一种实现轴流压气机试验特性关联的经验方法

向宏辉; 侯敏杰; 刘志刚

一种实现轴流压气机试验特性关联的经验方法

中国航空工业集团公司中国燃气涡轮研究院, 四川江油 621703

计量
- 文章访问数: 1381
- HTML浏览量: 1
- PDF量: 986
- 被引次数: 0
出版历程
- 收稿日期: 2012-11-20
- 刊出日期: 2013-07-28

Experiential method for realizing correlation of experimental characteristics of axial flow compressors

China Gas Turbine Establishment, Aviation Industry Corporation of China, Jiangyou Sichuan 621703, China

摘要

摘要: 采用系统研究思想,对10余台轴流压气机稳态性能试验数据进行了整理分析,在统计层次上探索了现有气动/结构设计体系下离散试验数据之间的内在关联规律.详细阐述了关联基准点的选取、关联基准线的构造、稳定工作边界的预估、特性线的泛化拟合和关联基准点的求解等环节,成功构建了一种实现多级轴流压气机试验特性有效关联的经验分析方法.结果表明:该经验方法对于大流量低速压气机变工况特性具有较好的预估能力,总体相对误差小于±10%.该方法可应用于同类型新设计压气机变工况特性表征关系的经验重构和先期性能评定,为压气机离散试验数据的挖掘、利用提供技术支持.
- 轴流压气机 /
- 性能特性 /
- 相关性 /
- 曲线拟合 /
- 经验预估
Abstract: Steady state performance experimental data of more than ten axial flow compressors were arranged and analyzed based on systematic idea. The inherent correlative law of the discrete experimental data in existing aerodynamic and structural design systems was explored statistically. Based on selection of the correlation reference point, estimation of the stability boundary, generalized fitting of the characteristics, solution of the correlation reference point and other aspects, an experiential analysis method for correlating the experimental characteristics of multistage axial flow compressors were built successfully. The results show that the experiential method has good prediction ability for large flow low-speed compressor off-design characteristics, with its general relative error less than ±10%. This analysis method can be applied to experiential reconstruction and advanced evaluation of the off-design characteristics of same type newly designed compressor, providing a technical support for discrete experimental data mining of axial flow compressors.
- axial flow compressor /
- performance characteristic /
- correlative relationship /
- curve fitting /
- experiential evaluation

HTML

参考文献(17)

[1]	Irving A,Johnsen,Robert O,et al.Aerodynamic design of axial flow compressors [R].NASA N65-23345,1965.
[2]	Wassell A B.Reynolds number effects in axial compressors[R].ASME WA/GT-2,1967.
[3]	Kurzke J,Riegler C.A new compressor map scaling procedure for preliminary conceptional design of gas turbines [R].ASME Paper 2000-GT-0006,2000.
[4]	Kong C D,Ki J Y.A new scaling method for component maps of gas turbine using system identification[J].ASME Journal of Engineering for Gas Turbines Power,2003,125(4):979-985.
[5]	Drummond C,Davison C R.Capturing the shape variance in gas turbine compressor maps [R].ASME Paper GT-2009-60141,2009.
[6]	Cravero C,Macelloni P.A new model for the prediction of compressor performance maps [R].ISABE-2009-1133, 2009.
[7]	Kurzke J.Correlations hidden in compressor maps.ASME Paper GT-2011-45519,2011.
[8]	张娜,林汝谋,蔡睿贤.压气机特性通用数学表达式[J].工程热物理学报,1996,17(1):21-24. ZHANG Na,LIN Rumou,CAI Ruixian.General formulas for axial compressor performance estimation[J].Journal of Engineering Thermophysics,1996,17(1):21-24.(in Chinese)
[9]	航空发动机设计手册总编委会.航空发动机设计手册:压气机[M].北京:航空工业出版社,2001.
[10]	XIANG Honghui,REN Minglin.Discussion of several questions with efficiency assessment in axial flow compressor experiment [R].JSASS-2009-5537,2009.
[11]	向宏辉,葛宁,任铭林.基于试验数据的轴流压气机喘振边界经验预估方法[J].燃气轮机技术,2011,24(1):40-44. XIANG Honghui,GE Ning,REN Minglin.Empirical prediction method of the surge line of axial flow compressors based on statistical experimental data[J].Gas Turbine Technology,2011,24(1):40-44.(in Chinese)
[12]	Drummond C,Davison C R.Improved compressor maps using approximate solutions to the Moore Greitzer model[J].ASME Paper GT-2009-60148,2009.
[13]	王志涛,李淑英,谭智勇.基于BP和RBF神经网络压气机特性曲线拟合方法的研究[J].汽轮机技术,2009,51(2):94-96. WANG Zhitao,LI Shuying,TAN Zhiyong.Comparing study on the fitting method of compressor characteristic curve based on BP and RBF neural network[J].Turbine Technology,2009,51(2):94-96.(in Chinese)
[14]	蒋爱武,谢寿生.基于支持向量机和粒子群算法的压气机特性计算[J].航空动力学报,2010,25(11):2571-2577. JIANG Aiwu,XIE Shousheng.Method to achieving compressor characteristics based on support vector machine(SVM) and particle swarm optimization(PSO)[J].Journal of Aerospace Power,2010,25(11):2571-2577.(in Chinese)
[15]	尹大伟,李本威,王永华,等.基于Kriging方法的航空发动机压气机特性元建模[J].航空学报,2011,32(1):99-106. YIN Dawei,LI Benwei,WANG Yonghua,et al.Aeroengine compressor characteristics metamodeling using Kriging method[J].Acta Aeronautica et Astronautics Sinica,2011,32(1):99-106.(in Chinese)
[16]	刘喜超,唐胜利.基于偏最小二乘法的压气机特性曲线的拟和[J].汽轮机技术,2006,48(5):327-329. LIU Xichao,TANG Shengli.Mathematical model of compressor characteristic map based on the partial least square theory[J].Turbine Technology,2006,48(5):327-329.(in Chinese)
[17]	杨欣毅,沈伟,刘海峰,等.一种应用滑动最小二乘求取压气机特性的方法[J].航空动力学报,2009,24(8):1741-1746. YANG Xinyi,SHEN Wei,LIU Haifeng,et al.Compressor characteristics generation method using moving least square[J].Journal of Aerospace Power,2009,24(8):1741-1746.(in Chinese)
