空气节流对超燃冲压发动机燃烧室起动点火影响的数值研究

田野; 乐嘉陵; 杨顺华; 张弯洲; 邓维鑫

空气节流对超燃冲压发动机燃烧室起动点火影响的数值研究

1.
中国空气动力研究与发展中心吸气式高超声速技术研究中心, 四川绵阳 621000
2.
西南交通大学机械工程学院, 成都 610031

计量
- 文章访问数: 1652
- HTML浏览量: 14
- PDF量: 1204
- 被引次数: 0
出版历程
- 收稿日期: 2012-12-11
- 刊出日期: 2013-07-28

Numerical study on air throttling influence of ignition transient on the scramjet combustor

1.
Airbreathing Hypersonics Research Center, China Aerodynamics Research and Development Center, Mianyang Sichuan 621000, China
2.
School of Mechanical Engineering, Southwest Jiaotong University, Chengdu 610031, China

摘要

摘要: 利用空气节流在流场中产生激波串,有效地辅助燃料实现起动点火.非定常Navier-Stokes方程数值模拟研究了空气节流对超燃冲压发动机燃烧室起动点火的影响,分析了起动点火时间段(0~1.0ms)内空气节流对流场参数的影响.数值模拟结果表明:在燃烧室入口马赫数为2.0、静温为548.8K、静压为101555.9 Pa,乙烯燃料当量比为0.5,先锋氢辅助点火的条件下,距离发动机入口845mm处,节流流量为入口空气流量的30%,有效地实现了发动机的起动点火,无空气节流情况下的发动机点火效果不佳,火焰最终熄灭.
- 空气节流 /
- 起动点火 /
- 激波串 /
- 火焰稳定 /
- 超燃冲压发动机燃烧室
Abstract: A proper shock train generated by air throttling could facilitate ignition.The effects of air throttling on ignition transient were studied by solving unsteady Navier-Stokes equations, and the mechanism of air throttling for ignition was also analyzed during the ignition transient (0— 1.0ms ).Computational fluid dynamics results show that:under the inflow air conditions of Mach number 2.0,static temperature 548.8K,static pressure 101555.9Pa and the equivalence ratio 0.5,the pilot H₂ is used for ignition,the location of air throttling is 845mm from the combustor entrance,and the flux of air throttling is 30% mass flux of inflow air. Ignition is achieved by air throttling, and flame goes out without air throttling at last.
- air throttling /
- ignition transient /
- shock train /
- flame stabilization /
- scramjet combustor

HTML

参考文献(15)

[1]	Itoh K.Study on scramjet engine characteristics under Mach 8 to 15 conditions [R].Cologne,Gemay:Proceedings of the 5th European Symposium on Aerothermodynamics for Space Vehicles,SP-563,ESA,2004.
[2]	Lavante V E,Zeitz D,Kallenberg M.Numerical simulation of supersonic airflow with transverse hydrogen injection[J].Journal of Propulsion and Power,2001,17(6):1319-1326.
[3]	Ghislain J R,Samuel K,Siddhartha V,et al.Experimental studies of cavity flame-holding in a Mach 2.5 cross flow [R].AIAA-2009-810,2009.
[4]	Hsu K Y,Carter C D,Gruber M R,et al.Experimental study of cavity-strut combustion in supersonic flow[J].Journal of Propulsion and Power,2010,26(6):1237-1246.
[5]	Tarun M,Mark G,Kevin J,et al.Supersonic combustion experiments with a cavity-based fuel injector[J].Journal of Propulsion and Power,2001,17(6):1305-1312.
[6]	Ben Y A,Hanson R K.Cavity flameholders for ignition and flame stabilization in scramjets:an overview[J].Journal of Propulsion and Power,2001,17(4):869-877.
[7]	Mathur T,Gruber M R,Jackson K,et al.Supersonic combustion experiments with a cavity-based fuel injector[J].Journal of Propulsion and Power,2001,17(6):1305-1312.
[8]	Tomoaki K,Atsushi M,Koichi M,et al.Ignition characteristics of methane and hydrogen using a plasma torch in supersonic flow[J].Journal of Propulsion and Power,2003,19(5):853-858.
[9]	田野,乐嘉陵,杨顺华,等.空气节流对超燃燃烧室流场结构和燃料混合影响的数值研究[J].推进技术,2013,34(1):54-61. TIAN Ye,LE Jialing,YANG Shunhua,et al.Numerical study on air throttling influence of flow structure and fuel-air mixing in scramjet combustor[J].Journal of Propulsion Technology,2013,34(1):54-61.(in Chinese)
[10]	Jeong-Yeol C,Jinhyeon N,Jong-Ryul B,et al.Numerical investigation of combustion/shock-train interactions in a dual-mode scramjet engine [R].AIAA-2011-2395,2011.
[11]	Jian L,Fuhua M,Vigor Y,et al.A comprehensive study of ignition transient in an ethylene-fueled scramjet combustor[R].AIAA-2007-5025,2007.
[12]	Kuo C L,Chung J T,Campbell C,et al.Flame characteristics and fuel entrainment inside a cavity flame holder in a scramjet combustor [R].AIAA-2007-5381,2007.
[13]	邢建文,杨样.H₂O污染对超燃冲压发动机燃烧室性能影响的三维数值模拟[J].推进技术,2011,32(1):5-10. XING Jianwen,YANG Yang.Three-dimensional simulation of H₂O vitiation effects on combustor performance for scramjet[J].Journal of Propulsion Technology,2011,32(1):5-10.(in Chinese)
[14]	杨顺华.碳氢燃料超燃冲压发动机数值研究 [D].四川绵阳:中国空气动力研究与发展中心,2006. YANG Shunhua.Numerical study of hydrocarbon fueled scramjets [D].Mianyang Sichuan:China Aerodynamics Research and Development Center,2006.(in Chinese)
[15]	赵慧勇.超燃冲压整体发动机并行数值研究 [D].四川绵阳:中国空气动力研究与发展中心,2005. ZHOU Huiyong.Parallel numerical study of whole scramjet engine [D].Mianyang Sichuan:China Aerodynamics Research and Development Center,2005.(in Chinese)
