and steady-state control through max/min logic into which an anti wind-up module was added to cope with the influence of integrator wind-up.Finally,the synthesis control system was validated in software MATLAB/Simulink.The results indicate that the synthesis control system has the following advantages:(1) during steady-state,the anti-disturbance quality is good;(2) during transient-state,the response curve is flat;(3) the system uses a variety of restrictions effectively with both anti-windup and smooth switching functions.
- turbofan engine /
- integration control /
- schedule-based acceleration and deceleration control /
- anti wind-up module /
- MATLAB/Simulink

HTML

参考文献(15)

[1]	Jaw L C.Aircraft engine controls:design,system analysis,and health monitoring[M].Reston:AIAA,2009.
[2]	Mattingly J D,Heiser W H,Pratt D T.Aircraft engine design[M].2nd ed.Virginia,US:American Institute of Aeronautics,2002.
[3]	Spang Ⅲ A H,Brown H.Control of jet engines[J].Control Engineering Practice,1999,7(9):1043-1059.
[4]	DeCastro J A,Litt J S,Frederick D K.A modular aero-propulsion system simulation of a large commercial aircraft engine[R].AIAA 2008-4579,2008.
[5]	Martucci A,Volponi A J.Fuzzy fuel flow selection logic for a real time embedded full authority digital engine control[J].Journal of Engineering for Gas Turbine and Power,2003,125(4):909-916.
[6]	陆军,郭迎清,陈小磊.线性拟合法建立航空发动机状态变量模型[J].航空动力学报,2011,26(5):1172-1177. LU Jun,GUO Yingqing,CHEN Xiaolei.Establishment of aero-engine state variable model based on linear fitting method[J].Journal of Aerospace Power,2011,26(5):1172-1177.(in Chinese)
[7]	Kulikov G G,Thompson H A.Dynamic modeling of gas turbines-identification,simulation,condition monitoring and optimal control[M].London,UK:Springer-Verlag,2004.
[8]	姚华,蒋平国,孙健国.某型发动机数控系统的相似参数自适应控制研究[J].航空动力学报,2005,20(4):673-678. YAO Hua,JIANG Pingguo,SUN Jianguo.Investigation of corrected-parameter adaptive control for an aero-engine digital control system[J].Journal of Aerospace Power,2005,20(4):673-678.(in Chinese)
[9]	Thomas S R,David P S,Mark L,et al.Continuation methods for aircraft models subject to integrator wind-up.AIAA 2004-4946,2004.
[10]	Kapoor N,Teel A R.A dynamic windup compensation scheme applied to a turbofan engine[C]//Proceedings of the IEEE Conference on Decision&Control.Piscataway:IEEE,1997:4689-4694.
[11]	Watts S R,Garg S.An optimized integrator windup protection technique applied to a turbofan engine control[R].AIAA-1996-35695,1996.
[12]	Krishnakumar K,Garg S.Integrator windup protection-techniques and a STOVL aircraft engine controller application[R].AIAA-1996-35711,1996.
[13]	Martin S,Wallace I,Bates D G.Development and validation of a civil aircraft engine simulation model for advanced controller design[J].Journal of Engineering for Gas Turbines Power,2008,130(5):051601.1-051601.15.
[14]	陆军,郭迎清,王海泉.基于快速原型化的数控系统实时仿真平台研制[J].计算机测量与控制,2009,17(6):1098-1101. LU Jun,GUO Yingqing,WANG Haiquan.Digital electronic engine control real-time simulation platform based on rapid prototyping[J].Computer Measurement & Control,2009,17(6):1098-1101.(in Chinese)
[15]	Csank J,Ryan D M,Jonathan S L,et al.Control design for a generic commercial aircraft engine[R].AIAA 2010-6629,2010.
