类乘波体防热壁板气动加热-温度场耦合特性分析

程兴华; 杨涛; 丰志伟

类乘波体防热壁板气动加热-温度场耦合特性分析

国防科学技术大学航天与材料工程学院, 长沙 410073

计量
- 文章访问数: 1333
- HTML浏览量: 4
- PDF量: 1137
- 被引次数: 0
出版历程
- 收稿日期: 2012-07-10
- 刊出日期: 2013-07-28

Analysis of aeroheating-temperature field coupling characteristics for thermal protection panel of quasi-wavrider

College of Aerospace and Material Engineering, National University of Defense Technology, Changsha 410073, China

摘要

摘要: 针对类乘波体防热壁板,采用松耦合算法推进气动热和传热迭代计算,研究气动加热-温度场的耦合特性.结果表明:在壁板达到辐射平衡前,冷壁热流和辐射平衡热流与真实气动加热的误差分别达+55.1%和-15.4%以上,必须将气动加热和温度场进行耦合分析;当地绝热壁面温度不随时间变化,表面传热系数是耦合效应的关键参数;采用平均表面传热系数进行瞬态气动加热-温度场耦合计算只进行2次气动加热计算,壁面温度预测误差在2.5%以内,可有效提高气动加热-温度场耦合计算的效率.
- 耦合 /
- 气动加热 /
- 温度场 /
- 防热壁板 /
- 类乘波体
Abstract: For thermal protection panel of quasi-waverider, the loose coupling algorithm was applied to drive the iteration of the aeroheating and heat transfer analysis. Then, the coupling characteristics of aeroheating-temperature field were studied. The results show that, before radiative equilibrium, the errors of cold wall and radiative equilibrium aeroheating are +55.1% and -15.4% over actual aeroheating respectively, so coupling analysis for aeroheating-temperature field was required. As the local adiabatic wall temperature is not changed with time, the surface heat-transfer coefficient is a key parameter for coupling effect. Only two aeroheating calculations are needed during calculation of coupling aeroheating-temperature field with average heat convection coefficient, and the error of predicted wall temperature is less than 2.5%, thus highly improving the analysis efficiency of coupled aeroheating-temperature field.
- coupling /
- aeroheating /
- temperature field /
- thermal protection panel /
- quasi-wavrider

HTML

参考文献(15)

[1]	宋少云.多场耦合问题的协同求解方法研究与应用 [D].武汉:华中科技大学,2007. SONG Shaoyun. Research and application of collaborative solution method for multiphysics problems [D].Wuhan: Huazhong University of Science and Technology,2007.(in Chinese)
[2]	Mcnamara J J,Friedmann P P,Powell K G,et al.Three-dimensional aeroelastic and aero-thermoelastic behavior in hypersonic flow.AIAA-2005-2175,2005.
[3]	Culler A J,Mcnamara J J.Studies on fluid-thermal-structural coupling for aerothermoelasticity in hypersonic flow[J].AIAA Journal 2010,48(8):1721-1738.
[4]	Spain C,Soistmann D,Parker E.An overview of selected NASP aeroelastic studies at the NASA Langley Research Center.AIAA 90-25218,1990.
[5]	吴志刚,惠俊鹏,杨超.高超声速下翼面的热颤振工程分析[J].北京航空航天大学学报,2005,31(3):270-273. WU Zhigang,HUI Junpeng,YANG Chao.Hypersonic aerothermoela stic analysis of wings[J].Journal of Beijing University of Aeronautics and Astronautics,2005,31(3):270-273.(in Chinese)
[6]	吕继航,杨茂,陈凤明.超音速舵面热气动弹性仿真[J].计算机仿真,2010,27(3):43-46. LV Jihang,YANG Mao,CHEN Fengming.Aerothermoelastic simulation of supersonic missile rudder[J].Computer Simulation,2010,27(3):43-46.(in Chinese)
[7]	Borrelli R,Riccio A,Tescione D,et al.Thermo-structural behaviour of an UHTC made nose cap of a reentry vehicle[J].Acta Astronautica,2009,65(314):441-456.
[8]	Myers D E,Martin C J,Blosser M L.Parametric weight comparison of advanced metallic,ceramic tile,and ceramic blanket thermal protection systems.NASA/TM-2000-210289,2000.
[9]	中国人民解放军总装备部军事训练教材编辑工作委员会.高超声速气动热和热防护[M].北京:国防工业出版社,2003.
[10]	Fay J A,Riddell F R.Theory of stagnation point heat transfer in dissociated air[J].Journal of the Aerospace Science,1985,25(2):73-85.
[11]	黄志澄.高超声速飞行器空气动力学[M].北京:国防工业出版社,1995.
[12]	吕丽丽,张伟伟,叶正寅.高超声速再入体表面热流计算[J].应用力学学报,2006,23(2):259-263. LV Lili,ZHANG Weiwei,YE Zhengyin.The calculation of surface heating rates for hypersonic reentry-body[J].Chinese Journal of Applied Mechanics,2006,23(2):259-263.(in Chinese)
[13]	程兴华,杨涛,常中东.熵层对高超声速二维钝楔气动参数的影响[J].航空动力学报,2012,27(6):1362-1367. CHENG Xinghua,YANG Tao,CHANG Zhongdong.Influence of entropy layer on aerodynamics parameters for hypersonic 2-D blunt wedge[J].Journal of Aerospace Power,2012,27(6):1362-1367.(in Chinese)
[14]	CHENG Xinghua,YANG Tao,LIU Xin.An improved data exchange algorithm based on the relationships between point and triangle[J].Advanced Materials Research,2012,538/539/540/541:777-783.
[15]	Cebral J R,Loehner R.Fluid-structure coupling extensions and improvements [R].AIAA 97-0858,1997.
