紧连阀轴流压气机变转速过失速瞬态模型

黄伟; 黄向华

紧连阀轴流压气机变转速过失速瞬态模型

黄伟,
黄向华

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 江苏省普通高校研究生科研创新计划(CX10B_106Z-02);航空科学基金(2009ZB52024)

计量
- 文章访问数: 1489
- HTML浏览量: 3
- PDF量: 990
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-12
- 刊出日期: 2013-07-28

Post stall transient model for axial compressor with closed-coupled valve under non-constant speed condition

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为了给各种压气机喘振主动控制器提供验证平台,提出了一个新的旋转失速及喘振模型.该模型在Moore-Greitzer轴流压气机过失速瞬态模型的基础上,考虑了转子动态及旋转失速高阶谐波对压气机气动稳定性的影响,并且在模型中增加了紧连阀作为执行机构.仿真结果表明:随着压气机转速的增加,压气机的失稳行为由旋转失速转为喘振;压气机转速的变化作为系统内部扰动,可能使压气机在节流阀开度较大时便进入气动失稳状态;虽然压气机初始扰动仅含有1阶谐波,但随着旋转失速的发展,高阶谐波强度不断增长而变得不可忽略.
- 轴流压气机 /
- 紧连阀 /
- 旋转失速 /
- 喘振 /
- Moore-Greitzer模型
Abstract: To provide a verification platform for various active surge controllers,a new rotating stall and surge model for axial compressor was proposed.Based on Moore-Greitzer post stall transient model,influences of spool dynamics and higher harmonics of rotating stall waves were considered in the proposed new model.In addition,a closed-coupled valve was included in the model as an actuator.Several conclusions can be made from simulation results.Firstly,with the increasing of rotor speed,the instability behavior of compressor transforms from rotating stall to surge.Secondly,as an internal disturbance,the spool dynamic may lead to instability even under large throttle opening conditions.Finally,even the initial disturbance only includes the first harmonics,the higher harmonics may become strong and have a significant effect on the behavior of rotating stall.
- axial compressor /
- closed-coupled valve /
- rotating stall /
- surge /
- Moore-Greitzer model

HTML

参考文献(19)

[1]	Camp T R,Day I J.A study of spike and modal stall phenomena in a low-speed axial compressor[J].Journal of Turbomachinery,1998,120(3):393-401.
[2]	Hoying D A,Tan C S,Vo H D,et al.Role of blade passage flow structures in axial compressor rotating stall inception[J].Journal of Turbomachinery,1999,121(4):735-742.
[3]	Vo H H,Greitzer E M.Criteria for spike initiated rotating stall [R].ASME Paper GT-2005-68374,2005.
[4]	Hah C,Schulze R,Wagner S,et al.Numerical and experimental study for short wavelength stall inception in a low-speed axial compressor [R].ISABE Paper 99-7033,1999.
[5]	SUN Xiaofeng.On the relation between the inception of rotating stall and casing treatment.AIAA 96-2579,1996.
[6]	SUN Xiaofeng,SUN Dakun,YU Weiwei.A model to predict stall inception of transonic axial flow fan/compressors[J]. Chinese Journal of Aeronautics,2011,24(6):687-700.
[7]	Moore F K,Greitzer E M.A theory of poststall transients in axial compressor:Part Ⅰ development of equations[J].Journal of Turbomachinery,1986,108(2):68-76.
[8]	Bonnaure L P.Modeling high speed multistage compressor stability [D].Massachusetts,US:Massachusetts Institute of Technology,1991.
[9]	Hendricks G J,Bonnaure L P,Longley J P,et al.Analysis of rotating stall onset in high-speed axial flow compressor [R].AIAA 93-2233,1993.
[10]	Feulner M R,Hendricks G J,Paduano J D.Modeling flow control of rotating stall in high speed multi-stage axial compressors [R].ASME Paper 1994-GT-2,1994.
[11]	Gravdahl J T,Egeland O.A Moore-Greitzer axial compressor model with spool dynamics [C]//Proceeding of the 36th IEEE Conderence on Decision and Control.California San Diego,US:IEEE,1997:4714-4719.
[12]	HU Jun,Fottner L.A new simplified model of post stall transients in axial compression system[J].Journal of Thermal Science,1999,8(3):176-189.
[13]	Abed E H,Houpt P K,Hosny W M.Bifurcation analysis of surge and rotating stall in axial flow compressors[J].Journal of Turbomachinery,1993,115(4):817-824.
[14]	王建,李应红,张东方,等.基于分岔理论的轴流式压气机旋转失速主动控制技术[J].航空动力学报,2007,22(7):1179-1183. WANG Jian,LI Yinghong,ZHANG Dongfang,et al.Investigation on active control of rotating stall in axial flow compressors via bifurcation theory[J].Journal of Aerospace Power,2007,22(7):1179-1183.(in Chinese)
[15]	Gravdahl J T,Egeland O.Two results on compressor surge control with disturbance rejection [C]//Proceeding of the 37th IEEE Conference on Decision and Control.Tampa,US:IEEE,1998:2563-2568.
[16]	Daroogheh N,Jahed-Motlagh M R,Beheshti M T H.Robust adaptive control of surge instability in a centrifugal compressor with variable speed [C]//Proceeding of American Control Conference.Baltimore,US:IEEE,2010:5056-5061.
[17]	Bartolini G,Ferrara A,Levant A,et al.A survey of applications of second-order sliding mode control to mechanical systems[J].International Journal of Control,2003,76(9/10):875-892.
[18]	高永,李本威,向锦武,等.基于模糊理论的轴流式压气机防喘控制器设计[J].航空动力学报,2006,21(3):492-496. GAO Yong,LI Benwei,XIANG Jinwu,et al.Design of the active anti-surge fuzzy controller for axial-flow compressors[J].Journal of Aerospace Power,2006,21(3):492-496.(in Chinese)
[19]	Simon J S,Valavani L,Epstein A H,et al.Evaluation of approaches to active compressor surge stabilization[J].Journal of Turbomachinery,1993,115(4):57-67.
