旋流空气对双油路离心喷嘴雾化特性影响的实验

周兵; 吉洪湖; 张宝诚

旋流空气对双油路离心喷嘴雾化特性影响的实验

1.
南京航空航天大学能源与动力学院, 南京210016
2.
沈阳航空航天大学动力与能源学院, 沈阳110136

计量
- 文章访问数: 1458
- HTML浏览量: 11
- PDF量: 1044
- 被引次数: 0
出版历程
- 收稿日期: 2012-09-08
- 刊出日期: 2013-09-28

Experiment of swirled air effect on spray characteristic of double-line pressure-swirl atomizer

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
College of Energy and Power Engineering, Shenyang University of Aeronautics and Astronautics, Shenyang 110136, China

摘要

摘要: 采用相位多普勒粒子分析仪(PDPA)对带空气旋流器的双油路离心喷嘴的雾化特性进行了实验研究,供油压力的工作范围在0.3~2.1MPa,采用轴向逆流器,旋流器叶片出口角为79°,旋流器前后空气压降在0.03~0.15MPa,实验得到了索太尔平均直径(SMD)与喷雾锥角随供油压力与风速的变化规律.结果表明:在相同供油压力下,旋流器通入空气后,喷雾锥角值较未通入旋流空气时将增大15°~20°,索太尔平均直径比未通入旋流空气时减小40%.
- 旋流空气 /
- 离心喷嘴 /
- 多普勒粒子分析仪 /
- 喷雾锥角 /
- 雾化
Abstract: The spray characteristic of the double-line pressure-swirl atomizer with air swirler was investigated using phase Doppler particle analyzer(PDPA).The fuel injection pressure ranged from 0.3MPa to 2.1MPa.The axial air swirler with blade outlet angle of 79°was adopted.The air pressure drop across the swirler ranged from 0.03MPa to 0.15MPa.The change rules of Sauter mean diameter(SMD) and spray cone angle with fuel injection pressure and swirled air velocity were obtained.The results show that in contrast with the situation without swirled air,the spray cone angle increases by 15°~20°and the Sauter mean diameter decreases by 40% which is induced by swirled air under the same fuel injection pressure.
- swirled air /
- pressure-swirl atomizer /
- phase Doppler particle analyzer /
- spray cone angle /
- spray

HTML

参考文献(16)

[1]	侯晓春,季鹤鸣,刘庆国.高性能航空燃气轮机燃烧技术[M].北京:国防工业出版社,2002.
[2]	甘晓华.航空燃气轮机燃油喷嘴技术[M].北京:国防工业出版社,2006.
[3]	金如山.航空燃气轮机燃烧室[M].北京:宇航出版社,1988.
[4]	王宏明,全中,甘晓华.燃油喷嘴对燃烧性能的控制研究[J].推进技术,1991,12(6):36-41. WANG Hongming,QUAN Zhong,GAN Xiaohua.An investigation on fuel nozzles on combustion performance[J].Journal of Propulsion Technology,1991(6):36-41.(in Chinese)
[5]	Rink K K,Lefebvre A H.Influence of fuel drop size and combustor operating conditions on pollutant emission[J].International Journal of Tuber and Jet Engines,1989,6(2):113-121.
[6]	丁红明,诸惠民.离心式压力雾化喷嘴性能计算方法的比较[J].航空发动机,1999(3):44-50. DING Hongmin,ZHU Huimin.Spray parameters of pressure-swirl atomizer[J].Aeroengine,1999(3):44-50.(in Chinese)
[7]	杨建辉,樊未军,杨茂林.离心式喷嘴雾化参数的计算[J].航空动力学报,2003,18(6):799-802. YANG Jianhui,FAN Weijun,YANG Maolin.A calculation of spray parameters of pressure-swirl atomizer[J].Journal of Aerospace Power,2003,18(6):799-802.(in Chinese)
[8]	陈俊,吉洪湖,张宝诚.双路离心喷嘴雾化特性的实验[J].航空动力学报,2010,25(4):774-779. CHEN Jun,JI Honghu,ZHANG Baocheng.Experimental investigation of spray characteristics of a double line pressure-swirl atomizer[J].Journal of Aerospace Power,2010,25(4):774-779.(in Chinese)
[9]	陈俊,吉洪湖,张宝诚.双油路离心喷嘴雾化油滴的平均和脉动速度场的实验[J].航空动力学报,2010,25(11):2464-2471.(in Chinese) CHEN Jun,JI Honghu,ZHANG Baocheng.Investigation on mean and fluctuation velocity distribution of droplet from a double line pressure-swirl atomizer with PDPA[J].Journal of Aerospace Power,2010,25(11):2464-2471.(in Chinese)
[10]	Chu C C,Chou S F,Lin H I,et al.An experimental investigation of swirl atomizer sprays[J].Heat Mass Transfer,2008,45(1):11-22.
[11]	Gellalles A G.Effect of orifice length-diameter ratio on spray characteristics.National Advisory Committee for Aeronautics TN-352,1930.
[12]	杨立军,葛明和,张向阳,等.喷口长度对离心喷嘴雾化特性的影响[J].推进技术,2005,26(3):209-214. YANG Lijun,GE Minghe,ZHANG Xiangyang,et al.Effects of spout length on spray characteristic of swirl injector[J].Journal of Propulsion Technology,2005,26(3):209-214.(in Chinese)
[13]	张弛,张荣伟,徐国强,等.直射式双旋流空气雾化喷嘴的雾化效果[J].航空动力学报,2006,21(5):805-809. ZHANG Chi,ZHANG Rongwei,XU Guoqiang,et al.Experimental investigation on atomization of an air-blast atomizer with plain-orifice nozzle and dual-swirl cup[J].Journal of Aerospace Power,2006,21(10):805-809.(in Chinese)
[14]	郭新华,林宇震,张弛,等.离心式同向双旋流器空气雾化喷嘴雾化特性研究[J].航空动力学报,2009,24(10):2249-2254. GUO Xinhua,LIN Yuzhen,ZHANG Chi,et al.Experiment investigation on atomization characteristic of an air blast atomizer with centrifugal nozzle and co-dual-swirl cup[J].Journal of Aerospace Power,2009,24(10):2249-2254.(in Chinese)
[15]	Hadef R,Lenze B.Effects of co-and counter-swirl on the droplet characteristics in a spray flame[J].Chemical Engineering and Processing,2008,47(12),2209-2217.
[16]	Karnawat J,Kushari A.Spray evolution in a twin-fluid swirl atomizer[J].Automization and Sprays,2008,18(5):449-470.
